Page 1 3 7 63 1515 0 SERVICE MANUAL CD RECEIVER 49841 2003 KD-SH9101 ANGLE DISC PRESET PRESET KD-SH9101 MOSFET DISC DISP VOLUME MODE L 13942296513 RM-RK100 Area Suffix E ------ ContinentalEurope EX --------- Central Europe TABLE OF CONTENTS Precautions ................1-3 Disassembly method .
Page 2: Http://Www.xiaoyu163.Com
http://www.xiaoyu163.com 3 7 63 1515 0 SPECIFICATION Front 50 W per channel Maximum Power Output Rear 50 W per channel 19 W per channel into 4Ω, 40 Hz to 20 000 Hz at Front no more than 0.8% total harmonic distortion. Continuous Power Output (RMS) 19 W per channel into 4Ω, 40 Hz to 20 000 Hz at...
Page 3: Precautions
http://www.xiaoyu163.com 3 7 63 1515 0 SECTION 1 Precautions Safety Precautions Burrs formed during molding may be left over on some parts of the chassis. Therefore, pay attention to such burrs in the case of preforming repair of this system. Please use enough caution not to see the beam directly or touch it in case of an adjustment or operation check.
Page 4: Disassembly Method 2
http://www.xiaoyu163.com 3 7 63 1515 0 Preventing static electricity Electrostatic discharge (ESD), which occurs when static electricity stored in the body, fabric, etc. is discharged, can destroy the laser diode in the traverse unit (optical pickup). Take care to prevent this when performing repairs. 1.2.1 Grounding to prevent damage by static electricity Static electricity in the work area can destroy the optical pickup (laser diode) in devices such as CD players.
Page 5: Disassembly Method
http://www.xiaoyu163.com 3 7 63 1515 0 SECTION 2 Disassembly method 2.1 Main body section 2.1.1 Removing the front panel assembly (See Fig.1) (1) Push the detach button in the lower right part of the front panel assembly. Front panel assembly (2) Remove the front panel assembly in the direction of the ar- row.
Page 6 http://www.xiaoyu163.com 3 7 63 1515 0 2.1.2 Removing the top chassis (See Figs.2 to 6) • Turn on power. (1) Push the eject button in the upper right part of the front pan- Top chassis el assembly to move the front panel assembly as shown in Fig.2 and turn off power.
Page 7 http://www.xiaoyu163.com 3 7 63 1515 0 2.1.3 Removing the mecha control board (See Fig.7) • Prior to performing the following procedures, remove the top chassis. Mecha control board (1) Disconnect the card wire from the connector CN601 on the mecha control board. (2) Remove the five screws G attaching the mecha control board.
Page 8 http://www.xiaoyu163.com 3 7 63 1515 0 2.1.5 Removing the motor assembly (See Figs.9 to 11) • Prior to performing the following procedures, remove the top chassis. Motor braket Spring (1) Remove the spring from the motor bracket. (See Fig.9.) (2) Disconnect the wire from the connector CN982 on the main board.
Page 9 http://www.xiaoyu163.com 3 7 63 1515 0 2.1.6 Removing the main board (See Figs.12 to 16) • Prior to performing the following procedures, remove the top chassis and motor assembly. (1) Disconnect the flexible wires from the connectors CN703 and CN991 on the main board respectively. (See Fig.12.) (2) Move the front bracket backward until it stops.
Page 10 http://www.xiaoyu163.com 3 7 63 1515 0 2.1.7 Removing the lifter switch board (See Fig.17) • Prior to performing the following procedure, remove the top chassis, motor assembly and main board. Bottom chassis Lifter switch board (1) Remove the two screws T attaching the lifter switch board to the bottom chassis.
Page 11 http://www.xiaoyu163.com 3 7 63 1515 0 2.1.8 Removing the lifter board (See Figs.18 to 24) • Prior to performing the following procedures, remove the top chassis and front panel assembly. • Remove the four screws U attaching the front bracket on the both sides of the main body.
