Page 1: Model Numbers & Company Address
50 lb. Sectionalized Shipboard Laundry Dryer Models L36TD30ME, L36TD30MS (NSN: 3H 3510-01-340-9419) (NSN: 3H 3510-01-312-4422) 440V. A.C. 60 CYCLE 3 PHASE T E C H N I C A L M A N U A L INSTALLATION O P E R A T I O N... -
Page 2: Important Notices
S6162-BS-MMC-010/12489 IMPORTANT NOTICES—PLEASE READ For optimum efficiency and safety, we recommend that you read the Manual before operating the equipment. Store this manual in a file or binder and keep for future reference. WARNING: For your safety, the information in this manual must be followed to minimize the risk of fire or explosion or to prevent property damage, personal injury, or loss of life. - Page 3 WARNING: Alterations to equipment may not be carried out without consulting with the factory and only by a qualified engineer or technician. Only Cissell parts may be used. WARNING: Remove clothes from dryer as soon as it stops. This keeps wrinkles from setting in and reduces the possibility of spontaneous combustion.
-
Page 4: Dryer Warranty
(90) days from date of sale. The warranty period on each new replacement part furnished by Cissell in fulfillment of the warranty on new equipment or parts shall be for the unexpired portion of the original warranty period on the part replaced. -
Page 5: Table Of Contents
S6162-BS-MMC-010/12489 TABLE CONTENTS 50 LB. SECTIONALIZED SHIPBOARD LAUNDRY DRYER P A G E Model Numbers & Company Address ............1 Important Notices ..............2-3 Dryer Warranty ................ 4 Table of Contents ..............5 Warnings, Cautionary Notes and Symbols ..........6-7 Front View of Dryer .............. -
Page 6: Warnings, Cautionary Notes And Symbols
S6162-BS-MMC-010/12489 S Y M B O L S The following symbols are used in this manual and/or on the machine. The numbers between () refer to the numbers on the machine surveys. Symbol Description Part/Measurement N O T E ! Hot! Do Not Touch Heiß! Nicht Beruhren Haute temperature! Ne pas... - Page 7 S6162-BS-MMC-010/12489 S Y M B O L S Symbol Description Part/Measurement rotation in two directions rotation dans les deux sens Drehbewigung in zwei Richtungen movimiento rotativo en los dos sentidos direction of rotation sens de mouvement continu de rotation Drehbewegung in Pfeilrichtung movimiento giratorio o rotatorio en el sentido de la flecha End of Cycle...
-
Page 8: Front View Of Dryer
S6162-BS-MMC-010/12489 ELECTRIC STEAM HEATED DRYERS FRONT VIEW Ref. No. Part No. Description TU10528 Thermometer for Basket Temp. PT111 Start Button TU5004 Temperature Range Selector FG147 On/Off Power Switch TU5421 Cool-Down Cycle Lamp TU5421 Drying Cycle Lamp TU4862 Drying Cycle Timer TU10521 Lint Trap Access Door TU5261... -
Page 9: Rear View Of Dryer
S6162-BS-MMC-010/12489 ELECTRIC STEAM HEATED DRYERS REAR VIEW Ref. No. PART Description MTR302 Fan Motor MTR302 Basket Motor TM100 Gear Reducer TU11812 Control Box Assembly Steam TU11850 Heating Unit, Electric Exhaust Vent TU10646 Fuses Power Input Disconnect Box TU10917 Cover,Housing TU10916 Housing TU10453 Control Box Assembly Electric... -
Page 10: Dimensions
S6162-BS-MMC-010/12489 Page 10... -
Page 11: Specifications
S6162-BS-MMC-010/12489 ELECTRIC HEATED L 3 6 T D 3 0 M E Heat Capacity ......3 6 K W Net Weight (approx.) ...... 790 lbs. Domestic Shipping ......1050 lbs. Weight (carton approx.) Export Shipping ......1200 lbs. (1 box approx.) Export Shipping Dimensions .... - Page 12 S6162-BS-MMC-010/12489 B R E A K D O W N P R O C E D U R E If the tumbler dryer is installed aboard ship, disconnect the electrical power leads and steam connections going to the dryer before proceeding further. NOTE: All wiring is to be left in place unless otherwise noted.
