Generac Power Systems 00940-2 Owner's Manual And Installation Instructions page 51

ITEM PART NO.
1 078621
2 076389
3 088411
4 072657A
5 077176
6 088057
7 076390
8 083379A
10 089923
11 089213G
13 081695
14 090604
17 078699B
18 0A9878
19 089096
21 0A8822
22 078691
23 0A5772
24 0A5776
25 074908
26 078606
28 0D2414
30 0C3733
31 088401
32 088590
33 083152
34 076381
36 021705B
37 0C3590
38 0C3591
39 088396A
40 083235
42 0C8754
43 077161
44 077160
45 076307
46 088403
47 077168
48 088413B
49 078629
50 090388
51 083153
52 092977
53 084186
54 088156
58 072347
59 099922
Section 6 — Exploded Views and Parts Lists
IMPACT-36 plus II Recreational Vehicle Generator
GN 220 RV Long Block – Drawing No. 0A6202-F
QTY. DESCRIPTION
1 ASSEMBLY, CONNECTING ROD & CAP
1 PISTON PIN
1 PISTON RING SET (STD. SIZE)
2 PIPE PLUG - 1/4 NPT
1 COVER, BREATHER
1 PISTON, 75 DIA.
2 RETAINER, PISTON PIN
1 ASSEMBLY, CRANKSHAFT AND GEAR
1 SEPARATOR, OIL-BREATHER
1 ASSEMBLY, CRANKCASE
2 SEAL, OIL-CRANKSHAFT
1 CUP, BREATHER BAFFLE
3 SLEEVE, DOWEL DIA. 12
1 ASSEMBLY, CAMSHAFT
1 GASKET, CRANKCASE FLANGE
1 GASKET, CYLINDER HEAD
1 RETAINER, OIL PRESSURE SPRING
1 SPRING, OIL PRESSURE
1 BALL, OIL PRESSURE
1 TAPTITE, M5-0.8 X 10
4 SCREW & LOCKWASHER, M6-1.00 X 12MM
6 SCREW HHFC M8-1.25 X 35
2 RETAINER, VALVE SPRING
2 SPRING VALVE
1 DOWEL PIN, DIA. 12 X 18 LONG
1 GEROTOR, INNER
2 BOLT, CONNECTING ROD
1 ASSEMBLY, CYLINDER HEAD WITH GUIDES & SEATS
1 VALVE, EXHAUST
1 VALVE, INTAKE
2 PUSH ROD
2 TAPPET
1 GASKET, VALVE COVER
2 STUD, BALL PIVOT
2 ROCKER ARM
2 NUT, ROCKER ARM
1 PLATE, PUSH ROD GUIDE
5 HEADBOLT, M8 X 56MM
1 COVER, ROCKER
2 GASKET, BREATHER
2 BOLT, TAPTITE M6 X 12MM
1 GEROTOR, OUTER
1 ASSEMBLY - SUMP, OIL
2 WASHER, WEAR-VALVE SPRING
1 SEAL, VALVE-INTAKE
1 SPARK PLUG, CHAMPION RC12YC
1 WASHER, WAVE
Generac ® Power Systems, Inc. 49
