@MAXX
R
LITE
EFERENCE
6.1.13.
This function code shall be used to set and get the character / block guard time of the reader.
The guard time is specified in terms of etus.
The buffer shall point to the escape code followed by the guard time structure.
typedef struct _GUARD_TIME
{
uint8
byGetSetIdentifier;
uint8
byGuardTimeIdentifier;
uint32 dwGuardTime;
} GUARD_TIME;
6.1.14.
This function code shall be used to set and get the extra guard time of the reader. The guard
time is specified in terms of etus.
The buffer shall point to the escape code followed by a structure given below.
typedef struct _EGT
{
uint8
byGetSetIdentifier;
uint32 dwEGT;
} EGT;
6.1.15.
This function is used to change the delay (in ms) between the power-up attempts in the class-
A, class-B, and class-C sequence;
The buffer shall point to the escape code followed by a BYTE containing the timeout value.
6.1.16.
This function code shall be used to change the VCC level for the reader. The input buffer shall
point to the escape code followed by a WORD containing VCC value. The ICC will be reset to
the value given in the buffer.
The supported smart card voltages are:
#define Vcc_AUTOMATIC
#define Vcc_5V
#define Vcc_3V
#define Vcc_1_8V
M
ANUAL

CCID_ESC_GET_SET_GUARDTIME

CCID_ESC_GET_SET_EGT

CCID_ESC_GET_SET_ATR_TIMEOUT

CCID_ESC_POWER

0x00
0x01
0x02
0x03
28
