1 1 . . 0 0 I I N N T T R R O O D D U U C C T T I I O O N N
1 1 . . 3 3 L L E E G G I I S S L L A A T T I I O O N N
T T h h e e a a p p p p l l i i a a n n c c e e i i s s s s u u i i t t a a b b l l e e o o n n l l y y f f o o r r i i n n s s t t a a l l l l a a t t i i o o n n i i n n G G B B a a n n d d I I E E a a n n d d
s s h h o o u u l l d d b b e e i i n n s s t t a a l l l l e e d d i i n n a a c c c c o o r r d d a a n n c c e e w w i i t t h h t t h h e e r r u u l l e e s s i i n n f f o o r r c c e e , , a a n n d d
o o n n l l y y u u s s e e d d i i n n a a s s u u i i t t a a b b l l y y v v e e n n t t i i l l a a t t e e d d l l o o c c a a t t i i o o n n . .
In GB, the installation must be carried out by a CORGI
Registered Installer. It must be carried out in accordance with
the relevant requirements of the:
• Gas Safety (Installation & Use) Regulations.
• The appropriate Building Regulations either The Building
regulations, The Building Regulations (Scotland), Building
Regulations (Northern Ireland).
• The Water Fittings Regulations or Water Byelaws in
Scotland.
• The Current I.E.E. Wiring Regulations.
Where no specific instructions are given, reference should be
made to the relevant British Standard Code of Practice.
In IE, the installation must be carried out by a competent
Person and installed in accordance with the current edition of
I.S. 813 'Domestic Gas Installations', the current Building
Regulations and reference should be made to the current ETCI
rules for electrical installation.
A A l l l l s s y y s s t t e e m m s s m m u u s s t t b b e e t t h h o o r r o o u u g g h h l l y y f f l l u u s s h h e e d d a a n n d d t t r r e e a a t t e e d d w w i i t t h h
i i n n h h i i b b i i t t o o r r ( ( s s e e e e s s e e c c t t i i o o n n 6 6 . . 2 2 ) ) . .
C C o o d d e e s s o o f f P P r r a a c c t t i i c c e e - - r r e e f f e e r r t t o o t t h h e e m m o o s s t t r r e e c c e e n n t t v v e e r r s s i i o o n n
I I n n G G B B t t h h e e f f o o l l l l o o w w i i n n g g C C o o d d e e s s o o f f P P r r a a c c t t i i c c e e a a p p p p l l y y : :
S S t t a a n n d d a a r r d d S S c c o o p p e e
BS 7967 Carbon monoxide in dwellings and the
combustion performance of gas fired appliances
BS 7967-2 Guide for using electronic portable combustion
gas analysers in the measurement of carbon
monoxide and the determination of combustion
performance
BS 7967-3 Guide for responding to measurements obtained
from electronic portable combustion gas
analysers
BS 7967-4 Guide for using electronic portable combustion
gas analysers as part of the process of servicing
and maintenance of gas fired appliances
BS 6891 Gas installation
BS 5546 Installation of hot water supplies for domestic
purposes
BS 5449 Forced circulation hot water systems
BS 6798 Installation of gas fired hot water boilers
BS 5440 Part 1 Flues
BS 5440 Part 2 Ventilation
BS 7074 Expansion vessels and ancillary equipment
for sealed water systems
BS 7593 Treatment of water in domestic hot water
central heating systems
I I n n I I E E t t h h e e f f o o l l l l o o w w i i n n g g C C o o d d e e s s o o f f P P r r a a c c t t i i c c e e a a p p p p l l y y : :
S S t t a a n n d d a a r r d d S S c c o o p p e e
I.S. 813 Domestic Gas Installation
The following standards give valuable additional information;
BS 5546 Installation of hot water supplies for domestic
purposes
BS 5449 Forced circulation hot water systems
BS 7074 Expansion vessels and ancillary equipment
for sealed water systems
BS 7593 Treatment of water in domestic hot water
central heating systems
G G A A S S L L E E A A K K S S
D D O O N N O O T T O O P P E E R R A A T T E E A A N N Y Y E E L L E E C C T T R R I I C C A A L L S S W W I I T T C C H H E E S S , , O O R R U U S S E E A A
N N A A K K E E D D F F L L A A M M E E . . T T U U R R N N O O F F F F T T H H E E G G A A S S S S U U P P P P L L Y Y . . V V E E N N T T I I L L A A T T E E T T H H E E
A A R R E E A A B B Y Y O O P P E E N N I I N N G G D D O O O O R R S S A A N N D D W W I I N N D D O O W W S S . . C C A A L L L L O O U U T T Y Y O O U U R R
L L O O C C A A L L G G A A S S S S U U P P P P L L I I E E R R
T T E E L L : : 0 0 8 8 0 0 0 0 1 1 1 1 1 1 9 9 9 9 9 9
C C o o n n t t r r o o l l o o f f S S u u b b s s t t a a n n c c e e s s H H a a z z a a r r d d o o u u s s t t o o H H e e a a l l t t h h
Under Section 6 of the Health and Safety at Work Act 1974, it
is required to provide information on substances hazardous to
health.
The adhesives and sealants used in this appliance are cured and
give no known hazard in this state.
Insulation Pads - These can cause irritation to skin, eye and
respiratory tract. If you have a history of skin complaint you
may be susceptible to irritation. High dust levels are usual only
if the material is broken. Normal handling should not cause
discomfort, but follow normal good hygiene and wash your
hands before eating, drinking or going to the lavatory. If you do
suffer irritation to the eyes or severe irritation to the skin seek
medical attention.
G G a a s s a a n n d d E E l l e e c c t t r r i i c c i i t t y y C C o o n n s s u u m m e e r r C C o o u u n n c c i i l l ( ( E E n n e e r r g g y y w w a a t t c c h h ) )
Energywatch is an independent organisation, which protects
the interests of gas users. If you need advice concerning
energy issues, they may be contacted on their consumer help
line number: 08459 060708, or via their website;
www.energywatch.org.uk.
This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been
given supervision or instructions concerning use of the
appliance by a person responsible for their safety. Children
should be supervised to ensure that they do not play with the
appliance.
5 5
