3. General information about @MAXX lite

3.1.

@MAXX lite key benefits

The @MAXX lite is an all-in-one device and belongs to SCM's @MAXX token family. Designed
as a USB-stick the @MAXX lite is portable and can be connected to stationary PCs as well as
Laptops. In addition to the normal smartcard reader the internal RF antenna converts the
normal USB-stick together with a dual interface smartcard to a portable mobile passive NFC
token. The typical application field of the @MAXX lite is the combination of physical and logical
access within one device.
3.2.

@MAXX lite key features

•
8-pin, ISO7816 compliant contact smart card reader for ID-000 smartcards
PC/SC v2.0 compliant
o
CCID compatible
o
•
Unique serial number for the Mass Storage interface
•
Can be plugged into any USB slot on a PC without having to re-install the driver.
•
embedded flash memory 2GB (other capacities on request)
•
internal passive RF-antenna connected to C4/C8 of the smartcard connector
3.3.

@MAXX lite ordering information

Item
@MAXX lite
Contact SDK
3.4.

@MAXX lite customization options

Upon request, SCM can customize:
•
The color of the casing
•
The logo
•
The product label
•
The USB strings for the Mass Storage Device
•
Flash memory capacity
Terms and conditions apply, please contact your local SCM representative or send an email to
sales@scmmicro.com.
M
ANUAL
Part number
905110
905129 SDK for Contact SmartCard
10
