2.4GHz 300Mbps 802.11n Wireless Outdoor Access Point
High Power Outdoor Wireless Coverage
PLANET Technology introduces the latest high power outdoor wireless LAN solution
- the 300Mbps PoE wireless outdoor AP, WNAP-6350. It provides higher transmit
power, better performance, widely coverage and more stable connection than
standard wireless outdoor AP. As an IEEE 802.11b/g/n compliant wireless device, the
WNAP-6350 is able to give stable and efficient wireless performance for long distance
application; while designed with IEEE 802.11n standard and 2T2R MIMO technology
makes it possible to deliver six times faster data rate up to 300Mbps than normal
802.11g wireless device. It also features adjustable output power up to 500mW to
extend broader coverage in outdoor long range application.
Wi-Fi City
WNAP-6350
Antenna
Data Sheet
1
Antenna
WNAP-6350
N
N
N
Antenna
N
WNAP-6350
N
Antenna
WNAP-6350
Key Features
Antenna
N
WNAP-6350
2.4GHz 802.11n
N
WNAP-6350
Industrial Compliant Wireless LAN & LAN
Compliant with IEEE 802.11n wireless technology
capable of up to 300Mbps data rate
Backward compatible with 802.11b/g standard
Equipped with 10/100Mbps RJ-45 Ports for LAN &
WAN, Auto MDI / MDI-X supported
Fixed-network Broadband Router
Supported connection types: Dynamic IP / Static IP /
PPPoE / PPTP / L2TP / IPSec
Supports Virtual Server, DMZ for various networking
applications
Supports DHCP Server, UPnP, Dynamic DNS
RF Interface Characteristics
Built-in two N-Type Female Antenna connectors
High Output Power up to 500mW with multiple
adjustable transmit power control
Outdoor Environmental Characteristics
Aluminum Housing, IP67 Protection
IEEE 802.3af/at Power over Ethernet design
Operating Temperature: -30~75 Degree C
Multiple Operation & Wireless Mode
Multiple Operation Modes: Bridge, Gateway, WISP
Multiple Wireless Modes: AP, Client CPE (WISP), WDS
PtP, WDS PtMP, Repeater
Supports Dual-SSID allowing users to access different
networks through one single AP
Supports WMM (Wi-Fi Multimedia)
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the WNAP-6350 and is the answer not in the manual?

Questions and answers

Summary of Contents for Planet WNAP-6350

  • Page 1 PPPoE / PPTP / L2TP / IPSec standard wireless outdoor AP. As an IEEE 802.11b/g/n compliant wireless device, the WNAP-6350 is able to give stable and efficient wireless performance for long distance • Supports Virtual Server, DMZ for various networking application;...
  • Page 2 Moreover, the WNAP-6350 is rated to operate at the temperature from -30 to 75 Degree C; thus it can operate more stably than general outdoor equipments. It is the best way using the WNAP-6350 to build outdoor wireless access applications between buildings on campuses, business, rural areas and etc.
  • Page 3 Easy Installation & Management With user-friendly Web UI and step by step Setup Wizard, the WNAP-6350 is easy to install, even for users who never experience setting up a wireless network. Furthermore, with SNMP-Based management interface, the WNAP-6350 is convenient to be managed and configured remotely.
  • Page 4 Application Longer distance coverage between LAN connections The WNAP-6350 is a cost-effective outdoor wireless solution for widely open space applications. It is ideal for outdoor wireless connections between buildings. With built-in two N-Type Antenna connectors, the WNAP-6350 brings longer coverage of wireless connection. The WNAP-6350 provides high output power with multiple adjustable Tx controller, which allows CPE users to easily install and adjust the suitable value in appropriate locations.
  • Page 5: Specification

    WNAP-6350 Specification Product 2.4GHz 300Mbps 802.11n Wireless Outdoor Access Point Model WNAP-6350 Hardware Specifications IEEE 802.11b/g/n Wireless LAN IEEE 802.11i Wireless Security IEEE 802.3 10Base-T Ethernet Standard IEEE 802.3u 100Base-TX Ethernet IEEE 802.3x Flow Control IEEE 802.3af/at Power over Ethernet / PD...
  • Page 6: Ordering Information

    WNAP-6350 11F., No.96, Minquan Rd., Xindian Dist., New Taipei City 231, Taiwan (R.O.C.) PLANET reserves the right to change specifications without prior notice. All brand names and trademarks are property of Tel: 886-2-2219-9518 Fax: 886-2-2219-9528 their respective owners. Copyright © 2013 PLANET Technology Corp. All rights reserved.
