Installation
One HDMI source extension to one local display and multiple remote displays:
Step 1:
power off all devices
Step 2:
connect HDMI source device to HDMI Transmitter (HVE-7004/7008)
cable
Step 3:
connect HDMI Transmitter
HDMI Receiver (HVE-6000)
Step 4:
connect LR Cat.5 HDMI Receiver (HVE-7000)
(HVE-6000)
Step 5:
repeat Step 3 and Step 4 for next HDMI display until all monitor is connected
Step 6:
if local display is required, connect HDMI display to HDMI Transmitter (HVE-7004/7008)
Step 7:
connect power adaptor to HDMI Transmitter (HVE-7004/7008)
Receiver (HVE-7000)
Step 8:
power on all devices
Step 9:
adjust equalizer control knob
*LR Cat.5 HDMI Receiver (HVE-7000) recommended for long range application (1080p
@ 30m). SR Cat.5 HDMI Receiver (HVE-6000) for short range application only (1080p @ 15m)
to LR Cat.5 HDMI Receiver (HVE-7000)
using Cat-X cable
to HDMI display using HDMI cable
to fine tune picture quality
or SR Cat.5 HDMI Receiver
9
using HDMI
or SR Cat.5
and LR Cat.5 HDMI
