- Page 1 Leica IMS500 Leica IMS500 HD Manual Ryf AG Bettlachstrasse 2 2540 Grenchen tel 032 654 21 00 fax 032 654 21 09 www.ryfag.ch...
-
Page 2: Table Of Contents
Close Unpacking Specifications IMS500 Installation! IMS500 – Installation Basic Systems with Computers Specifications IMS500 HD IMS500 – Installation Advanced Systems with Computers and remote control USB IMS500 HD - Installation Basic System without Computers Leica IMS500 / IMS500 HD Manual... -
Page 3: Safety Regulations
Safety regulations Leica IMS500 / IMS500 HD Manual... -
Page 4: Safety Concept
Warning of a danger Important information individual modules of the Leica IMS500 Systems Interactive This symbol indicates especially important infor- This symbol indicates additional information or Microscopy System and contains important instructions for mation that must be read and complied with. -
Page 5: Important Notes
Description User Manual Accessories from third-party suppliers The Leica IMS500 Systems meets today's state of the art This user manual includes important instructions related to You can combine individual system articles with articles of technology. Nevertheless, hazards may still arise during operating safety, maintenance and accessories. -
Page 6: Instructions On Use
Disposal The devices and accessories described in this Position the Leica IMS500 Systems so that it can be Disposal must comply with locally applicable laws and operating manual have been tested for safety and disconnected from the power supply at any time. -
Page 7: Information For The Person Responsible For The Instrument
Only original Leica replacement parts may be used in observance of these responsibilities. servicing the product. Do not use the Leica IMS500 Systems system unless it After service work or technical modifications, the unit is in perfect condition. must be reconfigured with observance to our technical requirements. -
Page 8: Care Instructions
Protect the Leica abraded particles. IMS500 Systems from oil and grease. It is advisable to enter a service agreement with Leica Service. Cleaning coated parts and plastic parts Dust and dirt particles should be removed with a soft brush or lint-free cotton cloth. -
Page 9: Accessories, Maintenance And Repair
Accessories, maintenance and repair Accessories Maintenance Repairs and service work Only the following accessories may be used with the Leica The Leica IMS500 Systems are basically maintenance- Only original Leica Microsystems spare parts may be IMS500 Systems: free. To ensure that it always operates safely and reli- used. -
Page 10: Electrical Data And Ambient Conditions
They should be used for safely storing and transport- Atmospheric pressure "in use" and for storage: 500–1060 mBar ing the instrument should the need arise. Humidity “in use” and for storage: 20–90% Installation Category II (Overvoltage Category) Pollution degree 2 Leica IMS500 / IMS500 HD Manual... -
Page 11: Installation
All HD displays must have DVI and HDMI connections and DVI cables (some displays don't come with DVI cables included, therefore, be sure they are supplied with the display) Some manufacturers displays require that the camera resolution is changed to 720P All HD displays must be of the same model Leica IMS500 / IMS500 HD Manual... -
Page 12: Ims500 - Installation Basic Systems With Computers
IMS500 - Installation Basic Systems with Computers TEACHER Leica Leica Camera Camera VGA cable VGA cable from customer VGA cable VGA cable from customer Student Teacher VGA module VGA module another another 35101320 35101310 Student Student system system Central Unit... -
Page 13: Ims500 - Installation Advanced Systems With Computers
IMS500 - Installation Advanced Systems with Computers and remote control USB STUDENT TEACHER VGA cable Leica Leica Camera Camera Student Remote module 35101330 VGA from Teacher customer Remote module 35101333 another another Student Student system system Central Unit Central Student... -
Page 14: Ims500 Hd - Installation Basic System Without Computers
IMS500 HD - Installation Basic System without Computers STUDENT TEACHER Leica HD Leica HD Teacher HD Camera Student HD Camera display with Teacher display with Student DVI input (from Station DVI input (from Station customer) customer) Large HD display or HD... -
Page 15: Quick Start
The transmitter is indicated by flashing light, receivers by permanent light. To select a new transmitter, hold the key pressed down for about 1 second or reset the system (VIDEO OFF) and start a new input sequence. Leica IMS500 / IMS500 HD Manual... -
Page 16: Keypad Functions
S1, student 1 will be transmitter (if there is no other selected as receiver. transmitter selected). Student to Student Student 1 is selected as transmit- ter, other Students can be set a a reveiver. Leica IMS500 / IMS500 HD Manual... - Page 17 (e.g. INSTR. to ALL). Both (IMS500 HD ONLY) settings are working simultane- ously, VIDEO OFF will NOT turn off the Projector-Notebook function. To turn it off, hit the key again, or replace it by the function PROJ. INSTR. Leica IMS500 / IMS500 HD Manual...
