Label pos. 1
The label serves for unambiguous identification of the Mo-
bileXL charging- and docking station. It contains product
designation and serial number of the MobileXL charging-
and docking station.
Kensington port pos. 2
The Kensington port serves for connecting an anti-theft
device, protecting the MobileXL charging- and docking sta-
tion against theft by means of a lock and a wire rope.
Serial ports pos. 3
Via the serial ports you connect external devices to the
MobileXL charging- and docking station.
USB ports pos. 4
Via the USB ports you connect external devices and stor-
EN
age media to the MobileXL charging- and docking station.
Network port pos. 5
You can connect a network cable to the network port. The
orange LED is on when the MobileXL charging- and dock-
ing station is connected to an active network device. 'The
green LED flashes when data is transferred.
Cash drawer port pos. 6
To the cash drawer port you can connect up to two cash
drawers by means of a Y-cable.
Power supply pos. 7
The power cable plug of the Vectron PS30 is connected to
the power supply.
