Summary of Contents for JVC KD-SH9700

Page 1 For installation and connections, refer to the separate manual. Para la instalación y las conexiones, refiérase al manual separado. Pour l’installation et les raccordements, se référer au manuel séparé. INSTRUCTIONS MANUAL DE INSTRUCCIONES MANUEL D’INSTRUCTIONS KD-SH9750/KD-SH9700 KD-SH9750/KD-SH9700 KD-SH9750/KD-SH9700 ANGLE DISC PRESET...
Page 2: Important For Laser Products
INFORMATION (For U.S.A.) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
Page 3: Table Of Contents
Thank you for purchasing a JVC product. Please read all instructions carefully before operation, to ensure your complete understanding and to obtain the best possible performance from the unit. CONTENTS How to reset your unit ... LOCATION OF THE BUTTONS ...
Page 4: Location Of The Buttons
LOCATION OF THE BUTTONS Control panel DISP 1 SRC (source) button 2 DISP (D) (display) button 3 5 (up) button 4/¢ buttons 5 Display window 6 • 0 (eject) button • (angle) button 7 BBE button Illumination Navigation for easy operations: If you use MODE (M) or SEL (select), the display and some controls (such as the number buttons, 4/¢...
Page 5: Remote Controller
For KD-SH9750: If the “Line In” setting is changed to “Off,” you cannot select “LINE IN” (see pages 40 and 42). For KD-SH9700: To select “LINE IN,” change the “Ext Input” setting to “Line In” (see pages 40 and 42).
Page 6: Preparing The Remote Controller
Preparing the remote controller Before using the remote controller: • Aim the remote controller directly at the remote sensor on the main unit. Make sure there is no obstacle in between. DISP Remote sensor • Do not expose the remote sensor to strong light (direct sunlight or artificial lighting).
Page 7: Basic Operations
Each time you press the button, the source changes as follows. For KD-SH9750: TUNER CD-CH (CD changer) For KD-SH9700: CD-CH or LINE IN TUNER (CD changer) If a disc is not in the loading slot, you cannot select CD as the source to play.
Page 8: Canceling The Display Demonstration
Canceling the display demonstration When shipped from the factory, display demonstration has been activated, and starts automatically when no operations are done for about 20 seconds. • It is recommended to cancel the demonstration before you use the unit for the first time. To cancel the display demonstration, follow the procedure below: Press and hold SEL (select) for more...
Page 9: Selecting The Level Meter
Set the clock system. 1 Select “24H/12H.” 2 Adjust “24Hours” or “12Hours.” Finish the setting. To check the current clock time when the unit is turned off, press DISP (D). The power turns on and the clock time is shown for about 5 seconds, then the power turns off.
Page 10: Radio Operations
RADIO OPERATIONS DISP Listening to the radio You can use either automatic searching or manual searching to tune in to a particular station. Searching a station automatically: Auto search Select the band (FM1 – 3, AM). 1 Press SRC (source) repeatedly to select the tuner.
Page 11: Searching A Station Manually: Manual Search
To tune in FM stations only with strong signals—LO/DX (Local/Distant) While searching FM stations (including SSM— see page 12), this unit stops searching whenever it detects signals (DX mode: The DX indicator is lit—initial setting). If received signals are weak, you may only hear noises.
Page 12: Storing Stations In Memory
When an FM stereo broadcast is hard to receive: Set the FM reception mode to “Mono On.” Press MODE (M) while listening to an FM stereo broadcast. “Mode” appears on the display, and the number buttons start flashing. Press number button 1, while “Mode” is still on the display.
Page 13: Manual Preset
Manual preset You can preset up to 6 stations in each band (FM1, FM2, FM3 and AM) manually. Ex.: Storing an FM station of 88.3 MHz into the preset number 1 of the FM1 band. Select the band (FM1 – 3, AM) you want to store stations into (in this example, FM1).
Page 14: Changing The Display Pattern
Selecting a preset station using the preset station list If you forget what stations are stored in what preset numbers, you can check the preset station list, then select your desired station on the list. Select the band (FM1 – 3, AM). 1 Press SRC (source) repeatedly to select the tuner.