-
Page 18: Additional Keypad Functions For Ims500 Advanced Systems With Computers And Remote Control
Additional Keypad functions for IMS500 Advanced Systems with computers and remote control Lock all keyboards and mice Remote control of student 1 Hold down the ALT FUNCT key while computer pressing the KEYB LOCK key to lock To control students´ 1 keyboard all student´s keyboards and mice. -
Page 19: Instructions For The Wireless Tablet Control Option
If the battery is completely discharged, you can not turn on ing with a serial 9-pin cable to the Instructor-Box. 5Volt USB Power Supply. the device even if the battery is charging. (Connector: Keyb). Leica IMS500 / IMS500 HD Manual... - Page 20 To start the Leica Microsystems control app select the icon Leica Microsystems on the home screen or through the application menu. Tap "Classroom 1" at the top of the screen. Leica IMS500 / IMS500 HD Manual...
- Page 21 The transmitter is marked with a green bar, one or more receivers are marked with a red bar. See the function of each button in the Quick Start guide on the previous pages. Leica IMS500 / IMS500 HD Manual...
- Page 22 The options will be shown by touching following button in the lower part of the screen. Leica IMS500 / IMS500 HD Manual...
- Page 23 Options (Overview) Includes IMS500/IMS500 HD User Manual Layout Creator To create individual room layouts. Close Closes the application. Current selections will not be closed. Leica IMS500 / IMS500 HD Manual...
-
Page 24: Layout Creator
Layout Creator Leica IMS500 / IMS500 HD Manual... - Page 25 With the layout creator you can create your own seating arrangement or change an existing seating plan. After starting the layout creator, a selection menu appears. Now you can choose the antenna/room, whose plan you want to create or change. Leica IMS500 / IMS500 HD Manual...
- Page 26 If you have chosen an antenna or room the current plan will be shown. If there is no existing plan, an empty plan will be shown to create a new one. Leica IMS500 / IMS500 HD Manual...
- Page 27 Add a student At the touch on an empty field a selection menu appears to choose a student number for that field. Leica IMS500 / IMS500 HD Manual...
- Page 28 If you want to remove a student number just touch the respective button on the tablet until it will be removed from screen. Save layout To save all settings open the option menu and choose „Save Layout“. Leica IMS500 / IMS500 HD Manual...
-
Page 29: Close
Close Layout Creator To close the Layout Creator open the option menu and choose „Close“. You will return to the main menu. When you select the appropriate classroom, you will see the changes you made. Leica IMS500 / IMS500 HD Manual... -
Page 30: Specifications Ims500
Central Unit Central Unit Cable Cables VGA-Cable (prefabricated) (prefabricated) Length 2 m …..30 m 1 m (1.8 m available) Weight 120 g (plugs) + 110g/m 200 g Connectors Sub-D25M, Sub-HD15M Sub-HD15M Sum-HD15F Leica IMS500 / IMS500 HD Manual... -
Page 31: Specifications Ims500 Hd
Boxes Teacher DVI-Box / 19.5 x 2.5 x 12.5 cm / 445 g / +5V DC Charger Boxes Student DVI-Box / 11.5 x 2.5 x 10.5 cm / 250 g / +5V DC Charger Leica IMS500 / IMS500 HD Manual... - Page 32 "with the user, for the user" has always been the Leica Microsystems – an international company with an experienced worldwide basis for the innovative strength of Leica Microsystems. On this, we have developed customer service network. our five corporate values:...
