Dennis FT Instruction Manual page 30

Fine turf cassette mower
Table of Contents

Advertisement

4
2
9
7
8
8.01
Item No. Description
1
See 8.02
2
J20119
3
J20256
4
J20461
5
J20463
6
J209201
7
SP03016
8
SP02008
9
J20462
10
J20457
11
SP01008
12
SP01035
NOTE
For Brake Band Cable, see Section 6.01
FT & Super Six
12
11
3
5
Part Number
Rear Roller Assy
Spring Scraper Brake Band
Roller Slot Cover Plate
Brake Drum
Brake Band Assy
Rear Roller Driven Pulley
Washer M10 Form C
Nut M10 Nyloc
Key Woodruff (606) 3/16" x 3/4"
Key 3/16" x 3/16" x 1" Rd End
Hex Set Screw M6 x 16
Hex Set Screw M10 x 25
Rear Roller - Main Assembly
Quantity
1
1
2
1
1
1
2
2
1
1
2
8
30
10
11
12
3
1
7
8
6
SP20001_REV_6
