4-Port DisplayPort® Video Splitter -
2560x1600
ST124DP
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
For the most up-to-date information, please visit: www.startech.com
Manual Revision: 07/09/2013
*actual product may vary from photos
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for StarTech.com DisplayPort ST124DP
Summary of Contents for StarTech.com DisplayPort ST124DP
- Page 1 DE: Bedienungsanleitung - de.startech.com FR: Guide de l'utilisateur - fr.startech.com ES: Guía del usuario - es.startech.com IT: Guida per l'uso - it.startech.com NL: Gebruiksaanwijzing - nl.startech.com PT: Guia do usuário - pt.startech.com For the most up-to-date information, please visit: www.startech.com Manual Revision: 07/09/2013...
-
Page 2: Fcc Compliance Statement
StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby... -
Page 3: Table Of Contents
Table of Contents Product Overview ..................1 Front View ..............................1 Rear View ..............................1 Remote Control ............................1 Introduction ....................2 Packaging Contents ..........................2 System Requirements ..........................2 Hardware Installation ................3 Hardware Operation ................3 Mode Video Audio..................5 Specifications ..................6 Technical Support ..................7 Warranty Information ................7 Instruction Manual... -
Page 4: Product Overview
Product Overview Front View Active Port Status LEDs Output Port Stanby/Function Activation Button Buttons Rear View EDID EDID Selection Copy Switch Button Output Ports Input Port Remote Control Instruction Manual... -
Page 5: Introduction
A perfect addition to virtually any application requiring the high quality video delivered by DisplayPort devices, the DP video splitter is easy to install and provides flawless, distortion-free digital video. The ST124DP is backed by a StarTech.com 2-year warranty and free lifetime technical support. Packaging Contents •... -
Page 6: Hardware Installation
1. Connect a DisplayPort Cable (not included) from your DisplayPort Video Source (i.e. computer) to the input Port on the ST124DP. 2. Connect a DisplayPort cable (not included) from the output ports on the ST124DP to each desired display device (up to 4). - Page 7 Blue LED will turn off indicating the standby process has begun. In this state the LED will flash every 5 seconds. b) To manually bring the ST124DP out of standby mode, and turn off all attached display devices. Press and hold the standby/function button for 5 seconds. The Blue flashing LED will turn solid and the display devices will turn back on.
-
Page 8: Mode Video Audio
Mode Video Audio Mode Function No EDID Copy Audio EDID Copy Video EDID Copy all (Audio + Vidoe) EDID a) Apply power to the unit. b) Connect the (EDID compliant) monitor to OUT 1 of the Unit and power on the monitor. -
Page 9: Specifications
Specifications AV Input 1x DisplayPort® AV Output 4x DisplayPort® Audio Max Resolution 2560 x 1600 Wide Screen Supported Universal Adapter Wall Plugs Included NA/EU/UK/AUS Power Adapter Included Input Voltage 100~240V Input Current 0.5 A A Output Voltage 12 DC V Output Current 1.5 A A Instruction Manual... -
Page 10: Technical Support
Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. - Page 11 StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology parts. StarTech.com was founded in 1985 and has operations in the United States, Canada, the United Kingdom and Taiwan servicing a worldwide market.
