WINEGARD
®
RoadTrip
Mission
®
™
Automatic Satellite TV Antenna
Made in the U.S.A.
PRODUCT REGISTRATION
Serial No.
Please register your Winegard product by filling
out and returning the Product Registration card
provided or by completing the online registration
form at http://www.winegard.com/registration
Winegard Company • 3000 Kirkwood St. • Burlington, IA 52601-2000
800/788-4417 • FAX 319/758-5854 • www.winegard.com
Printed in U.S.A. © Winegard Company 2011 2452219
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RoadTrip Mission and is the answer not in the manual?

Questions and answers

Related Manuals for Winegard RoadTrip Mission

Summary of Contents for Winegard RoadTrip Mission

  • Page 1 Product Registration card provided or by completing the online registration form at http://www.winegard.com/registration Winegard Company • 3000 Kirkwood St. • Burlington, IA 52601-2000 800/788-4417 • FAX 319/758-5854 • www.winegard.com Printed in U.S.A. © Winegard Company 2011 2452219...
  • Page 2 Information provided in this manual was accurate at the time of printing. If the RoadTrip® Mission ™ does not function as expected, please contact Winegard Company at (800) 788-4417 or visit our website at www.winegard.com.
  • Page 3 This model is PRESET for DIRECTV receivers. ® If you have a receiver, you must change DISH Network BELL TV™ ® the numbered switches (see figures below). TO CHANGE SWITCH SETTINGS FOR DISH FACTORY PRESET NETWORK. SIMPLY MOVE #4 & #7 TO DOWN POSITION (#8 SHOULD REMAIN DOWN ALSO).
  • Page 4 4. After selecting location for unit (see Step 2), place the unit on the centerline of the vehicle. 1. Connect the quick disconnect power cable to the panel mount on the back of the RoadTrip Mission unit. 5. Position base so that cables exit toward the rear of vehicle.
  • Page 5 3. Turn the power switch on for the RoadTrip Mission antenna. 3. Connect the YELLOW flag connector to the The dish will detect if it is already on a satellite signal. If it switch.
  • Page 6 2. Turn on the RoadTrip Mission system and wait to the correct satellite. for the unit to acquire a signal on satellite 119°...
  • Page 7 Primary receiver is on or was last using. Note: The RoadTrip Mission antenna is designed to be maintenance free. However, it is a good idea to clean the dome from time to time with a soft cloth, water and dish soap.

  • Page 8: Troubleshooting

    119° and 129°. 1. Rain, snow or excessive dew on the dome can interrupt the The RoadTrip Mission antenna never sees any signal. Snow and dew can be brushed off the dome. If heavy rain signals, it just keeps searching.
  • Page 9 The antenna will locate and toggle between satellites 110°, 119° and 129°. The RoadTrip Mission antenna will not operate in areas where satellite 110°, 119° and 129° are not available. Refer to figure below for an operational coverage map for satellite 110° and 119°. Satellite coverage maps are based on level, stationary operation.
  • Page 10 Hybrid Mode is for use with DISH Network in the Northeast where the 129° satellite is not available. The map below shows the coverage area for DISH Network satellite 129°. (Dotted area indicates coverage). *Coverage maps are for reference only and do not guarantee coverage. DISH Network satellite 61.5°...
  • Page 11 Winegard recommends using a standard DIRECTV receiver. RoadTrip Mission antenna will operate in all areas where satellites 101° and 119° are available. Refer to the figures below for an operational coverage map of satellite 101° and 119°. Satellite coverage maps are based on level, stationary operation.
  • Page 12 If a defect in material or workmanship is discovered, Customer may take the product to an authorized Winegard dealer for service. Customer must provide proof of purchase to verify the product is under warranty. If the product is brought to an authorized Winegard dealer for service prior to expiration of year one (1) of the warranty period and a defect in material or workmanship is verified by Winegard Technical Services, Winegard Company will cover the Winegard dealer’s labor...