- Page 13 S6162-BS-MMC-010/12489 BREAK DOWN PROCEDURE (Continued) Go to rear of dryer and remove top cover (10) (Electric Dryer Only) by unscrewing 2 hex head bolts, then lift top up and pull top to rear of dryer and remove. Now you are ready for dismantling the dryer. Unscrew twenty-eight 1/4”...
-
Page 14: Break Down Procedure
S6162-BS-MMC-010/12489 BREAK DOWN PROCEDURE (Continued) Go to the rear of dryer and unscrew fourteen 3/8” nuts holding rear channel, motor and gear reducer assembly (12) to the dryer. 1 0 . You can remove either the right section (13) or left section (14) next. Going to front of dryer, unscrew sixteen 1/4”... -
Page 15: General Installation
GENERAL INSTALLATIONS The construction of Cissell Cabinet Dryers permits installation side by side to save space or to provide a wall arrangement. Position dryer for the least amount of exhaust piping and elbows, and allow free access to the rear of dryer for future servicing of belts, pulleys, and motor. -
Page 16: Exhaust Duct Information
S6162-BS-MMC-010/12489 EXHAUST DUCT INFORMATION For Exhaust Duct less than 14 feet and 2 elbows equivalent and less than 0.3 inches static pressure. DRYER EXHAUSTS Area of section “A-A” must be equal to the sum of dryer exhaust pipes entering multiple exhaust pipe. ( See chart below. ) MODELS: L28FD30, L28US30, L36FD30, L36UR30, L36CD36, L44FD42 No. -
Page 17: Dryer Installation With Multiple Exhaust
S6162-BS-MMC-010/12489 DRYER INSTALLATION WITH MULTIPLE EXHAUST For Exhaust Duct more than 14 feet and 2 elbows equivalent and more than 0.3 inches static pressure. (See illustration on next page.) 1 . Make-up air from outside building may enter enclosure from top or side walls. Area of opening should be equal to 4 to 6 times the sum of dryer duct areas. -
Page 18: Dryer Installation With Separate Exhaust
S6162-BS-MMC-010/12489 DRYER INSTALLATION WITH SEPARATE EXHAUST ( P R E F E R R E D ) For ductwork less than 14 feet and 2 elbows equivalent and less than 0.3 inches static pressure: NEVER exhaust the dryer into a chimney. NEVER install wire mesh screen over the exhaust or make-up air area. -
Page 19: Dryer Air Flow Installation
S6162-BS-MMC-010/12489 DRYER FLOW INSTALLATION Nothing is more important than air flow for the proper operation of a clothes dryer. A dryer is a pump which draws make-up air from the out-of-doors, through the heater, through the clothes and then forces the air through the exhaust duct back to the out-of-doors. Just as in a fluid water pump, there must be a fluid air flow to the inlet of the dryer, if there is to be the proper fluid air flow out of the exhaust duct. -
Page 20: Steam Piping Installation Instructions
S6162-BS-MMC-010/12489 RECOMMENDED STEAM PIPING INSTALLATION ILLUSTRATION Page 20... -
Page 21: Operating Instructions
S6162-BS-MMC-010/12489 OPERATING INSTRUCTIONS Step 1. After loading the dryer tumbler with the washed clothes load, proceed to close the loading door. Step 2. Timer Models - Turn drying timer knob to the desired drying time. Step 3. Temperature Selector - Select temperature per type of load being dried in the dryer. -
Page 22: Troubleshooting Chart
S6162-BS-MMC-010/12489 Troubleshooting Chart T R O U B L E C A U S E R E M E D Y Motor will not start. Motor overloads Reset Overload Relay. open. Defective Bonnet Replace thermostat (Elec. models only) Hi-H Limit. No power. - Page 23 S6162-BS-MMC-010/12489 Troubleshooting Chart T R O U B L E C A U S E R E M E D Y Dryer runs, no steam to Solenoid valve. On dryers using solenoid temperature control, c o i l s . check operation of solenoid valve by advancing thermostat.