Page 15: About Mp3 And Wma Discs
DISP This unit has been designed to reproduce CDs, CD-Rs (Recordable), CD-RWs (Rewritable), and CD Texts. • This unit is also compatible with MP3 and WMA discs. For details about these discs, refer to “A Guide to MP3/WMA” (separate volume). About MP3 and WMA discs MP3 and WMA (Windows Media (word “file”...
Page 16 • Display indications when inserting an audio CD or a CD Text: 1 Total track number 2 Total playback time of the disc 3 Disc title/performer (if no title is recorded or assigned*, “No Name” appears.) 4 Track title (if no title is recorded, “No Name” appears.) 5 Current track number 6 Elapsed playing time of the current track...
Page 17: Locating A Particular Portion On A Track
Note: If the ejected disc is not removed within 15 seconds, the disc is automatically inserted again into the loading slot to prevent it from dust. (Disc will not play this time.) What is ImageLink When an MP3 or a WMA folder includes an image <jml>...
Page 18: Locating A Track On A Disc
Locating a track on a disc To go to a particular track directly (ONLY for CD and CD Text discs) Press the number button corresponding to the track number to start its playback. • To select a track number from 1 – 6: Press 1 (7) –...
Page 19: Locating A Folder On A Disc
Locating a folder on a disc The following operations are only possible when playing an MP3 or a WMA disc. To go to a folder directly IMPORTANT: To directly select the folders using the number button(s), it is required that folders are assigned 2 digit numbers at the beginning of their folder names.
Page 20 To skip to the next or previous folder within a folder (on the same hierarchy level) Example 1 Example 2 See the hierarchy diagram on page 15. ONLY on the remote controller: PRESET PRESET Press 3 (right) while playing a disc to skip to the next folder.
Page 21: Selecting A Folder And A Track Using The Name Lists
Selecting a folder and a track using the name lists The following operations are only possible when playing an MP3 or a WMA disc. You can show the folder name and track name lists on the display while playing a disc, then select a folder or a track you want to play.
Page 22: Selecting Playback Modes
Selecting playback modes To play back tracks at random (Random Play) You can play back tracks on a disc (or in a folder for MP3 and WMA discs) at random. Press MODE (M) while playing a disc. “Mode” appears on the display, then the number buttons and the 5 (up)/∞...
Page 23: Prohibiting Disc Ejection
For audio CD and CD Text discs: Repeat Track Repeat Off For MP3 and WMA discs: Repeat Track Repeat Folder Repeat Off Mode Plays repeatedly Repeat Track : Current (or specified) track. • While playing, up on the display Repeat Folder*: All tracks of the current (or specified) folder.
Page 24: Changing The Display Pattern
Changing the display pattern By pressing DISP (D), you can change the information shown on the display. Each time you press the button, the display patterns change as follows: DISP While playing an audio CD or a CD Text disc: •...
Page 25: Dsp Operations
Selecting the DSP modes Using the DSP (Digital Signal Processor) modes built in this unit, you can create a more acoustic sound field in your car compartment. Available DSP modes: THEATER: Reminds you of the intensity reproducing a theater. HALL: Reminds you of a large concert hall with a being-there feeling.
Page 26 Adjust the DSP effect level—1, 2, or The selected DSP effect level is valid for all DSP modes except “V.CANCEL.” • As the number increases, the effect level becomes stronger. Ex. When “Dome” is selected in the previous step To cancel the DSP modes, select “DEFEAT” in step 2 .
Page 27 Press number button 6 to enter the further precise setting screen. Select your listening seats position. • Press number button 1 to select “LEFT (front left)” seat. • Press number button 2 to select “RIGHT (front right)” seat. • Press number button 3 to select “FRONT” seats.