Page 12 http://www.xiaoyu163.com 3 7 63 1515 0 Lifter board Connector cover Fig.23 L 13942296513 Fig.24 u163 1-12 (No.49841) http://www.xiaoyu163.com...
Page 13 http://www.xiaoyu163.com 3 7 63 1515 0 2.1.9 Removing the front board (See Figs.25 to 28) • Prior to performing the following procedures, remove the front panel assembly. Front panel assembly (1) Remove the six screws X attaching the rear panel to the front panel assembly.
Page 14 http://www.xiaoyu163.com 3 7 63 1515 0 2.2 CD Mechanism section 2.2.1 Removing the top cover (See Figs.1 and 2) (1) Remove the four screws A on the both side of the body. (2) Lift the front side of the top cover and move the top cover backward to release the two joints a.
Page 15 http://www.xiaoyu163.com 3 7 63 1515 0 2.2.2 Removing the connector board Wires (See Figs.3 to 5) CAUTION: Before disconnecting the flexible wire from the pickup, solder the short-circuit point on the pickup. No observance of this in- struction may cause damage of the pickup. (1) Remove the screw B fixing the connector board.
Page 16 http://www.xiaoyu163.com 3 7 63 1515 0 2.2.3 Removing the DET switch (See Figs.6 and 7) (1) Extend the two tabs c of the feed sw. holder and pull out the switch. (2) Unsolder the DET switch wire if necessary. switch Connector board Pickup...
Page 17 http://www.xiaoyu163.com 3 7 63 1515 0 2.2.4 Removing the chassis unit (See Figs.8 and 9) • Prior to performing the following procedure, remove the top Chassis unit cover and connector board. Suspension spring (L) Suspension spring (R) (1) Remove the two suspension springs (L) and (R) attaching the chassis unit to the frame.
Page 18 http://www.xiaoyu163.com 3 7 63 1515 0 2.2.5 Removing the clamper assembly (See Figs.10 and 11) • Prior to performing the following procedure, remove the top cover. (1) Remove the clamper arm spring. Clamper arm spring (2) Move the clamper assembly in the direction of the arrow to release the two joints d.
Page 19 http://www.xiaoyu163.com 3 7 63 1515 0 2.2.6 Removing the loading / feed motor assembly (See Figs.12 and 13) • Prior to performing the following procedure, remove the top cover, connector board and chassis unit. (1) Remove the screw C and move the loading / feed motor as- sembly in the direction of the arrow to remove it from the chassis rivet assembly.
Page 20 http://www.xiaoyu163.com 3 7 63 1515 0 2.2.7 Removing the pickup unit Pickup unit (See Figs.14 to 18) • Prior to performing the following procedure, remove the top cover, connector board and chassis unit. (1) Remove the screw D and pull out the pu. shaft holder from Part e the pu.
Page 21 http://www.xiaoyu163.com 3 7 63 1515 0 2.2.9 Removing the trigger arm Joint k (See Figs.19 and 20) • Prior to performing the following procedure, remove the top cover, connector board and clamper unit. (1) Turn the trigger arm in the direction of the arrow to release Trigger arm the joint k and pull out upward.
Page 22 http://www.xiaoyu163.com 3 7 63 1515 0 2.2.11 Removing the mode sw. / select lock arm Link plate Joint t (See Figs.22 and 23) Mode sw. • Prior to performing the following procedure, remove the top plate assembly. Select lock arm (1) Bring up the mode sw.
Page 23 http://www.xiaoyu163.com 3 7 63 1515 0 2.2.12 Reassembling the mode sw. / select lock arm Select lock arm spring (See Figs.24 to 26) REFERENCE: Hook w Reverse the above removing procedure. Joint v (1) Reattach the select lock arm spring to the top plate and set Joint v the shorter end of the select lock arm spring to the hook w on the top plate.
Page 24 http://www.xiaoyu163.com 3 7 63 1515 0 2.2.13 Removing the select arm R / link plate Joint c' Link plate Joint r (See Figs.27 and 28) Select arm R Joint b' • Prior to performing the following procedure, remove the top plate assembly.
