6.1.10.
In case when an application wants to change the clock frequency, this escape ID is used to
inform the reader about the change in clock. The first byte of the input buffer will contain the
escape function value; the next byte will contain the clock divisor value. The output buffer field
shall be NULL.
The possible clock divisor values and hence the clock frequency is given in the table below
CLOCK DIVISOR
VALUE
6.1.11.
This function code shall be used by the reader to get and set the current ETU. The ETU is
specified in terms of smart card clock cycles.
The input buffer shall point to the escape code followed by a DWORD specifying the value to
be set. The output buffer shall point to NULL.
6.1.12.
This function code shall be used to set and get the character / block waiting time of the reader.
The wait time is specified in terms of smart card clock cycles.
The buffer shall point to the escape code followed by the wait time structure.
typedef struct _WAIT_TIME
{
uint8 byGetSetIdentifier;
uint8 byWaitTimeIdentifier;
uint32 dwWaitTime;
} WAIT_TIME;
M
ANUAL

CCID_ESC_CLK_FREQUENCY

CLK FREQUENCY (in MHz)
USB
6 4
4 6
3 8
2 12

CCID_ESC_GET_SET_ETU

CCID_ESC_GET_SET_WAITTIME

RS232
3.686
5.53
7.37
11.06
