SCM Microsystems @MAXX lite Reference Manual page 23

@MAXX R
LITE EFERENCE
5.4.1.3.1.
This error code is returned when a hardware short circuit condition is detected, during
application of power to the card or if any other internal hardware error is detected. This error
code has been defined in the error code table 6.2-2 of the CCID specification.
5.4.1.3.2.
This error code is returned when the card does not respond until the reader time out occurs.
This error will be reported in the response to PC_to_RDR_XfrBlock message and
PC_to_RDR_IccPowerOn messages. This error code has been defined in the error code table
6.2-2 of the CCID specification.
M
ANUAL
HW_ERROR
ICC_MUTE
23