Page 25 http://www.xiaoyu163.com 3 7 63 1515 0 2.2.15 Removing the loading roller assembly (See Figs.31 to 33) Loading roller assembly • Prior to performing the following procedure, remove the Roller guide clamper assembly and top plate assembly. spring (1) Push inward the loading roller assembly on the gear side and detach it upward from the slot of the joint g' of the lock arm rivet assembly.
Page 26 http://www.xiaoyu163.com 3 7 63 1515 0 2.2.16 Removing the loading gear 5, 6 and 7 Loading gear bracket (See Figs.35 and 36) • Prior to performing the following procedure, remove the top Loading gear 6 cover, chassis unit, pickup unit and top plate assembly. (1) Remove the screw K attaching the loading gear bracket.
Page 27 http://www.xiaoyu163.com 3 7 63 1515 0 2.2.17 Removing the gears Joint p' (See Figs.37 to 40) • Prior to performing the following procedure, remove the top Change plate cover, chassis unit, top plate assembly and pickup unit. rivet assembly • Pull out the loading gear 3. (See Fig.35.) (1) Pull out the feed gear.
Page 28 http://www.xiaoyu163.com 3 7 63 1515 0 2.2.18 Removing the turn table / spindle motor Turn table (See Figs.41 and 42) • Prior to performing the following procedure, remove the top cover, connector board, chassis unit and clamper assembly. (1) Remove the two screws L attaching the spindle motor as- sembly through the slot of the turn table on top of the body.
Page 29: Adjustment
(4) Stereo modulator (5) Electric voltmeter Frequency Band (6) Digital tester 87.5MHz to 108.0MHz (7) Tracking offset meter (8) Test Disc JVC :CTS-1000 AM (MW) 522kHz to 1620kHz (9) Extension cable for check AM (LW) 144kHz to 279kHz EXTSH002-22P × 1...
Page 30 http://www.xiaoyu163.com 3 7 63 1515 0 Service mode When entering the service mode, "DATA CLEAR" is displayed without fail. : Initial display : SEEK UP : DISC UP POWER : SEEK DOWN : DISC DOWN SOURCE EPROM all clear & Flash ROM all clear DATA_CLEAR EPROM_CLEAR (Following all contents are cleared.)
Page 31 http://www.xiaoyu163.com 3 7 63 1515 0 CD_DATA_READ ADJ_NOW ADJ_NOW ADJ_INT FEB__ ____TEB__ OTHERS FGA__ ____TGA__ FEO__ ____RFG__ DISC+/-:FUNCTION TEO__ ADJ_NOW ADJ_INT ADJ_INT FEB__ ____TEB__ OTHERS FGA__ ____TGA__ FEO__ ____RFG__ TEO__ CD data display ADJ_NOW OTHERS Hex. code display ADJ_INT IOP__TEMP____I Total running time display OTHERS IOP__INT__...
Page 32 http://www.xiaoyu163.com 3 7 63 1515 0 Troubleshooting Feed section Is the voltage output at Is the wiring for IC621 Is 3.3V present at IC681 IC621 pin "40" 5V or 0V? pin "40"? pin "6"? Check CD 8V Check the vicinity of and 5V.
Page 33 http://www.xiaoyu163.com 3 7 63 1515 0 Flow of functional operation unit TOC read Power ON When the laser diode correctly When the pickup correctly moves Set Function CD emits to the inner area of the disc Microprocessor $82 $81 Microprocessor commands Disc inserted commands...
Page 34 http://www.xiaoyu163.com 3 7 63 1515 0 Maintenance of laser pickup Replacement of laser pickup (1) Cleaning the pick up lens Before you replace the pick up, please try to clean the lens Turn off the power switch and,disconnect the power cord from the ac outlet. with a alcohol soaked cotton swab.
Page 35: Description Of Major Ics
http://www.xiaoyu163.com 3 7 63 1515 0 SECTION 4 Description of major ICs BA3220FV-X (IC171,IC271) : Line out amplifier • Pin layout 3220 • Block diagram OUTL OUTR RGND LGND L 13942296513 REFR REFL FILTER u163 (No.49841)1-35 http://www.xiaoyu163.com...
