Overview
The remote starter module harness will interface with the existing KJ ignition switch
connector, four center-splice connections, and a ground termination. Two wires will
be routed through the cowl panel, to a hood-mounted safety switch and tachometer
connection.

Vehicle Preparation

1. Remove driver's side lower dash
panels, located directly under the
steering column.
A. Pull down lower dash & remove.
B. Remove (2) screws holding lower
under-dash panel. Remove panel.
C. Remove (2) screws on bottom of
steering column shroud.
D. Unsnap & remove steering column
shroud.
2. Remove driver's side dash panel,
located on left side of dash.
A. Gently pull to remove dash panel.
3. Remove driver kick panel cover.
A. Gently pull up & remove driver sill
cover. Gently pull and remove
driver kick panel cover.
