Summary of Contents for JVC KD-SH707

Page 1 For installation and connections, refer to the separate manual. Para la instalación y las conexiones, refiérase al manual separado. Pour l’installation et les raccordements, se référer au manuel séparé. INSTRUCTIONS MANUAL DE INSTRUCCIONES MANUEL D’INSTRUCTIONS KD-SH909/KD-SH707 KD-SH909/KD-SH707 KD-SH909/KD-SH707 KD-SH909 ANGLE MOSFET...
Page 2: How To Reset Your Unit
INFORMATION (For U.S.A.) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
Page 3: Table Of Contents
Thank you for purchasing a JVC product. Please read all instructions carefully before operation, to ensure your complete understanding and to obtain the best possible performance from the unit. CONTENTS How to reset your unit ... How to use the MODE (M) button ...
Page 4: How To Use The Mode (M) Button
How to use the MODE (M) button: If you press MODE (M), the unit goes into functions mode and the number, DISP (D) work as different function buttons. MODE To use these buttons for their original function (ex. as the number buttons) again after pressing MODE (M), wait for 5 seconds without pressing any of these buttons until the functions mode is cleared.
Page 5: Location Of The Buttons
LOCATION OF THE BUTTONS Control panel Display window DIRECTORY FILE DISC STATION TRACK g h j MOSFET 2 0 0 W K D - S H 9 0 9 1 0 (eject) button 2 Control dial 3 SEL (select) button 4 EQ (equalization) button 5 E-BASS (EB) (Extended Bass) button 6 DISP (D) (Display) button...
Page 6: Remote Controller
** For KD-SH909: If “AUX IN” or “LINE IN” is set to “OFF,” this cannot be selected (see pages 33 and 34). For KD-SH707: To select the external component, you have to change the external component setting (see page 33).
Page 7: Preparing The Remote Controller
Preparing the remote controller Before using the remote controller: • Aim the remote controller directly at the remote sensor on the main unit. Make sure there is no obstacle in between. Remote sensor • Do not expose the remote sensor to strong light (direct sunlight or artificial lighting).
Page 8: Basic Operations
For KD-SH909: AM TUNER FM TUNER (AM) (FM) AUX INPUT LINE INPUT (AUX) (LINE) For KD-SH707: AM TUNER FM TUNER (AM) (FM) CD CHANGER (CD CH) AUX INPUT (AUX) LINE INPUT (LINE) If a disc is not in the loading slot, you cannot select CD as the source to play.
Page 9: Canceling The Display Demonstration
Canceling the display demonstration When shipped from the factory, display demonstration has been activated, and starts automatically when no operations are done and no sound comes in for about 3 minutes. To cancel the display demonstration, follow the procedure below. Press and hold SEL (select) for more than 2 seconds so that one of the PSM items appears on the display.
Page 10: Radio Basic Operations
RADIO BASIC OPERATIONS Listening to the radio You can use either automatic searching or manual searching to tune in to a particular station. Searching a station automatically: Auto search Select FM or AM. 1 Press SOURCE repeatedly to select FM or AM as the source.
Page 11 Searching a station manually: Manual search Select FM or AM. 1 Press SOURCE repeatedly to select FM or AM as the source. 2 If necessary, press BAND (B) repeatedly to select the FM band BAND number. Each time you press the button, the FM band changes as follows: (FM 1)
Page 12: Storing Stations In Memory
Storing stations in memory You can use one of the following two methods to store broadcasting stations in memory. • Automatic preset of FM stations: SSM (Strong- station Sequential Memory) • Manual preset of both FM and AM stations FM station automatic preset: SSM You can preset 6 local FM stations in each FM band (FM1, FM2 and FM3).
Page 13: Tuning In To A Preset Station
Tune in to a station (in this example, of 88.3 MHz). Press ¢ in to stations of higher frequencies. Press in to stations of lower frequencies. Press and hold the number button (in this example, 1) for more than 2 seconds.