Page 28: Equalizer Operations
EQUALIZER OPERATIONS Selecting preset sound modes (iEQ: intelligent equalizer) You can select a preset sound mode (iEQ: intelligent equalizer) suitable to the music genre. Available sound modes: H. ROCK (Hard Rock) R & B (Rhythm and Blues) POP (Popular music) JAZZ (Jazz) DANCE (Dance music) Country (Country music)
Page 29: Storing Your Own Sound Modes
Storing your own sound modes You can adjust the sound modes to your preference and store your own adjustments in memory (USER 1, USER 2 and USER 3). Press SEL (select) twice to show the sound mode selection screen. The last selected sound mode is called up.
Page 30: Sound Adjustments
SOUND ADJUSTMENTS Performing the basic sound settings You can set the speaker output balance, subwoofer output level, and input level of each source. • There is a time limit in doing the following procedure. If the setting is canceled before you finish, start from step 1 again.
Page 31: Making Sounds Natural-Bbe Digital
To adjust the input level of each source —Vol Adj: This setting is required for each source except FM. Before making an adjustment, select an appropriate source for which you want to make an adjustment. Once you have made an adjustment, it is memorized, and you will not need to adjust the volume level each time you change the source.
Page 32: Graphic Displays
What is Image Converter Image Converter is a JVC’s original software to produce a custom image to show on your JVC Car Audio. Here is a basic procedure to make a CD-R including still images (pictures) and animations...
Page 33: Downloading Images And Animations
Downloading images and animations Before starting the following procedure, prepare a CD-ROM including still images (pictures) and animations (movies). • The supplied Image Converter CD-ROM includes sample images and animations, so you can use this disc as your first trial. IMPORTANT: •...
Page 34 Select (highlight) one of the listed items for which you want to download a file. • PowerOn : Opening screen To download an animation to be shown after the unit is turned on. (You can store only one animation consisting of 30 frames maximum.) •...
Page 35: Deleting Unwanted Files
Select a file you want to download. The file name appears, and the unit will ask you “Download OK?” If it is OK, press number button 1 to start downloading. Downloading starts, and “Downloading...” appears on the display. If it is over, the file name list appears again.
Page 36 To delete the files stored for “PowerOn,” “PowerOff,” “Picture (all stored images at a time),” and “Movie” Press MODE (M) while playing any source. “Mode” appears on the display, and the number buttons and 5 (up)/ ∞ (down) buttons start flashing. Press number button 6 to show the download selection screen.
Page 37: Activating The Downloaded Images And Animations
To delete more files, repeat from steps Press DISP (D) to resume the source indication screen. Activating the downloaded images and animations To activate the animations stored for opening and ending screens After the unit turns on or before the unit turns off, you can see preset animations on the display.
Page 38 Press number button 1 to select— “MOVIE”—Movie category of the PSM settings. The “Graphics” setting screen appears on the display. Select “UserMovie,” “UserSlide,” or “UserPict.” Ex. When you select “UserPict.” • UserMovie: Your edited animation stored in “Movie” is activated as your graphic screen.
Page 39: Other Main Functions
Changing the general settings (PSM) You can change the items listed on the table on the next page by using the PSM (Preferred Setting Mode) control. • The PSM items are grouped into five categories—MOVIE, CLOCK, DISP (display), TUNER, and AUDIO. Basic Procedure Ex.
Page 40 Displayed only after a downlaodable file is stored in memory and while selecting “UserPict.” for “Graphics.” Displayed only when “Dimmer” is set to “Time Set.” Only for KD-SH9700: Not displayed when the current source is “CD-CH (CD changer)” or “LINE IN.” Only for KD-SH9750: Not displayed when the current source is “LINE IN.”...
Page 41 To show the graphics on the display— Graphics You can change the graphics shown on the display. These graphics appear if no operation is done for about 20 seconds (except for “ImageLink”). • All Demo: Display demonstration (animation) appears (see page 8). •...
Page 42 • Off: Deactivates the key-touch tone. To select the external component to use —Ext Input (Only for KD-SH9700) You can connect the external component to the CD changer jack on the rear using the Line Input Adapter KS-U57 (not supplied).