- Page 24 S6162-BS-MMC-010/12489 Troubleshooting Chart T R O U B L E C A U S E R E M E D Y Basket motor runs, but V-Belt broken. Replace V-Belt. basket will not revolve. V-Belt loose. Adjust belt tension. Motor pulley loose. Tighten set screw.
- Page 25 S6162-BS-MMC-010/12489 Troubleshooting Chart T R O U B L E C A U S E R E M E D Y Dryer runs, but no heat. Incorrect voltage. Check for correct control voltage - 120V. No voltage. Check power supply, check secondary voltage on transformer and check wiring and wiring diagram.
-
Page 26: Air Switch Adjustment
S6162-BS-MMC-010/12489 SWITCH ADJUSTMENT ELECTRIC ONLY 1 . Shut off current; disconnect leads and remove air switch. 2 . Lay air switch assembly on flat surface. Adjust air blade at “A” (Fig. 1) so that air blade lays flat and surface “B” is parallel to the flat surface. 3 . - Page 27 Gear Reducer case. EACH GEAR REDUCER is filled with 5 pints of Cissell TU3465 transmission oil before leav- ing the factory. Change oil once every 6 months.
-
Page 28: Gear Reducer Information
REDUCER SEALS NOTE: On original equipment, the Cissell Gear Reducer is equipped with a Garlock Shaft Seal. If this seal requires replacement, it cannot be replaced with the same type of seal since the original seal would have seated in on the shaft. It must be replaced with a TU2166. -
Page 29: Instructions For Dryers With Reversing Control
S6162-BS-MMC-010/12489 INSTRUCTIONS DRYERS WITH REVERSING CONTROL I M P O R T A N T Tumbler Basket must stop completely for 3 to 5 seconds between reversals. In operation, coasting of basket increases, making it necessary to readjust Reversing Timer. Failure to do this will cause the thermal overload units for the basket to cut-out unnecessarily... -
Page 30: Aligning Basket
S6162-BS-MMC-010/12489 INSTRUCTIONS FOR ALIGNING BASKET ON CISSELL 50 LB. DRYER - D O U B L E M O T O R 1 . Loosen the 4 gear reducer mounting bolts (1, 2, 3 & 4) on rear of dryer, and 2 adjusting bolts #5, on gear reducer housing (Fig. -
Page 31: Basket & Spider Assembly
S6162-BS-MMC-010/12489 BASKET AND SPIDER ASSEMBLY - TU10460 Ref. No. Part No. Description Quantity TU2831 1/2” Heavy Lockwasher TU2882 1/2” - 20 x 3/4” Hex Nut TU5887 TU3536 #1 - 14 x 1-1/2” F Hex Jam Nut TU3537 #1 - 14 x 1-1/2” F Hex Nut TU2493 2 - 1/8 x 1 Washer TU108... -
Page 32: Overall Assemblies
S6162-BS-MMC-010/12489 OVERALL ASSEMBLIES Ref. No. Part No. Description Quantity TU11717 Bottom Bolted Section TU11718 Right Center Bolted Section “Electric” TU11818 Right Center Bolted Section “Steam” TU11719 Left Center Bolted Section TU11720 Top Bolted Section, Electric TU11721 Top Bolted Section, Steam TU10600 Back Channel Bolted Section TU11766... - Page 33 S6162-BS-MMC-010/12489 OVERALL ASSEMBLIES Ref. No. Part No. Description Quantity TU10481 Access Door Assembly TU10651 Mechanism Box Cover FB187 #10 Lockwasher TU10580 Mechanism Box Door Assembly TU10577 Top Jacket Weldment TU2372 7/8” Heyco Bushing TU819905 Fuse, 5 Amp, 600 Volt VSB134 Lockwasher TU11207 Disconnect Box, 30 Amp...
