Pro-Form PFTL11012.0 User Manual page 8

2. Pull the Upright Wire (78) and the base ground
wire (A) through the indicated hole in the
Base (95).
If there is a screw (B) preinstalled in the side
of the Base (95), remove and discard it. Attach
the ground wire (A) to the Base with a #8 x 1/2"
Silver Screw (9).
Press the Grommet (90) into the square hole in
the Base (95).
3. Identify the Left Upright (79). Have a second
person hold the Left Upright near the Base (95).
See the inset drawing. Tie the wire tie in the
Left Upright (79) securely around the end of the
Upright Wire (78). Then, pull the other end of the
wire tie until the Upright Wire is routed through
the Left Upright.
2
Hole
78
9
3
78
Wire
Tie
79
8
90
B
A
95
79
Wire
Tie
78
95
78
