Noticeable Points While Assembling
3 LVDS Cable Connection
a. DIGITAL B/D part
(Place these CLAMP WIRES as shown in the figure below)
* Make LVDS Cable not to touch on the Terminal Plate while connecting.
b. VIDEO B/D part
CABLE LVDS, S/N : 4856818800
CLAMP WIRE, S/N : 4856818800
CLAMP WIRE, S/N : 4856815900
-39-