Page 43: Selecting The Dimmer Mode
Selecting the dimmer mode You can dim the display at night automatically or as you set the timer. When shipped from the factory, Auto Dimmer mode is activated. Note: Auto Dimmer equipped with this unit may not work correctly on some vehicles, particularly on those having a control dial for dimming.
Page 44: Assigning Names To The Sources
Assigning names to the sources You can assign names to station frequencies, CDs (both in this unit and in the CD changer), and the external component. After assigning a name, it will appears on the display when you select the source. Maximum number of Sources characters...
Page 45: Changing The Control Panel Angle
Changing the control panel angle You can change the angle of the control panel to four positions. Press and hold 0 ( ) until the angle adjustment screen appears. The 5 (up) and ∞ (down) buttons start flashing to teach you that they can be used for the next operational steps.
Page 46: Detaching The Control Panel
Detaching the control panel You can detach the control panel when leaving the car. When detaching or attaching the control panel, be careful not to damage the connectors on the back of the control panel and on the panel holder. Detaching the control panel Before detaching the control panel, be sure to turn off the power.
Page 47: Cd Changer Operations
DISP We recommend that you use the JVC MP3- compatible CD changer with your unit. By using this CD changer, you can play back your original CD-Rs (Recordable) and CD-RWs (Rewritable) recorded either in audio CD format or in MP3 format.
Page 48: To Go To A Particular Disc Directly
• When the current disc is an MP3 disc: 1 Disc number 2 Disc type—MP3 3 Album title/performer (or folder name is set to “Off”—see page 41, or when no Tag is recorded) 4 Track title (or track name “Off”—see page 41, or when no Tag is recorded) 5 Current folder number 6 Current track number 7 Elapsed playing time of the current track...
Page 49 To go to a track quickly This operation is only possible when using JVC MP3-compatible CD changer CH-X1500. Press MODE (M) while playing a disc. “Mode” appears on the display, and the number buttons and 5 (up)/ ∞ (down) buttons start flashing.
Page 50: Locating A Folder On A Disc
Locating a folder on a disc The following operations are only possible when playing an MP3 disc using a JVC MP3- compatible CD changer, CH-X1500. To skip to the next or previous folder (either on the same or different hierarchy levels) See the hierarchy diagram on page 15.
Page 51: Selecting A Disc/Folder/Track Using The Name Lists
Selecting a disc/folder/track using the name lists To select a disc using the disc lists If you forget what discs are loaded in the CD changer, you can show the disc name list and select a disc in the list shown on the display. •...
Page 52: Selecting Playback Modes
Selecting playback modes To play back tracks at random (Random Play) You can play back tracks on a disc, on all loaded discs (or in a folder for MP3 discs) at random. Press MODE (M) while playing a disc. “Mode” appears on the display, then the number buttons and the 5 (up)/∞...
Page 53 To play back tracks repeatedly (Repeat Play) You can play back a track, a disc (or a folder for MP3 discs) repeatedly. Press MODE (M) while playing a disc. “Mode” appears on the display, then the number buttons and the 5 (up)/ ∞...
Page 54: External Component Operations
• If you cannot select “LINE IN” as the source, change the “Line in” setting to “On.” (See pages 40 and 42.) For KD-SH9700: You can connect the external component to the CD changer jack on the rear using the Line Input Adapter KS-U57 (not supplied).
Page 55: Additional Information
Sound modes (preset frequency level settings) The list below shows the preset frequency level settings for each sound mode. • You can adjust the preset sound modes temporarily. However, your temporary adjustments will be reset when you select another sound mode. Sound Mode 60 Hz...
Page 56: Troubleshooting
TROUBLESHOOTING What appears to be trouble is not always serious. Check the following points before calling a service center. Symptoms • Sound is sometimes interrupted. • Sound cannot be heard from the speakers. • CD-R/CD-RW cannot be played back. • Tracks on the CD-R/CD-RW cannot be skipped.
Page 57 Symptoms • Download does not seem to finish. • Animation does not move. • “Movie” category settings in the PSM do not take effect. • “No Disc” flashes on the display . • “Reset 08” flashes on the display . •...