Page 14: Cd Operations
CD OPERATIONS When playing an MP3 disc, refer also to “MP3 OPERATIONS” on pages 20 to 26. Playing a CD Open the control panel. The control panel moves down, and the loading slot appears. Note: When an external component is connected to the MP3 INPUT jack, be careful of handling a disc.
Page 15: Locating A Track Or Particular Portion On A Cd
To return the control panel to its previous position, press 0 again. • If you keep the loading slot open for one minute (or 30 seconds when you have ejected a disc with the ignition key turned to “OFF”), a beep sounds and the control panel returns to its previous position.
Page 16: Playing A Cd Text
Playing a CD Text In a CD Text, some information about the disc (its disc title, performer and track title) is recorded. You can show these disc information on the display. Select text display mode while playing a CD Text. Each time you press the button, the display changes as follows: DISP...
Page 17: Prohibiting Disc Ejection
To play back the current track repeatedly (One Track Repeat Play) You can play back the current track repeatedly. 1 Press MODE (M) while playing a disc. The unit MODE enters the functions mode. 2 Press RPT (repeat) while still in the functions mode, so that the “REPEAT”...
Page 18: Mp3 Introduction
MP3 INTRODUCTION What is MP3? MP3 is an abbreviation of Motion Picture Experts Group (or MPEG) Audio Layer 3*. MP3 is simply a file format with a data compression ratio of 1:10 (128 Kbps**). That means, by using MP3 format, one CD-R or CD-RW can contain 10 times as much data volume as a regular CD can.
Page 19 MP3 directory/file configuration : Root ROOT : Directories : MP3 files MP3 playback/search order (page 22) • The numbers in circles below the MP3 files ( MP3 files. Normally this unit plays back MP3 files in the recorded order. • The numbers inside the directories indicate the playback order and search order of the directories on an MP3 disc.
Page 20: Mp3 Operations
MP3 OPERATIONS Refer also to “CD OPERATIONS” on pages 14 to Playing an MP3 disc Open the control panel. The control panel moves down, and the loading slot appears. Insert an MP3 disc into the loading slot. The display changes to show the following: CD-in indicator lights up.
Page 21 • When “TAG DISP” is set to “OFF” Directory name & File name File name & Elapsed playing time (with track No.*) * When the source symbol animation display is not selected. Notes: • All the files on the disc will be played repeatedly until you stop playback—All File Repeat Play.
Page 22: Locating A File Or Particular Portion On An Mp3 Disc
• When the source symbol animation display is not selected... Album name/ Performer (Directory name*) & Track Title (File name*) Track Title (File name*) & Track No./ Elapsed playing time * When “TAG DISP” is set to “OFF,” or if an MP3 file does not have ID3 tags, directory name and file name appear.
Page 23 To go to a particular directory directly IMPORTANT: To directly select the directories using the number button(s), it is required that directories are assigned 2 digit numbers at the beginning of their directory names. (This can only be done during the recording of CD-Rs or CD-RWs.) Ex.: If directory name is “01 ABC”...
Page 24 To skip to the previous directory—either on the same hierarchy level or on a different hierarchy level On the control panel: 1 Press MODE (M) while playing an MP3 disc. The unit enters the functions mode. 2 Press in the functions mode. Each time you press the button consecutively, the previous directory is located (and the...
Page 25 To skip to the previous directory on the same hierarchy level (only within the same parent directory) On the remote controller: Each time you press the button PRESET consecutively, the previous directory on the same hierarchy level is located (and the first file in the directory starts playing, if recorded).
Page 26: Selecting Mp3 Playback Modes
Selecting MP3 playback modes To play back files at random (Random Play) You can play back all files on the MP3 disc at random. 1 Press MODE (M) while playing an MP3 disc. The MODE unit enters the functions mode. 2 Press RND (random) while still in the functions mode, so that “RANDOM1”...
