AUDIO SOURCE
MONO Output
TRS, XLR or RCA
MONO Input
TRS, XLR or RCA
5 – Monitor Layout
The Prodipe studio monitors can be placed in a vertical or horizontal position.
Positioning in Stereo
When designing a studio layout, the positioning of the monitors is of the utmost importance.
Reflection is the most common acoustics problem.
SOURCE AUDIO
LEFT MONO Output LEFT MONO Output
TRS, XLR or RCA TRS, XLR or RCA
IN LEFT IN RIGHT
Figure 10 – Connections
Optimum listening height
Figure 11
Equilateral
Triangle
Stereo Listening Position
Figure 12
No contractual pictures
Copyright © 2012 IPE Music
MONO Input
TRS, XLR or RCA
OUT LEFT
OUT RIGHT
MONO Input
TRS, XLR or RCA
-5-
