JVC GET0624-003A Instructions Manual page 16

Category Menu item
VOL ADJUST
Volume adjust
(For KD-R412/
KD-R411/KD-R35)
L/O MODE *
Line output mode
SUB.W FREQ *
Subwoofer cutoff
frequency
SUB.W LEVEL *
Subwoofer level
BEEP
TEL MUTING
Telephone muting
AMP GAIN *
Amplifier gain
control
AM *
AM station
AUX IN *
Auxiliary input
11
* For KD-R412/KD-R411/KD-R312/KD-R311.
12
* Displayed only when <L/O MODE> is set to <SUB.W>.
13
* The volume level automatically changes to "VOLUME 30" if you change to <LOW POWER> with the
volume level is set higher than "VOLUME 30."
14
* Displayed only when any source other than "AM" is selected.
15
* Displayed only when any source other than "AUX IN" is selected.
16 ENGLISH
VOL ADJ –05 —
VOL ADJ +05
[ VOL ADJ 00 ]
11
• SUB.W
• REAR
11, 12
* • LOW
• MID
• HIGH
11, 12
* SUB.W 00 —
SUB.W 08
[ SUB.W 04 ]
• BEEP ON
• BEEP OFF
• MUTING 1/
MUTING 2
• MUTING OFF
13
• LOW POWER
• HIGH POWER
14
• AM ON
• AM OFF
15
• AUX ON
• AUX OFF
Selectable setting, [
: Preset the volume adjustment level of
each source (except FM), compared to the
FM volume level. The volume level will
automatically increase or decrease when
you change the source.
• Before making an adjustment, select the
source you want to adjust.
• "VOL ADJ FIX" appears on the display if
"FM" is selected as the source.
: Select if the REAR LINE OUT terminals are
used for connecting a subwoofer (through
an external amplifier).
: Select if the REAR LINE OUT terminals are
used for connecting the speakers (through
an external amplifier).
: Frequencies lower than 72 Hz are sent to the
subwoofer.
: Frequencies lower than 111 Hz are sent to
the subwoofer.
: Frequencies lower than 157 Hz are sent to
the subwoofer.
: Adjust the subwoofer output level.
: Activates the keypress tone.
: Deactivates the keypress tone.
: Select either one which mutes the sounds
while using a mobile phone.
: Cancels.
: VOLUME 00 – VOLUME 30 (Select if the
maximum power of each speaker is less than
50 W to prevent damaging the speakers.)
: VOLUME 00 – VOLUME 50
: Enable "AM" in source selection.
: Disable "AM" in source selection.
: Enable "AUX IN" in source selection.
: Disable "AUX IN" in source selection.
]
Initial: Underlined