Page 27: Sound Adjustments
Adjusting the sound You can adjust the sound characteristics to your preference. Select the item you want to adjust. Each time you press the button, the adjustable items change as follows: FADER* (Fader) (Balance) VOLUME VOL ADJ*** (Volume adjust) (Volume) Indication To do: FADER*...
Page 28: Selecting Preset Sound Modes (Eq)
Selecting preset sound modes (EQ) You can select a preset sound mode suitable to the music genre. Press EQ to activate the sound mode (EQ). Each time you press the button, the sound mode (EQ) is activated or deactivated. • When the sound mode (EQ) is activated, the last selected sound mode is recalled and applied to the...
Page 29: Storing Your Own Sound Adjustments
Storing your own sound adjustments You can adjust the sound modes to your preference and store your own adjustments in memory (USER 1, USER 2 and USER 3). • There is a time limit in doing the following procedure. If the setting is canceled before you finish, start from step 1 again.
Page 30: Other Main Functions
OTHER MAIN FUNCTIONS Changing the general settings (PSM) You can change the items listed on the next page by using the PSM (Preferred Setting Mode) control. Basic Procedure Press and hold SEL (select) for more than 2 seconds so that one of the PSM items appears on the display.
Page 31 Auxiliary input switch KEY SEL** External key-operation mode selection IF FILTER Intermediate frequency filter TAG DISP Tag display • Press SEL (select) to finish the setting. * Only for KD-SH707. ** Only for KD-SH909. Set. Counter- Clockwise clockwise Back Advance Back Advance...
Page 32 To set the clock display – CLOCK You can set the clock to be shown on the display when the unit is turned on. When shipped from the factory, the clock is set to be shown on the display. • ON: Clock display is turned on.
Page 33 35. To select the external component to use – EXT IN (For KD-SH707 only) You can connect the external component to the CD changer jack on the rear using the Line Input Adaptor KS-U57 (not supplied).
Page 34 To select the target component to operate through this receiver – KEY SEL (For KD-SH909 only) You can operate either JVC’s DVD player or VCR through this receiver, by using the number buttons on the control panel. When shipped from the factory, these number buttons are set to be used for the DVD operations.
Page 35: Assigning Names To The Sources
Assigning names to the sources You can assign names to stations, CDs, and the external components. After assigning a name, it will appear on the display when you select the source. Sources Maximum number of characters Station frequencies up to 11 characters (up to 30 station frequencies including both FM and AM) CDs*...
Page 36: Changing The Control Panel Angle
Changing the control panel angle You can change the angle of the control panel to four positions. Adjust the angle to the position you want. Each time you press the button, the panel angle changes as follows: When using the remote controller Press ANGLE ∞...
Page 37: Detaching The Control Panel
Detaching the control panel You can detach the control panel when leaving the car. When detaching or attaching the control panel, be careful not to damage the connectors on the back of the control panel and on the panel holder. Detaching the control panel Before detaching the control panel: •...
Page 38: External Component Operations
• To use the external component connected to the MP3 INPUT jack on the control panel, set “AUX IN” to “ON” (see page 34). You can connect a JVC DVD player or VCR to the LINE IN plugs. You can operate a JVC DVD player or VCR through this receiver using the number buttons on the control panel.
Page 39 Note: When you press the above buttons, the display shows “VCR” and its operation mode (such as 3, 7 ). For KD-SH707: You can connect two external components to this unit. Connect one to the auxiliary input jack on the control panel, and the other to the CD changer jack on the rear.
Page 40: Cd Changer Operations
We recommend that you use one of the CH-X series with your unit. If you have another CD automatic changer, consult your JVC car audio dealer for connections. • For example, if your CD automatic changer is one of the KD-MK series, you need a cord (KS-U15K) for connecting it to this unit.
Page 41: Selecting Cd Playback Modes
Elapsed playing time Ex.: When disc number 3 is selected. To show CD Text information This is possible only when connecting a JVC CD automatic changer equipped with CD Text reading capability. See “Playing a CD Text” on page 16.
