Winegard RoadTrip SD Operation Manual
Digital satellite mobile antenna for two receivers
Hide thumbs
Also See for RoadTrip SD:
- Installation manual (9 pages) ,
- Operation manual (12 pages) ,
- Installation manual (9 pages)
Table of Contents
Advertisement
®
WINEGARD
RoadTrip
™
Digital Satellite Mobile Antenna for Two Receivers
RoadTrip SD - Stationary Satellite System
TM
RoadTrip SDi - In-Motion Satellite System
TM
OPERATION MANUAL
Made in the U.S.A. U.S. Patents Pending
Winegard Company • 3000 Kirkwood St. • Burlington, IA 52601-2000
APPLY SERIAL NUMBER
319/754-0600 • FAX 319/754-0787 • www.winegard.com
LABEL HERE
Printed in U.S.A. © Winegard Company 2006 2452085
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Winegard RoadTrip SD
Summary of Contents for Winegard RoadTrip SD
-
Page 1: Operation Manual
RoadTrip SD - Stationary Satellite System RoadTrip SDi - In-Motion Satellite System OPERATION MANUAL Made in the U.S.A. U.S. Patents Pending Winegard Company • 3000 Kirkwood St. • Burlington, IA 52601-2000 APPLY SERIAL NUMBER 319/754-0600 • FAX 319/754-0787 • www.winegard.com LABEL HERE... - Page 2 Introduction/How Does Digital Satellite TV Work? About this manual —We hope this manual will provide clear instructions to install and operate your Winegard mobile satellite system. Two symbols have been used — Indicates caution should be taken! Introduction Congratulations! You have purchased one of Winegard’s latest developments in the mobile satel-...
-
Page 3: Changing Numbered Switches
RoadTrip SDi In-Motion system, to be set for the proper installation option. Simply set the switch, and forget it! Your Winegard RoadTrip Satellite Antenna will locate the proper satellite with just the flip of a switch. - Page 4 Operation RoadTrip SD (VEHICLE MUST BE STATIONARY!!) 1. Turn on receiver and television set. The RoadTrip must be connected to a receiver that ™ is plugged into 120 VAC. 2. Verify that you are getting the receiver’s menu screens on the television. These screens are avail- able with or without the dish finding the signal.
- Page 5 Operation RoadTrip SDi (In-Motion System) 1. Turn on receiver and television set. The RoadTrip must be connected to a receiver ™ that is plugged into 120 VAC. 2. Verify that you are getting the receiver’s menu screens on the television. These screens are available with or without the dish finding the signal.
- Page 6 ™ Input: Satellite: Polarity: Status: NOTE: Be sure the “Superdish” and “Alternate” boxes ARE NOT checked. Toggle: Your Winegard automatic satellite dish will move from the primary to the alternate satellite in order to receive multi-satellite programming. Install Summary SW42...
-
Page 7: Troubleshooting
PROBLEM The RoadTrip does not attempt to find a satellite or it never moves. The dish never stops on any of the signals that it sees. With DIRECTV, the dish will find the alternate satellite but it never finds the primary satellite. I am not getting all the DISH Network channels I subscribed to. - Page 8 The antenna will locate and continually track both satellites 119° and 110°. Winegard does not recommend using receivers with hard drives not recommended by the manufactuer for mobile applications. Winegard recommends using a stan- dard DISH Network receiver. The RoadTrip will not operate in areas where satellite 119° and 110° is not avaliable.
- Page 9 The RoadTrip™SD and™SDi will operate with most DIRECTV receivers. The antenna will locate and con- tinually track satellites 101° and 119°. Winegard does not recommend using satellite receivers with hard drives not recommended by the manufacturer for mobile applications. Winegard recommends using a standard DIRECTV receiver.
- Page 10 Notes...
- Page 11 Notes...
- Page 12 If a defect in material or workmanship is discovered, Customer may take the product to an authorized Winegard dealer for service. Customer must provide proof of purchase to verify the product is under warranty. If the product is brought to an authorized Winegard dealer for service prior to expiration of year one (1) of the warranty period and a defect in material or workmanship is verified by Winegard Technical Services, Winegard Company will cover the Winegard dealer’s labor charges for warranty service.
