Reassembly

1. Module & Harness mounting.
A. Using supplied wire ties, secure the remote start module to existing
wire harnesses under the left side of the dash.
B. Using supplied wire ties, secure the SKIM/SKREEM Interface
module to an existing wire harness under the dash.
C. Using supplied wire ties, secure the main harness and SKIM/
SKREEM Interface harnesses to existing wire harnesses under the
dash. Ensure no wires will become entangled in the steering column
knuckle and that they are not visible to vehicle occupants.
D. Using a supplied wire tie, secure the programming button to the
harness leading to the vehicle's diagnostic connector. Consistency
in mounting this switch in the same place every time, will make it
easier to find in case the system comes back for service. Also, the
dash will not have to be disassembled to access it.
2. Dash reassembly.
A. Reverse the dash dissassembly procedure.
15
