- Page 1 UTP VGA VIDEO SPLITTER 4-port UTP VGA Video Splitter/Extender ST124UTP Instruction Guide ST124UTPLRR ST124UTPR * Actual product may vary from photo The Professionals’ Source For Hard-to-Find Computer Parts...
-
Page 3: Table Of Contents
Table of Contents Welcome 1. Introduction 2. The system components 3. The Central Unit 4. The Remote Long Range Unit 5. The Remote Short Range Unit ports 6. The cables 7. Connecting the System cables 8. Connecting the Screen cable 9. -
Page 4: Welcome
StarTech.com, will be responsible. Changes or modifications made to this equipment not expressly approved by StarTech.com could void the user's authority to operate the equipment.StarTech.com assumes no responsibility for any errors that appear in this document. Information in this document is subject to change without notice. -
Page 5: Introduction
Introduction With the UTP VGA Splitter system, broadcast your computer's VGA screen to four remote monitors simultaneously. Broadcast up to 250m/820ft using CAT5 UTP cables without loosing any picture quality. The UTP VGA Splitter system is compatible with VGA, SVGA, or XGA video standards The system components The UTP VGA Splitter system components include: •... - Page 6 The figure below illustrates the Central Unit 4-port model configuration. The configuration is the same for the 2-port model, except that there are only 2 Remote Units connected. P1 10 Optional keyboard, monitor & mouse TO REMOTE UNITS Central Unit POWER LOCAL MONITOR VIDEO IN...
-
Page 7: The Central Unit
The Central Unit The figure below illustrates the Central Unit front panel. BROADCASTER BROADCASTER CENTRAL UNIT SPLITTER SPLITTER SPLITTER The figure below illustrates the ports on the Central Unit 2 Port rear panel. Power connector TO REMOTE UNITS POWER LOCAL MONITOR VIDEO IN (optional) Screen... -
Page 8: The Remote Short Range Unit Ports
The figure below illustrates the ports on the Remote Long Range Unit rear panel. Power connector POWER PICTURE MONITOR TO CENTRAL UNIT Picture adjuster System cable Monitor’s Brightness to Central Unit cable adjuster The Remote Short Range Unit ports The figure below illustrates the ports on the Remote Short Range Unit rear panel. -
Page 9: The Cables
The cables The cables used in the UTP VGA Splitter system are illustrated below. Screen cable CAT5 UTP System cable Connecting the System cables The System cable consists of a single 4-pair CAT5 UTP cable, 2 x 4 x 24 AWG. The System cables connect the Remote Units to the Central Unit. -
Page 10: Connecting The Screen Cable
Connecting the Screen cable The Screen cable connects the Central Unit to the computer. To connect the Screen cable: 1. Connect the HDD15M connector to computer’s video card. 2. Connect the HDD15F connector to the Central Unit 's Video In port. Connecting monitors to the Remote Units To connect monitors to each Remote Unit: 1. - Page 11 The figure below illustrates the detailed connections of the UTP VGA Splitter system P 1 1 0 Optional keyboard, monitor & mouse TO REMOTE UNITS Central Unit POWER LOCAL MONITOR VIDEO IN Screen cable CAT5 cable CAT5 cable P 1 1 0 P1 1 0 POWER PICTURE...
-
Page 12: The Utp Video Splitter Remote Long Range Unit
The UTP Video Splitter Remote Long Range unit The figure below illustrates the underside panel of the Remote Long Range unit, with 4 sets of dipswitches. One set is not used. Not used... -
Page 13: The Dipswitches
The dipswitches The dipswitches are used for RGB compensation. All 3 sets of dipswitches must have the same settings. Set dipswitches 1 – 3 of each set according to the cable length, screen resolution and refresh rates. See the table below. Note! Dipswitch number 4 is not used. -
Page 14: Operating The Utp Vga Splitter System
Operating the UTP VGA Splitter system To prepare the system for operation: 1. Connect the system. 2. Switch on the computer, Central Unit, Remote Units and remote display monitors. The computer screen image broadcasts to all the Remote unit locations. Adjusting the screen picture When the picture sharpness on the remote screen needs adjusting, use a screwdriver to turn the Picture Adjuster knob on... -
Page 15: Technical Specifications
Technical Specifications Video output SVGA, VGA, XGA, or Monochrome System cable length With Remote Short Range 110m/360ft With Remote Long Range 250m/820ft Power adapters Central Unit 2/4 port – 2 x 9 VAC, 1A from AC/AC adapter Remote Long Range – 2 x 9 VAC, 1A from AC/AC adapter Remote Short Range –... -
Page 16: Technical Support
Limitation of Liability In no event shall the liability to StarTech.com Ltd. (or its officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive incidental, conse- quential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of related to the use of the product exceed the actual price paid for the product.
