Summary of Contents for XTZ XTZ 99 W8.16
- Page 1 XTZ 99 W8.16 XTZ 99 W8.16 XTZ 99 W8.16 XTZ 99 W8.16 Active subwoofer User's manual...
-
Page 2: Table Of Contents
Congratulations on your purchase of a XTZ Home Theatre Contents Powered Subwoofer System! About XTZ When combined with surround audio/video electronics, Technical presentation you'll experience motion picture sound as it was originally meant to be. Now when you watch your favorite movie,... -
Page 3: About Xtz
About XTZ Philosophy Our reference and startling point is to recreate a natural sound, but also in respect to the fact that acoustics always is a matter of taste. XTZ goals Our main goal is to provide the best possible compromise of cost, performance and quality available on the market. -
Page 4: Technical Presentation
The amplifier / We have equipped the XTZ W8.16 with a very powerful crossover amplifier with a big cooling flange for effective cooling. The terminal connectors are gold-plated and very solid. -
Page 5: Preparations
Preparation Unpacking the Carefully unpack the speaker, and pay attention so you don't subwoofer brake anything. If possible, save the carton box for future transportations. If there should be a damage on the loudspeaker, please contact your retailer. Accessories 2 bass plugs (found in the bass reflex gates) User's manual... -
Page 6: Practice Of Sound / Installation And Placement Tips
Practice of sound / Installation and placement tips This chapter contains common information on loudspeaker placement and installation. In which room No matter how good the equipment is, in the wrong do you achieve listening environment it will inevitably sound bad. There are the best sound? some basic rules concerning... - Page 7 Cables Try to keep them as short as possible. By its electrical parameters, a long conductor will have a bigger influence on the sound than a short one. It may also work as an antenna and thus receive various signals, that may become a constant noise in an active subwoofer.
-
Page 8: Mounting
Mounting The loudspeaker should stand as stable as Mounting The XTZ 99 W8.16 is best placed standing on the floor. possible, at loud sound levels both the alternatives speaker and the surroundings may vibrate However it is fully possible to lay it down without affecting so heavy that it may move the speaker. -
Page 9: Connections
From the low level output (sub-out) on the amplifier you power cord until everything else is low level connect a RCA cable to SUB IN on the XTZ 99 W8.16. connected! output If you wish to use an additional active subwoofer, you may (sub-out) connect this from the SUB OUT of the XTZ 99 W8.16. -
Page 10: Control Descriptions
Control Descriptions Sound is always a matter of time, so please By using the controls and the supplied bass plug, you can take yout time to find the sound to fit your alter the sonic characteristics in a wide variety. This is a personal taste. - Page 11 By using the supplied bass plugs in the bass reflex gates, you efficiency you will have to adjust the volume, Mechanical can alter the lower boundary frequency on XTZ 99 frequency and High Pass in the room tuning adjustment of WW10.16.
-
Page 12: Sound Settings
Sound settings Basic setting for Since the sonic characteristics depends on a whole range of a neutral bass external factors, there exists no "standard" setting for a representation neutral representation. The external factors that have impact on the sound include the room, the placement of the speaker, output levels etc. -
Page 13: Functional Reference
Functional reference This chapter describes all settings and connections. XTZ 99 W8.16 rear panel... - Page 14 To obtain the optimal sound, you should let Power switch Power switch. Press down "I" to power on and the indicator the subwoofer be in ON mode. The amplifier (ON, OFF) will will then immediately have the right be lighted. Press "0" to power off. Make sure it is set OFF working temperature from the beginning.
-
Page 15: Technical Specifications
Technical specifications Construction Active subwoofer, Bass reflex gate or may be set as closed type box. Dimensions 300 x 360 x 380 mm (WxDxH) Foot +15 mm Amplifier +20 mm Weight 16 kg Terminal Goldplated RCA connection Power 100 W RMS at 4 ohms 200 W DIN Settings and Low level input and output. -
Page 16: Service & Support
In other cases however, the warranty does not apply if you cause other defects on the loudsspeaker. Where to send the For service we refer to your XTZ dealer. ALWAYS pack the product / part very product for a warranty carefully.