-
Page 34: Top Bolted Assembly
S6162-BS-MMC-010/12489 TOP BOLTED SECTION, ELECTRIC - TU11720 Ref. No. Part No. Description Quantity TU10791 Solid Top TU10577 Top Jacket P104 1/4” Cut Washer FB187 #10 Lockwasher TU2842 #10 - 32 Hex Nut TU3479 #10 - 32 x 7/16” Screw TU11903 Front Guard TU2847 1/4”... -
Page 35: Left Center Bolted Section
S6162-BS-MMC-010/12489 LEFT CENTER BOLTED SECTION - TU11719 Ref. No. Part No. Description Quantity SC633 Rivet M271 #8 Washer AT383 #8 - 32 x 1/2” Screw TU10528 Thermometer Assembly* TU10574 Left Center Jacket TU2372 Heyco Bushing * - See Separate Page Page 35... -
Page 36: Right Center Bolted Section
S6162-BS-MMC-010/12489 RIGHT CENTER BOLTED SECTION STEAM - TU11818 ELECTRIC - TU11718 Ref. No. Part No. Description Quantity TU10573 Right Center Jacket W/A TU10591 Control Box Cover Assembly SV80 1/4” - 20 x 3/8” Hex Head Bolt TU2846 1/4” Lockwasher TU8206 Air Switch Assembly - (Electric Only) TU5507 Cover Plate (Steam Only)#8 - 32 x 3/8”... -
Page 37: Access Door & Control Panel Assembly
15/32” - 32 Lock Nut ET208 #6 - 32 x 1/4” Screw TU3198 Cover Plate TU3164 Knob TU10478 Mechanism Box Door TU8013 Cissell Nameplate TU8014 Therm-O-Cool Nameplate TU8418 On - Off Label TU10603 Push to Start Label TU8599 Relay TU3624 #6 - 32 x 1/4”... -
Page 38: Thermometer Assembly
S6162-BS-MMC-010/12489 THERMOMETER ASSEMBLY TU10528 Ref. No. Part No. Description Quantity TU3593 Thermometer TU2641 Thermometer Gasket TU6766 Mounting Plate SC153 Spacer FB187 #8 Lockwasher 601367512 #8 - 32 x 1 Truss Head Screw M262 #8 - 32 x 3/8” Truss Head Screw C257 Clamp TU10527... -
Page 39: Bottom Bolted Assembly
S6162-BS-MMC-010/12489 BOTTOM BOLTED ASSEMBLY TU11717 Ref. No. Part No. Description Quantity TU10521 Lint Door Assembly* TU5261 Lint Screen TU10457 Lint Trap Frame TU10572 Bottom Jacket TU3206 Lock Plate TU2846 1/4” Lockwasher SV80 1/4” - 20 x 3/8” Hex Head Bolt TU10575 Fan Assembly TU4787... -
Page 40: Back Channel Bolted Assembly
S6162-BS-MMC-010/12489 BACK CHANNEL BOLTED ASSEMBLY TU10600 Page 40... - Page 41 S6162-BS-MMC-010/12489 BACK CHANNEL BOLTED ASSEMBLY TU10600 Ref. No. Part No. Description Quantity TU10464 Back Channel TM100 Gear Reducer TU1851 1/2” Cut Washer TU2831 1/2” Lockwasher RC347 1/2” - 13 x 1-1/4” Cap Screw TU33 Motor Drive Bracket TU3124 3/8” - 16 x 3/4” Cap Screw IB140 3/8”...
