2. Introduction to the manual

2.1.

Objective of the manual

This manual provides an overview of the hardware and software features of the @MAXX lite
(contact smartcard reader, mass storage, RF-antenna) reader, hereafter referred to as
"@MAXX lite".
This manual describes in details interfaces and supported commands available for developers
using @MAXX lite in their applications.
2.2.

Target audience

This document describes the technical implementation of @MAXX lite.
The manual targets software developers.
Should you have questions, you may send them to
2.3.

Product version corresponding to the manual

Item
Hardware
Firmware (SIM)
Windows Driver
(PC/SC)
MAC OS Driver
(PC/SC)
WinCE Driver for
SIM interface
Linux Driver for
SIM Interface
2.4.

Definition of various terms and acronyms

Term Expansion
APDU Application Protocol Data Unit
ATR Answer to Reset, defined in ISO/IEC 7816
ATS Answer to select, defined in ISO/IEC 14443
Byte Group of 8 bits
CCID Chip Card Interface Device
CID Card Identifier
CL Contactless
DFU Device Firmware Upgrade
DR Divider receive: used to determine the baud rate between the reader to the card
DS Divider send: used to determine the baud rate between the card to the reader
LED Light emitting diode
MIFARE is the NXP Semiconductors (a spin-off company formed out of Philips Semiconductors)-
owned trademark of the reputedly most widely installed contactless smartcard
NA Not applicable
NAD Node Address
Nibble Group of 4 bits. 1 digit of the hexadecimal representation of a byte.
Example: 0xA3 is represented in binary as (10100011)b. The least significant nibble is 0x3
or (0011)b and the most significant nibble is 0xA or (1010)b
M
ANUAL
Version
SD-03-M-Ver-F
2.02
4.41
5.0.6
3.14
5.0.2
support@scmmicro.com
