Communication and Control, cont'd
Energy Save
When an energy save function is selected, power consumption
is reduced compared to the normal operating mode. When set
to Auto, this sensor measures the level of light inside the
viewing room. See the Pioneer Operating Instructions for
additional information.
Schedule page
Using the schedule page (figure 4-12), you can create scheduled
events such as power on/off, input changes, or send status
email.
Figure 4-12 — Pioneer Schedule screen
To enable an event to occur at a specified time
1. Click Schedule on the menu on the left side of the window.
The Schedule screen (figure 4-12) is displayed.
2. Select the check box beside a task.
3. Click Edit to view the calendar options and schedule the
time and date of the weekly event (figure 4-13).
Figure 4-13— Pioneer Schedule calendar
4. Click Save to submit the schedule.
For Users, this is a view-only function.
www.camboard.de
4-16 IPL M PDP-ES • Communication and Control
CAMBOARD Electronics
Tel. 07131 911201
Fax 07131 911203
Monitor page
Using the Monitor page (figure 4-13), you can monitor power
levels, internal temperature and usage of the Pioneer plasma.
An email notification can be sent to a recipient when specified
conditions are met or exceeded.
To do so
1. Click Monitor on the menu on the left side of the window.
The Monitor screen (figure 4-14) is displayed.
2. Select the check box for the appropriate condition.
3. Make appropriate changes.
4. Click Submit to input the changes.
For Users, this is a view-only function.
Figure 4-14— Pioneer Monitor screen
If status is unavailable, the system email notification
states that the internal temperature is 509° Celsius, and
the usage is 65535 hours.
ce-info@camboard.de
IPL M PDP-ES • Communication and Control
4-17