Page 36 http://www.xiaoyu163.com 3 7 63 1515 0 AK7740VT (IC101) : Audio DSP with AD/DA converter • Pin layout AINL3 AOUTL2 AINR2 AOUTR2 AINL2 BVSS AINR1 DVSS AINL1 DVDD VREFH INT_RESET 48 pin LQFP AVDD (TOP VIEW) S_RESET AVSS DVSS SCLK DVDD Note) JX , SDIN and SDINA are Pull-down pins •...
Page 37 http://www.xiaoyu163.com 3 7 63 1515 0 • Pin function Pin No. Symbol Function AINL3 ADC single-ended analog Lch input pin No.3 AINR2 ADC single-ended analog Rch input pin No.2 AINL2 ADC single-ended analog Lch input pin No.2 AINR1 ADC single-ended analog Rch input pin No.1 AINL1 ADC single-ended analog Lch input pin No.1 VREFH...
Page 38 http://www.xiaoyu163.com 3 7 63 1515 0 BA6956AN (IC981) : Reversible motor driver • Pin layout & Block diagram • Pin function Pin No. Symbol Function VREF Output high voltage level control terminal OUT2 Output terminal for motor GND of driver division CONTROL LOGIC OUT1 Output terminal for motor...
Page 39 http://www.xiaoyu163.com 3 7 63 1515 0 BR24L32F-W-X (IC703) : EEPROM • Pin layout • Block diagram Symbol Function A0A1A2 Slave address set Ground (0V) Slave and word address Serial data input serial data output Serial clock input Write protect input Power supply •...
Page 40 http://www.xiaoyu163.com 3 7 63 1515 0 HA13166 (IC911) : System regulator for car-audio • Pin layout • Block diagram 100u 0.1u EXTOUT Surge Protector 0.1u COMPOUT ANTOUT 0.1u BIAS SW5VOUT ANT CTRL VREF VREF L 13942296513 VDDOUT CTRL 0.1u VthM VthH VREF DSPOUT...
Page 41 http://www.xiaoyu163.com 3 7 63 1515 0 HD74HCT126T-X (IC503) : Buffer • Pin arrangement • Pin function Input Output H : High level L : Low level X : Irrelevant Z : Off (Hhigh-impedance)state of a 3-stage output • Block diagram L 13942296513 u163 (No.49841)1-41...
Page 42 http://www.xiaoyu163.com 3 7 63 1515 0 IC-PST3424U-X (IC803) : Reset • Pin layout VOUT • Block diagram VOUT Vref • Pin function Pin Name Function L 13942296513 Vout Reset Signal Output PIN VDD PIN / Voltage Detect PIN Non connect VSS PIN 4.10 NJU7241F33-X (IC504,IC804) : Voltage regulator •...
Page 43 http://www.xiaoyu163.com 3 7 63 1515 0 4.11 TDA7560-8U (IC301) : Car radio amplifier • Pin layout • Block diagram Vcc1 Vcc2 470uF 100nF ST-BY MUTE HSD/V OUT1+ OUT1- 0.1µF PW-GND L 13942296513 OUT2+ OUT2- 0.1µF PW-GND OUT3+ OUT3- 0.1µF PW-GND OUT4+ OUT4- 0.1µF...
Page 44 http://www.xiaoyu163.com 3 7 63 1515 0 4.12 LH28F160BJHET93 (IC803) : 16M flash memory • Pin layout BYTE# 48-LEAD TSOP STANDARD PINOUT 12mm x 20mm TOP VIEW RY/BY# • Block diagram to DQ Output Input buffer buffer L 13942296513 I/O logic ID code BYTE# register...
Page 45 http://www.xiaoyu163.com 3 7 63 1515 0 • Pin function Pin No. Symbol Function 1 to 8 to A Address input for memory address Address input for memory address Non connection Write enable Reset VCCW Power supply for write/erase Write protect RY/BY# Ready/Busy 16,17...