-
Page 42: Fan Assembly
S6162-BS-MMC-010/12489 FAN ASSEMBLY - TU10575 Ref. No. Part No. Description Quantity MTR302 Motor, 240/480/60/3 TU10445 Motor Mount W/A TU2473 Side Gasket TU2474 Top & Bottom Gasket TU5874 Fan, 5/8” Bore TU2476 Felt Seal TU5439 5/16” - 18 x 3/4” Cap Screw TU2814 5/16”... -
Page 43: Front Panel And Door Assemblys
S6162-BS-MMC-010/12489 RIGHT HAND FRONT PANEL DOOR ASSEMBLY TU11766 LEFT HAND FRONT PANEL AND DOOR ASSEMBLY - TU11772 Ref. No. Part No. Description Quantity TU11767 Right Hand Insulated Front Panel TU11773 Left Hand Insulated Front Panel TU11943 Right Hand Latch Assembly TU11942 Left Hand Latch Assembly FG140... -
Page 44: Lint Door Assembly
S6162-BS-MMC-010/12489 INSULATED LINT DOOR - TU10521 Ref. No. Part No. Description Quantity TU10525 Lint Door TU2710 Trim Holder TU2385 Trim F557 #10-24 x 3/8” Round Head Screw TU11610 Door Latch SC633 Rivet Page 44... -
Page 45: Small Gear Reducer Assembly
S6162-BS-MMC-010/12489 P A R T S — S M A L L G E A R R E D U C E R — T M 1 0 0 Quantity 1 TM103 Housing 2 TM104 Small Seal 3 TM105 Small Open End Cap 4 TM107 Small Bearing Cup 5 TM108... -
Page 46: Control Box Assembly
S6162-BS-MMC-010/12489 CONTROL COMPONENT ASSEMBLY STEAM - TU11812 ELECTRIC - TU10453 Ref. No. Part No. Description Quantity TU10581 Reversing Control Panel TU6965 Contactor, 3 Pole Single TU44131 Timer, Reversing TU7252 Contactor, 3 Pole Double TU6774 Thermal Overload TU267911 Basket Overload Heater TU4660 Transformer M262... -
Page 47: Electronic Heated Bonnet Assembly
S6162-BS-MMC-010/12489 ELECTRONIC HEATED BONNET ASSEMBLY TU11850 Ref. No. Part No. Description Quantity TU11352 Small Brass Buss Bar TU11844 Rear Panel TU11849 Bonnet TU7240 Contactor - 120V, 60A TU2847 1/4” Flat Washer M271 #8 Lockwasher M262 #8 - 32 x 3/8” Screw TU11722 Spacer TU13738... -
Page 48: Nine Section Steam Bonnet Assembly
S6162-BS-MMC-010/12489 NINE SECTION STEAM BONNET ASSEMBLY TU11202 9 Section Steam Bonnet Assembly w/Solenoid Valve 120V Ref. No. Part No. Description Quantity TU11203 Housing Weldment TU2547 Front Coil Retainer TU2548 Rear Coil Retainer TU2413 Steam Coil Manifold TU2414 3/4” - 16 x 3/8” Straight Connector TU2405 Steam Coil 7-3/4”... -
Page 49: Thermostat Assembly
S6162-BS-MMC-010/12489 THERMOSTAT ASSEMBLY TU10796 Ref. No. Part No. Description Quantity 601367512 #8 - 32 X 1” Truss Hd. Screw M270 Washer TU3624 #6 - 32 x 1/4” Screw TU5143 Mounting Bracket TU3400 #6 - 32 Hex Nut TU2045 Cool-Down Thermostat TU3240 Thermostat - 185°... -
Page 50: Wiring Diagrams
S6162-BS-MMC-010/12489 Page 50... - Page 51 S6162-BS-MMC-010/12489 Page 51...
- Page 52 S6162-BS-MMC-010/12489 Page 52...
- Page 53 S6162-BS-MMC-010/12489 Page 53...
