User Manual of Network Video Recorder

4.2 PTZ Control Toolbar

In the Live View mode, you can press the PTZ Control button on the front panel or on the remote control, or
choose the PTZ Control icon
Icon Description
Direction button and
the auto-cycle button
The speed of the
PTZ movement
Previous item
Stop the patrol or
pattern movement
to enter the PTZ toolbar.
Figure 4. 11
Table 4. 1
Description of the PTZ toolbar icons
Icon
3D-Zoom
Patrol
PTZ Toolbar
Description
Zoom+, Focus+,
Iris+
Light on/off
Centralization
Pattern
Next item
Minimize
windows
57
Icon Description
Zoom-, Focus-, Iris-
Wiper on/off
Preset
Menu
Start pattern/patrol
Exit
