Dimplex System 18 Installation And Servicing Instructions page 10

5 5 . . 0 0 D D I I M M E E N N S S I I O O N N S S
F F i i g g . . 4 4
Tube Ø 100mm
264mm 182mm 185mm 148mm
150mm
94mm
796mm
446mm 333mm
F F i i g g . . 5 5
Tap Rail
125mm 125mm
10mm
Condensate CH Flow Gas Inlet CH Return
Drain (22mm) (22mm) (22mm)
1 1 0 0
© Dimplex Boilers 2008
