8. Set the console assembly face down on a soft
surface to avoid scratching the console assem-
bly. Remove and discard the three screws (D).
Then, lift off the Console Cover (100).
9. Set the console assembly on the Left Handrail
(83) and the Right Handrail (86). Make sure not
to pinch any wires (E, 78).
Attach the console assembly with four 5/16" x
1/2" Screws (8) and four 5/16" Star Washers
(11). Do not tighten the Screws yet.
8
D
100
9
86
11
8
11
Console
Assembly
D
Console
Assembly
E
83
78
11
8