Page 46 http://www.xiaoyu163.com 3 7 63 1515 0 4.13 MN102H60KCJ1 (IC801) : LCD display sub CPU • Pin layout • Block diagram Pin No. Symbol Function LCD reset output Read enable output for extension memory Write enable output for extension memory VCCWCNT Writing voltage control for external ROM RY/BY Read/Busy input for extension memory...
Page 47 http://www.xiaoyu163.com 3 7 63 1515 0 Pin No. Symbol Function LCD chip select output Connect to ground VOL1 Rotary encoder input 1 VOL2 Rotary encoder input 2 SWLED3 Not connect AGND Analog ground 62 to 65 KEY0 to KEY3 Key 0 to 3 input AD terminal Power supply SWLED0 SW_LED flashing output 0 for [VOL] key LED...
Page 48 http://www.xiaoyu163.com 3 7 63 1515 0 4.14 NJM2360AM-X (IC921) : DC-DC convertor • Pin layout 1. Cs 2. Es 3. C 4. GND 5. INV 6. Vcc 7. S 8. C • Block diagram Switch Driver collector collector Switch Ipk sense emitter Timing capacitor...
Page 49 http://www.xiaoyu163.com 3 7 63 1515 0 4.17 SAA6579T-X (IC71) : RDS detecter • Pin layout QUAL DATA Vref OSCO OSCI TEST SCOUT MODE • Block diagram ANTI- 57 kHz OSCILLATOR QUALITY BIT RECONSTRUCTION ALIASING BAND PASS GENERATOR FILTER FILTER (8th ORDER) DIVIDER COSTAS LOOP BIPHASE...
Page 50 http://www.xiaoyu163.com 3 7 63 1515 0 4.18 UPD784217AGC217 (IC701) : CPU • Pin layout • Block diagram Pin No Symbol Function S.SELECT E-VOL selection output, H: REAR L: FRONT DSP.SELECT DSP or Source direct selection output, H: Source direct L: DSP LINE IN ON OTHER AMP KILL...
Page 51 http://www.xiaoyu163.com 3 7 63 1515 0 Pin No Symbol Function NOT USE Not connect DETACH Detach detect input; H means detaching DSP data writing ready input INPUT OVER lLINE,AUX input over detecting port, L: Input over S.RESET DSP system reset output INIT.RESET DSP initialize reset output DSP request input, RQ=L: Interface to micom...
Page 52 http://www.xiaoyu163.com 3 7 63 1515 0 4.19 TDA7404D-X (IC911) : Car radio signal processor • Pin layout • Block diagram Mono Fader Mono Fader Mono Fader Mono Fader Mono Fader Mono Fader Zero Cross Mono/Beep Beep Digital Control I C-Bus Supply L 13942296513 u163...
Page 53 http://www.xiaoyu163.com 3 7 63 1515 0 L 13942296513 u163 (No.49841)1-53 http://www.xiaoyu163.com...
Page 54 http://www.xiaoyu163.com 3 7 63 1515 0 L 13942296513 u163 VICTOR COMPANY OF JAPAN, LIMITED AV & MULTIMEDIA COMPANY MOBILE ENTERTAINMENT CATEGORY 10-1,1chome,Ohwatari-machi,Maebashi-city,371-8543,Japan (No.49841) Printed in Japan http://www.xiaoyu163.com...
Page 55: Schematic Diagrams
KD-SH9101 3 7 63 1515 0 SCHEMATIC DIAGRAMS CD RECEIVER KD-SH9101 Area Suffix E ---------- Continental Europe EX -------------- Central Europe L 13942296513 ANGLE DISC PRESET PRESET MOSFET KD -SH9101 DISC DISP VOLUME MODE RM-RK100 Contents Block diagram Standard schematic diagrams...
Page 56: Safety Precaution
KD-SH9101 3 7 63 1515 0 Safety precaution Burrs formed during molding may be left over on some parts of the chassis. Therefore, pay attention to such burrs in the case of preforming repair of this system. Please use enough caution not to see the beam directly or touch it in case of an adjustment or operation check.
