3.2 Connecting the Printer
The S3750THS printer supports Serial RS232 and IrDA compatible infrared
communication interfaces. Radio frequency (RF) communication is also
available as an optional feature as well as 802.11b interface.
Serial, IrDA, 802.11b and Bluetooth communication settings can be changed
via a DIP switch located on the control card.
The DIP switch is located inside the battery compartment as illustrated below
indicating the location of this switch. Figure 2 shows the DIP switch selection.
The functions assigned to these switches are shown in Table 2.
If the Serial interface is selected, the communication Parameters, Baud rate,
Data Bit and Parity, must be set. These parameters apply both for UART 1
and UART 2.
Note: Optional serial cable is available for Serial RS232
communication (part # 5892RJD9).
Printer drivers for Windows 95/98/NT/2000 and XP are available from
Extech.
PrinterCE print Control utility is available from Extech for Windows CE
devices.
Printboy Print Utility from Bachmann Software or PalmPrint Utility, from
StevensCreek, are recommended for Palm Pilot devices
F
i
g
u
r
e
2
:
D
i
p
S
w
i
t
c
F
i
g
u
r
e
2
:
D
i
p
S
w
i
t
c
h
L
o
c
a
t
i
o
n
h
L
o
c
a
t
i
o
n
Page 11
