10. Attach the console assembly to the Handrails
(83, 86) with four #10 x 3/4" Screws (7) and four
#10 Star Washers (14) as shown. Start all four
Screws, and then tighten them.
11. Connect the Upright Wire (78) to the console
wire (E). See the inset drawing. The connec-
tors should slide together easily and snap
into place. If they do not, turn one connector
and try again. IF YOU DO NOT CONNECT THE
CONNECTORS PROPERLY, THE CONSOLE
MAY BECOME DAMAGED WHEN YOU TURN
ON THE POWER.
Insert the excess wires (E, 78) into the console
assembly.
Firmly tighten the four 5/16" x 1/2" Screws (8)
(only two are shown).
10
Console
Assembly
7
11
E
78
12
14
83
Console
Assembly
8
78
E
7
14
86
