Summary of Contents for XTZ 99 W12.18 ICE
- Page 1 XTZ 99 W12.18 ICE High End subwoofer User manual © 2009 XTZ AB , www.xtz.se Page: 1 / 12...
-
Page 2: Table Of Contents
Table of contents Page: Contents About XTZ Technical presentation Preparations Practice of sound / Installation and placement tips Mounting Functional reference Area of usage Technical specifications Service & Support Page: 2 / 12... -
Page 3: Contents
The 99 W12.18 ICE subwoofer combines a 550-watt continuous power amplifier, heavy-duty 12" woofer. 99 W12.18 ICE is a product with many options, so read the manual carefully before using it. Read the manual before using the product and use all possibilities carefully. -
Page 4: Technical Presentation
Technical presentation Amplifier The XTZ 99 W12.18 ICE is equipped with The Danish Bang & Olufsen ICEpower has been one of the pioneers in developing ICEpower® 125ASX2, a powerful 550 watt new technologies to enhance Class D amplifier. For professional use (studio, PA etc), it is amplification and bring the audio quality equipped with a balanced input. -
Page 5: Preparations
Preparations Carefully unpack the speaker, and pay attention so Unpacking the you don't break anything. If possible, save the subwoofer packing box for future transportations. If there should be damage on the loudspeaker, please contact your retailer. Accessories 1 Power chord 2 bass plugs (found in the bass reflex gates) User manual Speaker cover... -
Page 6: Practice Of Sound / Installation And Placement Tips
Practice of sound / Installation and placement tips This chapter contains common information on loudspeaker placement and installation. This is general rules, so there are exceptions of some rules No matter how good the equipment is, in the wrong In which room do listening environment it will inevitably sound bad. - Page 7 Try to keep them as short as possible. By its Cables electrical parameters, a long conductor will have a bigger influence on the sound than a short one. It may also work as an antenna and thus receive various signals that may become a constant noise in an active subwoofer.
-
Page 8: Mounting
This subwoofer is intended for XTZ products, but can of course be used with other speakers. Spikes 99 W12.18 ICE have feet of rubber to absorb vibrations. But it’s possible to change this to spikes. The Rubber foot are adjustable to get the subwoofer in level with the floor. -
Page 9: Functional Reference
Functional reference Rear panel 1. Volume 2. Frequency 3. Phase 4. Auto On 5. EQ 1 6. EQ 2 7. High Pass/Subsonic 8. XLR/Balanced Input 9. RCA/Line In 10. Standby/On indicator 11. Speaker In/High Level 12. Fuse 13. Input voltage 14. - Page 10 The phase is determined by several things: altering the poles of the cables (setting + to - and - -Placement of 99 W12.18 ICE to +) -Placement referred to the rest of the system. -The crossover frequency. If the phase is not correct, a top or dip will...
-
Page 11: Area Of Usage
Mechanical factors, there exists no "standard" setting on XTZ 99 W12.18 ICE adjustment of the for a neutral representation. This makes it possible to alter the sonic boundary frequency characteristics of the woofer. -
Page 12: Technical Specifications
Please contact our “free-of-charge” support if you need installation advice, or if any problems occur during the installation. Contact us by e-mail support@xtz.se and include your phone number if you require help, and we will ring you back. Page: 12 / 12...
