Summary of Contents for Daikin FXHQ32MVE

  • Page 1: Installation Manual

    INSTALLATION MANUAL English SYSTEM Inverter Air Conditioners Deutsch MODELS Français Ceiling suspended type FXHQ32MVE FXHQ32MAVE FXHQ63MVE FXHQ63MAVE Español FXHQ100MVE FXHQ100MAVE Italiano READ THESE INSTRUCTIONS CAREFULLY BEFORE INSTALLATION. KEEP THIS MANUAL IN A HANDY PLACE FOR FUTURE REFERENCE. ÅëëçíéêÜ LESEN SIE DIESE ANWEISUNGEN VOR DER INSTALLATION SORGFÄLTIG DURCH.
  • Page 2 3P109591-1E...
  • Page 3: Table Of Contents

    VRV SYSTEM Inverter Air Conditioners Installation manual CONTENTS • Install the air conditioner on a foundation strong enough to withstand the weight of the unit. 1. SAFETY CONSIDERATIONS ......... 1 A foundation of insufficient strength may result in the equip- 2.
  • Page 4: Before Installation

    (b) where corrosive gas, such as sulfurous acid gas, is pro- ACCESSORIES duced Check the following accessories are included with your Corroding copper pipes or soldered parts may result in unit. refrigerant leakage. (c) near machinery emitting electromagnetic waves Name (1) Drain hose (2) Metal clamp Electromagnetic waves may disturb the operation of the...
  • Page 5: Selecting Installation Site

    SELECTING INSTALLATION SITE FOR THE FOLLOWING ITEMS, TAKE SPECIAL CARE DURING CONSTRUCTION AND CHECK (1) Select an installation site where the following condi- AFTER INSTALLATION IS FINISHED. tions are fulfilled and that meets your customer’s approval. a. Items to be checked after completion of work •...
  • Page 6: Preparations Before Installation

    PREPARATIONS BEFORE INSTALLA- TION (1) Relative positions of indoor unit, suspension bolt, pip- ing hole, drain piping hole, and electric wire hole posi- tion. (Refer to Fig. 2) Front view Fig. 4 Left side piping hole Rear side piping hole 100 ) 2) Detach the dressing boards (left and right).
  • Page 7: Indoor Unit Installation

    4) Set the suspension bolt. (Use W3/8 or M8-M10 size sus- (5) When hanging the indoor unit main body, be sure to pension bolts.) use a level or a plastic tube with water in it to make sure • Adjust the distance from the unit to the ceiling slab the drain piping is set either level or slightly tilted, in beforehand.
  • Page 8 (1) In case of backward piping Top penetration • Remove the rear cover for piping. (Refer to Fig. 12, 14) lid cramp section Thermistor lead line (2) In case of upward piping Clamp • In case of upward piping,optional L-shape piping kit is required.
  • Page 9: Drain Piping Work

    Use “ Table 2 ” as a reference if a torque wrench is not available. NOTE NOTE NOTE NOTE Once work is complete, make sure there is no gas leaking. As The flare nuts used must be those included with the main the flare nut is tightened with the wrench, the torque will sud- body.
  • Page 10: Electric Wiring Work

    • For left drain pipe outlet, remove the rubber plug and the NOTE NOTE NOTE NOTE insulation on the drain pipe connecting opening on the • To ensure no excessive pressure is applied to the included left side of the unit and change the position to the right drain hose (1), do not bend or twist when installing.
  • Page 11: Wiring Example And How To Set The Remote Controller

    WIRING EXAMPLE AND HOW TO SET • This system consists of multiple indoor units. Mark each indoor unit as unit A, unit B..., and be sure the terminal board THE REMOTE CONTROLLER wiring to the outdoor unit and BS unit are properly matched. If wiring and piping between the outdoor unit and an indoor HOW TO CONNECT WIRINGS unit are mismatched, the system may cause a malfunction.
  • Page 12 7. Use only specified wire and tightly connect wires to termi- CAUTION nals. Be careful wires do not place external stress on termi- • Be sure to attach the sealing material or putty (field supplied) nals. Keep wiring in neat order and so as not to obstruct to hole of wiring to prevent the infiltration of water as well as other equipment such as popping open the electric parts any insects and other small creatures from outside.
  • Page 13 When including BS unit (2) Turn the MAIN/SUB changeover switch on one of the two remote controller PC boards to “S”. (Leave the switch of the Power Power Outdoor unit supply supply other remote controller set to “M”.) 220-240V 220-240V Control box IN/D OUT/D 50Hz...
  • Page 14: Installation Of The Suction Grille And The Air Filter

    10. INSTALLATION OF THE SUCTION • When in the field set mode, select mode No. 12, then set the first code (switch) No. to “1”. Then set second code GRILLE AND THE AIR FILTER (position) No. to “01” for FORCED OFF and “02” for ON/ Install side panel and suction grille properly in the order oppo- OFF OPERATION.
  • Page 15 3P172532-7 EM02A086B (0602) HT...

This manual is also suitable for:
