1
Introduction

Chapter 1 - Introduction

Specifications

Processor
Front Side Bus
Chipset
System Memory
Expansion Slots
BIOS
Power Management
Hardware Monitor
Audio
LAN
10
® TM
• AMD Athlon 64 X2 / Athlon 64 FX / Athlon
• Socket AM2
• 2000MT/s HyperTransport interface
TM
• NVIDIA nForce4 Ultra (INFINITY NF ULTRA-M2)
TM
NVIDIA nForce4 (INFINITY NF-M2)
• Four 240-pin DDR2 DIMM sockets
• Supports DDR2 533 and DDR2 667 DIMMs
• Supports dual channel (128-bit wide) memory interface
• Supports up to 4GB system memory
• Supports unbuffered non-ECC x8 and x16 DIMMs
• 1 PCI Express x16 slot
• 2 PCI Express x1 slots
• 3 PCI slots
• Award BIOS
• 4Mbit flash memory
• ACPI and OS Directed Power Management
• ACPI STR (Suspend to RAM) function
• Wake-On-PS/2 Keyboard/Mouse
• Wake-On-USB Keyboard/Mouse
• Wake-On-LAN
• Wake-On-Ring
• RTC timer to power-on the system
• AC power failure recovery
• Monitors CPU/system/chipset temperature
• Monitors 12V/5V/3.3V/Vcore/Vbat/5Vsb/Vdimm/Vchip
voltages
• Monitors the speed of the cooling fans
• CPU Overheat Protection function monitors CPU temperature
during system boot-up
• Realtek ALC655 6-channel AC'97 audio CODEC
• True stereo line level outputs
• S/PDIF-in/out interface
• Realtek RTL8111 Gigabit PCIE LAN
• Fully compliant to IEEE 802.3 (10BASE-T), 802.3u (100BASE-
TX) and 802.3ab (1000BASE-T) standards
TM TM
64 / Sempron
