- Page 1 Operating Instructions (GB/USA) MODEL: PRS PRSJ UL LISTING COVERS 115V PRS MODEL ONLY PRS/PRSJ 98330 03/28/00...
-
Page 2: Important Safety Instructions
Do not pull or carry by cord, use cord as a handle, close a door on cord, or pull cord around sharp edges or corners. Do not pull/run machine over cord. Keep cord away from heated surfaces. Connect to a properly grounded outlet. See Grounding Instructions. SAVE THESE INSTRUCTIONS PRS/PRSJ 98330 03/28/00... -
Page 3: Hazard Intensity Level
Unless Operation Guide is Read and understood. In Flammable or Explosive areas. In areas with possible falling objects. WHEN SERVICING MACHINE: Avoid moving parts. Do not wear loose clothing; jackets, shirts, or sleeves when working on the machine. Use Windsor approved replacement parts. PRS/PRSJ 98330 03/28/00... -
Page 4: Grounding Instructions
GROUNDING & OPERATION on the machine. This mini-extractor is equipped with a 25 ft. 16/3 power cord. INSPECTION Do not exceed the 50-ft. cord limit. Carefully unpack and inspect your mini- extractor for shipping damage. Each unit is A. SET UP AND OPERATION operated and thoroughly inspected before 1. -
Page 5: Troubleshooting
Clogged spray jet on Remove and clean jets flow cleaning tool Check and replace pump. Faulty pump (Call Windsor Tech. Services first) Incorrectly attached Ensure solution hose coupler is securely attached to solution hose the coupler on the solution tank. Loss of vacuum/... - Page 6 THIS PAGE LEFT BLANK INTENTIONALLY PRS/PRSJ 98330 03/28/00...
-
Page 7: Wiring Diagram
76127 WIRE NUT, CRIMP 3/18G 23181 CORD SET, 18/3 X 25’ SJTW 14832 BREAKER, 6A VDE CIRCUIT 53230 VAC MOTOR ASM, 115V 4.8 2ST 72150 SWITCH, DPDT ON-OFF-ON 10A 65159 PUMP, 100V SOLENOID 65158 PUMP, 120V SOLENOID PRS/PRSJ 98330 03/28/00... - Page 8 FOAM TAPE, 1/32T X 1/2 2SDA FT 57014 NUT, 10-32 HEX 70253 SCR, 10-32 X 1.25 PHMS 84054 SOLUTION VALVE, DHT 39417 HOSE, VAC 44061 JET, 11003 MINI-QUICK (115V) 44062 JET, 110015 MINI-QUICK (100V) 40011 HOSEBARB, 1/8 MPT X 1/4 PRS/PRSJ 98330 03/28/00...
- Page 9 SCREW, 1/4-20 X 1.5 TAP PLTD. 57196 NUT, 1/2 STAR LOCK PUSH-ON 57104 NUT, 10-32 HEX W/ STAR WASHER 89048 WHEEL 57047 NUT, 1/4-20 LOCK 27637 BASE, CART PRESTO 70088 SCREW, 10-32 X 1/2 PHMS 140088 BASKET, 3 BOTTLE 18010 CASTER, SWIVEL PRS/PRSJ 98330 03/28/00...
- Page 10 PRESTO MINI EXTRACTOR-PARTS BREAKDOWN PRS/PRSJ 98330 03/28/00...
- Page 11 WASHER, 1/4 ID X 1.25 OD PLTD. 14942 BOOT, 5/8 CIRCUIT BREAKER 70517 SCREW, 8-32 X 1/2 FHMS SS 35173 GASKET, NIPPLE SEAL 57208 NUT PG11 METAL, 1.024 OD X 0.73 ID 40059 HOSEBARB, 1/8 FPT X 3/8 PRS/PRSJ 98330 03/28/00...
-
Page 12: Suggested Spare Parts
DESCRIPTION NOTES: FROM 44052 JET BODY, MINI-QUICK 44061 JET, 11003-QUICK CHANGE 14832 BREAKER, 6A VDE CIRCUIT 35160 GASKET, 6.8 X 3.4 X 0.125 NEOPRENE 73250 STRAINER, 80 MESH X 3/8 FPT 65158 PUMP ASM, 120V 60HZ SOLENOID PRS/PRSJ 98330 03/28/00... -
Page 13: Limited Warranty
If proof of purchase cannot be identified, the warranty start date is 90 days after date of sale to an authorized Windsor distributor. Parts replaced or repaired under warranty are guaranteed for the remainder of the original warranty period.
