Settings Tab: General Settings
Change Picture Settings – This page allows the user to change the number of
pictures taken (default is 3) per motion event (1 to 10). It also allows you to
change the time between each photo (2 to 10 seconds). You can also adjust the
image resolution (3, 5 or 8 megapixels). Use the directional buttons to change
programming options and then push the OK button once the Save field is
highlighted. All programming options will be saved even after the camera is
turned off.
Change Video Settings – This programming option allow you to choose the
length of video (10, 20 or 30 seconds) as well as choose the video resolution
(720P-30 frames per second, 720P-60 frames per second or 1080P-30 frames
per second). Pushing the OK button once the Save field is highlighted at the
bottom of the screen will save your chosen options.
Adjust Motion Sensor – This screen allows you to turn the motion sensor On or
Off as well as adjusting the motion sensor's sensitivity levels (Low, Medium Low,
Medium, Medium High or High). It is highly recommended that you do not
change the sensitivity levels for most applications. Pushing the OK button once
the Save field is highlighted at the bottom of the screen will save your chosen
options.
Security Tab: Security Settings
Change CodeLoc Settings – CodeLoc™ allows the user to add a four-digit
security code to the camera to prevent unauthorized use in the event of
tampering or theft. Pushing the OK button once the Save field is highlighted at
the bottom of the screen will save your chosen code.
TIP: Remember to write your four-digit CodeLoc™ code on the last page of this
manual in case it is forgotten.
