DIMENSIONS AND ACCESSORIES
Figure 4.1 - Model POR Dimensions
Table 4.1 - Dimensions (Inches)
Model
A
B
POR100
27-1/2
35-1/4
POR145
27-1/2
35-1/4
POR185
28-5/8
40-1/4
Accessories
Low-Voltage Thermostats – Single-stage, 24-volt.
Thermostat Guard – Protects from damage or tampering.
Booster Pump Relay – Used to control booster pump
operation in the oil supply system. Factory set to close contacts
at 50 PSIG with a maximum allowable pressure of 150 PSIG.
Supplied with a 1/8" MPT connector and screw terminals.
Oil Safety Valve – Protects the burner pump from excessive
line pressure. The maximum inlet pressure is 60 PSIG.
Fuel Oil Filter – Protects oil burner from foreign particles.
As Modine Manufacturing Company has a continuous product improvement program, it reserves the right to change design specifications without notice.
Distributed By:
C
D
E
F
28-1/8
25
23-7/8
13-3/4
28-1/8
25
23-7/8
13-3/4
32-3/4
26-1/8
23-7/8
14-3/8
G
H
J
K
8-5/8
23-7/8
8
12
8-5/8
23-7/8
9-1/2
12
8-5/8
25
10
13-3/4 42-3/4 20-3/4
Vertical Louvers – Used in combination with standard
horizontal louvers for complete control of air delivery.
Draft Regulator – Barometric type with screw adjustments and
hinge-pin action. Designed for precise control of drafts.
Outside Combustion Air Kit – Kit converts the burner to
accept outside combustion air piping. Includes adapter,
gaskets, vacuum relief valve, outside intake air hood, and other
miscellaneous hardware.
4-112.3
Approx.
L
M
Y
Shipping Wt. (lbs)
38-1/8
16
8
38-1/8
16
8
8
Commercial Products Group
Modine Manufacturing Company
1500 DeKoven Avenue
Racine, Wisconsin 53403-2552
Phone: 1.800.828.4328 (HEAT)
Fax: 1.800.204.6011
www.modine.com
© Modine Manufacturing Company 2008
Litho in USA
324
333
398
