INTRODUCTION

Congratulations! You are the proud owner of the finest inverter on the market today - and one very
complex piece of equipment. The Trace Engineering PS Series Inverter/Charger has many features and
capabilities previously either non-existent, or found only in separate products.
With proper installation, the inverter will operate satisfactorily for many applications straight out of the box
using the factory default settings. To fully utilize the inverter's generator inter-active, or utility inter-active
capabilities, it is necessary to understand the way the inverter operates and then tailor its operation via
the SWRC and the user and setup menu systems. This manual will provide the necessary information.
However, it is recommended that you consult with your authorized dealer to ensure correct installation
and maximum utilization of the numerous features of this product. If you do not understand any aspect of
the installation, contact your authorized dealer/installer for assistance.
If you intend to operate the inverter in a utility inter-active mode in which power will be sold to the utility,
you must contact the local utility office and get their approval. The utility may require additional
information that may not be included in this manual. Please contact your Trace Engineering
dealer/installer for assistance.
This manual is specific to models designed for use in Alternative Energy or Back-Up Power systems in
permanent structures, such as homes and commercial buildings. As a minimum, you should read the
sections of the manual that relate to your type of installation. The MENU SYSTEM section, beginning on
page 29, explains how to make changes to the inverter's user/setup menus. The OPERATION section,
beginning on page 55, explains how the inverter works in each of its different modes. Focus on the
Operating Modes that relate best to your type of installation and make the appropriate selections and
adjustments. Installation diagrams are provided for many of the various applications. This menu system
provides control of the inverter, allows features to be enabled, and allows setting of operating parameters.
This is a long manual and much of it is technical. Throughout the manual terms may be used that are
unfamiliar, see the INVERTER/CHARGER TERMINOLOGY glossary on page 114 for clarification. If you
are an insomniac, properly used, this manual is guaranteed to provide several good nights of sleep.
This manual is specific to REVISION 5* PS AE software. Using the optional SWRC Remote Control,
you can verify what revision software your inverter is using by selecting third menu item under the TRACE
ENGINEERING (3) menu heading.
Note: * refers to all revisions from 5.0 to 5.9
Before beginning -
•
Unpack the inverter/charger and verify that you have the correct inverter.
•
Record your model number and serial number below for future reference
•
Verify that you have everything listed on the Packaging Checklist sheet included in your box. If any
items are missing, please call Customer Service at (360) 435-8826.
•
Complete the warranty card and mail it to Trace Engineering within 10 days from the date of purchase
Keep your bill of sale as proof of purchase, should any difficulties arise concerning the registration of
the warranty card.
•
Keep the original carton and packing materials It is the best way to keep the inverter safe if it needs to
be moved.
•
Read this manual and enjoy your inverter/charger!
Model Number: _________________________________
Serial Number: __________________________________
Check out our web site at www.traceengineering.com for more information and answers to your FAQ's
Copyright © Trace Engineering Company, Inc.
5916 - 195th Street N.E.
Arlington, WA 98223
Telephone: 360/435-8826
Fax: 360/435-2229
www.traceengineering.com
INTRODUCTION
Page
PS Series Inverter/Charger
Part No. 3597
5
Rev. D: November 23, 1999