Page 58: Maintenance
MAINTENANCE Handling discs This unit has been designed to reproduce CDs, CD-Rs (Recordable), CD-RWs (Rewritable), and CD Texts. • This unit is also compatible with MP3 and WMA discs. How to handle discs When removing a disc from its case, press down the center holder of the case and lift the disc out, holding it by the edges.
Page 59: Specifications
Signal-to-Noise Ratio: 70 dB Line-In Level/Impedance (KD-SH9750 only): LINE IN: 1.5 V/20 kΩ load Line-Out Level/Impedance: KD-SH9750: 4.0 V/20 kΩ load (full scale) KD-SH9700: 2.0 V/20 kΩ load (full scale) Output Impedance: 1 kΩ TUNER SECTION Frequency Range: 87.5 MHz to 107.9 MHz (with channel interval set to 200 kHz) 87.5 MHz to 108.0 MHz...
Page 60 Having TROUBLE with operation? Please reset your unit Refer to page of How to Reset Still having trouble?? USA ONLY Call 1-800-252-5722 http://www.jvc.com We can help you! VICTOR COMPANY OF JAPAN, LIMITED EN, SP, FR 0203MNMMDWJEIN © 2003 VICTOR COMPANY OF JAPAN, LIMITED...
Page 61: Localizacion De Averias
• The following illustration shows a typical installation. However, you should make adjustments corresponding to your specific car. If you have any questions or require information regarding installation kits, consult your JVC car audio dealer or a company supplying kits. Before mounting: Press (Control Panel Release button) to detach the control panel if already attached.
Page 62: Electrical Connections
NEGATIVA solamente. Si su vehículo no posee este sistema, será necesario un inversor de tensión, que puede ser adquirido en los concesionarios de JVC de equipos de audio para automóviles. • Reemplace el fusible por uno con la corriente especificada. Si el fusible se quemase frecuentemente consulte con su concesionario de JVC de equipos de audio para automóviles.
Page 63 • You cannot use the KD-MK series CD changers with this unit. A l’antenne Only for KD-SH9700: You can also use an external component such as a portable MD player by connecting the Line Input Adapter KS-U57 (not supplied). (See diagram Se recomienda conectar el cambiador de CD de JVC compatible con MP3.
Page 64 Adaptateur d’entrée de ligne KS-U57 (non fourni avec cet appareil) KD-SH9700 JVC CD changer jack Toma del cambiador de CD de JVC Prise CD changeur JVC CAUTION / PRECAUCION / PRECAUTION: • To prevent short-circuit, cover the terminals of the UNUSED leads with insulating tape.
Page 65 LVT1046-001A ENGLISH A Guide to MP3/WMA What are MP3/WMA? MP3 (MPEG Audio Layer 3) is one of digital audio compression standards. • This player cannot play back MP3i and MP3 PRO formats. ® WMA (Windows Media Audio) is the digital audio compression format developed by Microsoft Corporation.
Page 66 ‡ : Compatible / Compatibles / Compatible KD-SH9750, KD-SH9700 (compatible with both MP3 and WMA files) / (compatible con ambos archivos MP3 y WMA) / (compatible à la fois avec les fichiers MP3 et WMA) ‡...
Page 67 Notice the following information will help you to solve your problems. Keep this IMPORTANT sheet together with the INSTRUCTIONS. • After installing the unit = Follow the procedure Å described below. • If the unit does not operate = Follow the procedure Å described below. •...
Page 68: Activación De Imágenes Y Animaciones Descargadas
Addendum/Addenda/Addenda English Page 37 Activating the downloaded images and animations To activate the animations stored for opening and ending screens • Opening and ending screens will not be shown if the “KeyIn CFM” setting is set to “Short” or “Off.” (See page 41).
Page 69 Canceling the display demonstration / Cancelación de la demostración en pantalla / Annulation de la démonstration des affichages / Abbrechen der Display-Demonstration / Annuleren van de displaydemonstratie / Annullamento della demo del display ENGLISH When shipped from the factory, display demonstration has been activated, and starts automatically when no operations are done for about 20 seconds.