Page 42 To play back tracks repeatedly (Repeat Play) You can play back the current track or all tracks on the current disc or specified disc in the CD changer. 1 Press MODE (M) while playing a disc. This unit enters MODE the functions mode.
Page 43: Additional Information
ADDITIONAL INFORMATION Sound modes (preset frequency level settings) The list below shows the preset frequency level settings for each sound mode. • You can adjust the preset sound modes (except USER 1/2/3) temporarily. However, your temporary adjustments will be reset when you select another sound mode. Sound Mode 70 Hz...
Page 44: Troubleshooting
TROUBLESHOOTING What appears to be trouble is not always serious. Check the following points before calling a service center. Symptoms • Sound is sometimes interrupted. • Sound cannot be heard from the speakers. • CD-R/CD-RW cannot be played back. • Tracks on the CD-R/CD- RW cannot be skipped.
Page 45 Symptoms • “NO DISC” appears on the display. • “RESET 8” appears on the display. • “RESET 1” – “RESET 7” appears on the display. • Disc cannot be played back. • Files skip, or 00’00” appears and playback stops. •...
Page 46: Maintenance
MAINTENANCE Handling discs This unit has been designed to reproduce the discs bearing the following marks. COMPACT DIGITAL AUDIO You can also play back your original CD-Rs (Recordable) and CD-RWs (Rewritable) either in audio CD format or in MP3 format. How to handle discs When removing a disc from its case, press down the...
Page 47: Specifications
LINE IN: 1.5 V/20 k load MP3 INPUT: 3.5 mm dia. stereo mini jack (analog) Line-Out Level/Impedance: KD-SH909: 4.0 V/20 k load (full scale) KD-SH707: 2.0 V/20 k load (full scale) Output Impedance: 1 k TUNER SECTION Frequency Range: 87.5 MHz to 107.9 MHz (with channel interval set to 200 kHz) 87.5 MHz to 108.0 MHz...
Page 48 Technical Support & Customer Satisfaction Survey. US RESIDENTS ONLY Having TROUBLE with operation? Please reset your unit Refer to page of How to Reset Still having trouble?? USA ONLY Call 1-800-252-5722 http://www.jvc.com We can help you! VICTOR COMPANY OF JAPAN, LIMITED EN, SP, FR 0102MNMMDTJEIN...
Page 49: Localizacion De Averias
• The following illustration shows a typical installation. However, you should make adjustments corresponding to your specific car. If you have any questions or require information regarding installation kits, consult your JVC car audio dealer or a company supplying kits. Before mounting: Press (Control Panel Release button) to detach the control panel if already attached.
Page 50: Electrical Connections
NEGATIVA solamente. Si su vehículo no posee este sistema, será necesario un inversor de tensión, que puede ser adquirido en los concesionarios de JVC de equipos de audio para automóviles. • Reemplace el fusible por uno con la corriente especificada. Si el fusible se quemase frecuentemente consulte con su concesionario de JVC de equipos de audio para automóviles.
Page 51 • If your CD changer is one of the KD-MK series, you need an optional cord (KS-U15K). ONLY FOR KD-SH707: You can also use an external component such as a portable MD player by To antenna connecting the Line Input Adaptor KS-U57 (not supplied). (See diagram A la antena Cuando conecte un cambiador de CD, se recomienda utilizar uno de la serie CH-X.
Page 52 Adaptateur d’entrée de ligne KS-U57 (non fourni avec cet appareil) KD-SH707 JVC CD changer jack Toma del cambiador de CD de JVC Prise CD changeur JVC DVD, VCR or TV / DVD, VCR o TV / DVD, Magnétoscope ou Téléviseur...
Page 53 Canceling the display demonstration / Cancelación de la demostración en pantalla / Annulation de la ENGLISH When shipped from the factory, display demonstration has been activated, and starts automatically when no operations are done and no sound comes in for about 3 minutes. To cancel the display demonstration, follow the procedure below.