Page 57: Block Diagram
KD-SH9101 3 7 6 3 1 5 1 5 0 Block diagram IC331 TU-L IC301 TU-R IC431 VA,VB VOUTL CD.L-CH FM/AM POWER AMP. VE,VF VOUTR IC572 CD.R-CH BUFF AMP. TUNER PACK IC601 MD,LD IC571 RWSEL,IOP FL,RL CD LPF IC171...
Page 58 KD-SH9101 KD-SH9101 Standard schematic diagrams 3 7 6 3 1 5 1 5 0 Main amplifier section IC301 TDA7560 R173 R338 R336 IC171 C333 C336 BA3220FV C180 0.01 C175 100P 100/10 4.7/25 C171 4.7/25 C177 4.7/25 IC151 IC251 C173...
Page 59 KD-SH9101 LCD & Key control, tuner and DSP section 3 7 6 3 1 5 1 5 0 R852 ACC5V R853 R840 R854 1.5k R841 R855 1.5k R842 1.5k R896 R454 R453 R452 R451 KEY0 D803 C830 1000P S805...
Page 60 KD-SH9101 KD-SH9101 CD servo control section 3 7 6 3 1 5 1 5 0 RWSEL R585 C585 C587 C589 R613 R581 R583 C611 CD.L-CH 120p 4.7/35 4.7/35 R614 R612 R611 R610 C610 C586 C588 C590 R582 R584 CD.R-CH...
Page 61 KD-SH9101 3 7 63 1515 0 Printed circuit boards Main board Forward side IC911 CN941 CN322 R913 CN321 R914 R915 R953 R954 C931 C920 C356 R921 CN901 C913 C923 C411 C325 C425 C918 D901 C311 R328 R428 D411 C925...
Page 62 KD-SH9101 3 7 63 1515 0 Main board Reverse side CN901 C421 C422 C322 C321 CN322 CN941 C324 C323 IC911 R329 CN321 C716 C326 C944 R921 CN702 R371 C931 C913 C356 D901 C923 C920 C362 D702 R370 R368 D353...
Page 63 KD-SH9101 3 7 63 1515 0 Front board Forward side Reverse side D842 D841 D840 D814 D813 D812 D811 D810 D809 D808 D807 D806 R876 Q802 C830 C829 C823 R848 R847 C828 R845 C824 C825 R844 R843 C826 R839...
Page 64 KD-SH9101 3 7 63 1515 0 Mecha control board Forward side TH501 R615 R605 R606 R616 C573 R608 C572 R614 R607 C571 R609 R564 R566 R565 C608 R571 R574 R524 C632 C631 R539 R678 R630 R526 R631 R507 R506...
Page 65 KD-SH9101 3 7 63 1515 0 Mecha control board Reverse side L501 Q683 B681 C674 C652 D681 R514 Q682 R515 L651 L622 C682 L623 R511 L621 Q681 D505 C681 D504 R508 C505 R689 D503 C654 R531 R651 D502 C504...
Page 66 KD-SH9101 3 7 63 1515 0 L 13942296513 u163 VICTOR COMPANY OF JAPAN, LIMITED AV & MULTIMEDIA COMPANY 10-1,1Chome,Ohwatari-machi,Maebashi-city,371-8543,Japan Printed in Japan (No.49841SCH) 2003/05 http://www.xiaoyu163.com...
Page 67: Parts List
KD-SH9101 3 7 63 1515 0 PARTS LIST [ KD-SH9101 ] * All printed circuit boards and its assemblies are not available as service parts. Area suffix E------------ Continental Europe EX --------------- Central Europe L 13942296513 - Contents - Exploded view of general assembly and parts list (Block No.M1)
Page 68 KD-SH9101 3 7 63 1515 0 Exploded view of general assembly and parts list Block No. L 13942296513 u163 http://www.xiaoyu163.com...
Page 69 KD-SH9101 3 7 63 1515 0 General assembly Block No. [M][1][M][M]  Symbol No. Part No. Part Name Description Local  Symbol No. Part No. Part Name Description Local LV40865-001A MINI SCREW (x3) LV40865-001A MINI SCREW (x2) --------------------- CD MECHA...
Page 70 KD-SH9101 3 7 63 1515 0 CD mechanism assembly and parts list Block No. Grease TNG-87 TN-2001-1013 GP-501MK CFD-005Z GP-501A L 13942296513 u163 http://www.xiaoyu163.com...
Page 71 KD-SH9101 3 7 63 1515 0 CD mechanism Block No. [M][B][M][M]  Symbol No. Part No. Part Name Description Local 30320101T FRAME 30320102T TOP COVER 30320115T DANPER F (x2) 30320116T DANPER R 303205505T CHASSIS RIVET 303205503T CHANGE P. RVT A...
Page 72: Electrical Parts List
KD-SH9101 3 7 63 1515 0 Electrical parts list Main board Block No. [0][1][0][0]  Symbol No. Part No. Part Name Description Local  Symbol No. Part No. Part Name Description Local MA152WK-X SI DIODE D301 1SS355-X SI DIODE...
Page 73 KD-SH9101 3 7 63 1515 0  Symbol No.  Symbol No. Part No. Part Name Description Local Part No. Part Name Description Local C102 NCB31HK-102X C CAPACITOR 1000pF 50V K C279 QERF1CM-476Z E CAPACITOR 47uF 16V M C103...
Page 74 KD-SH9101 3 7 63 1515 0  Symbol No.  Symbol No. Part No. Part Name Description Local Part No. Part Name Description Local C724 NDC31HJ-101X C CAPACITOR 100pF 50V J R122 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J C725...
Page 75 KD-SH9101 3 7 63 1515 0  Symbol No.  Symbol No. Part No. Part Name Description Local Part No. Part Name Description Local SH91 R739 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R354 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J...
Page 76: Front Board
KD-SH9101 3 7 63 1515 0  Symbol No.  Symbol No. Part No. Part Name Description Local Part No. Part Name Description Local R936 NRSA63D-473X MG RESISTOR 47kΩ 1/16W D S894 NSW0146-001X DETECT SW R937 NRSA63D-392X MG RESISTOR 3.9kΩ...
Page 77 KD-SH9101 3 7 63 1515 0  Symbol No.  Symbol No. Part No. Part Name Description Local Part No. Part Name Description Local C811 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M R816 NRSA63J-331X MG RESISTOR 330Ω 1/16W J...
Page 78 KD-SH9101 3 7 63 1515 0  Symbol No.  Symbol No. Part No. Part Name Description Local Part No. Part Name Description Local EN801 QSW1025-001 ROTARY ENCODER C575 NEAD0JM-476X E CAPACITOR 47uF 6.3V M SH91 C576 NCB31CK-104X C CAPACITOR 0.1uF 16V K...
Page 79 KD-SH9101 3 7 63 1515 0  Symbol No.  Symbol No. Part No. Part Name Description Local Part No. Part Name Description Local C664 NCB31EK-273X C CAPACITOR 0.027uF 25V K R563 NRSA63J-682X MG RESISTOR 6.8kΩ 1/16W J C665...
Page 80 KD-SH9101 3 7 63 1515 0  Symbol No. Part No. Part Name Description Local L502 NQL114K-470X COIL 47uH K L571 NQL114K-470X COIL 47uH K L572 NQL114K-470X COIL 47uH K L621 NQL114K-470X COIL 47uH K L622 NQL114K-470X COIL 47uH K...
Page 81 KD-SH9101 3 7 63 1515 0 <MEMO> L 13942296513 u163 3-15 http://www.xiaoyu163.com...
Page 82 KD-SH9101 3 7 63 1515 0 Packing materials and accessories parts list Block No. A12A13 L 13942296513 KIT: A14A15 A16A17 A18 u163 3-16 http://www.xiaoyu163.com...
Page 83 KD-SH9101 3 7 63 1515 0 Packing and accessories Block No. [M][3][M][M]  Symbol No. Part No. Part Name Description Local LVT1005-001A INST BOOK ENG GER FRE DUT SH91 LVT1005-002A INST BOOK RUS SPA ITA POL SH91 LVT1005-003A INST BOOK...
