Contents Introduction ....................2 Warnings and cautions ............…...... 3 Main unit descriptions ............…..... 6 Television Installation ..................8 Function Description of Key on Remote Control ..…………….…... 10 The OSD menus ..……………………………….......….... 17 Troubleshooting .................... 24 Display Mode ..........…..........26 Specifications ....................27 Note: All information in this manual may change from time to time without prior notice.
Introduction Thank you very much for your purchase of our LCD TV. It serves as a normal color TV and PC Monitor. To enjoy your set to the full from the very beginning, read this manual carefully and keep it handy for ready reference. Installation Locate the receiver in the room where direct light does not strike the screen.
Warnings and cautions Warning High voltages are used in the operation of this product. Do not remove the back cover of the cabinet. Refer servicing to qualified service personnel. Warning To prevent fire or electrical shock hazard, do not expose the main unit to rain or moisture.
Page 5
Warnings and cautions Caution If the television is to be built into a compartment or similarly enclosed, the minimum distances must be maintained. Heat build-up can reduce the service life of your television, and can also be dangerous. Caution Never stand on, lean on, push suddenly the product or its stand.
Page 6
Warnings and cautions Caution When the product is not used for an extended period of time, it is advisable to disconnect the AC power cord from the AC outlet. Caution Avoid exposing the main unit to direct sunlight and other source of the heat.
Main unit descriptions Control location 1.Power button 2. SOUCRE button ( TV/AV ) 3. MENU button (MENU) ● 4.Program down button ( P -) TV/AV ● 5. Program up button ( P+ ) MENU 6. Volume down button (V-) ● 7.
Page 8
Main unit descriptions Control location 1. AC IN: AC switch and AC power cord socket. 2. HDMI1/ HDMI2: HDMI input socket. 3. VGA: VGA(D-Sub 15pin) input socket. 4. SCART1/ SCART2: SCART input socket. 5. S-VIDEO: S-Video input socket. 6. YPBPR: YPbPr input socket. 7.
Television Installation Connect antenna or video facility 1.Use 75 Ω coaxial cable plug or 300-75 Ω impedance converter to plug in antenna input terminal on the rear of the cabinet. 2.Connect the video facility to the audio, video in jack on the rear of the cabinet.
Page 10
Television Installation The remote control uses two 1.5V AAA batteries. For battery installation and replacement are as following: 1. Turn the remote control unit upside down. Press down the grip of battery compartment and slide the color in the direction of the arrow. 2.
Function Description of Key on Remote Control The location and function of key in the remote control are as the following picture: (PN: SMC-OTH-3211RC01) 1. [ POWER ] Turn on and off, carry out the function of standby and turn-on. 2.
Page 12
5. [ DISPLAY ] Display the following information: (1) The current program number or signal source. (2) The stereo mode. 6. [ SCART ] Press the key to switch to the SCART mode, Press [SCART] key again to the SCART2 mode. 7.
Page 13
11. [ -/-- ] Numeric digits select: - 1 digit mode -- 2 digit mode --- 3 digit mode 12. [ RETURN ] Jump back to the previous program or source. 13. [ PICTURE ] Press [PICTURE] key, then picture will change as follows: STANDARD→DYNAMIC→SOFT→PERSONAL.
Page 14
15. [ SOURCE ] Press [ Source ], signal source changes as following: PC→HDMI→HDMI2→TV→AV→SVIDEO→SCART→SCART2→YPBPR Press [ CH- /CH+] key to select above source. Press [VOL-/VOL+] key to enter. 16. [ PREVIEW ] Press [PREVIEW] key to enter preview mode, and again to play program, you can select your program by the [VOL-/VOL+] or [CH-/CH+] key, press [MENU] key to play normally and quit preview mode.
Page 15
20. [ RED ] (for Teletext) It carries out the function of red key while in the mode of text. 21. [ GREEN ] (for Teletext) It carries out the function of green key while in the mode of text. 22.
Page 16
26. [ SIZE ] (for Teletext) While entering the mode of text, it is used to change the display scale of text. 27. [ SUBPAGE ] (for Teletext) If already entered text mode via [TXT/CC] key, this key functions as sub-page. After pressing this key, 4 digit key of sub-page number should be entered next.
Page 17
31. [ SIZE ] (for PIP) While entering the mode of PIP, it is used to change the display scale of sub-window. 32. [ POSITION ] (for PIP) While entering the mode of PIP, it is used to adjust the horizontal and vertical position of sub-window. 33.
The OSD menus OSD adjustment in TV, AV, S-VIDEO, YPBPR, SCART mode: . Press [MENU] key and you can get the OSD menu. Press [VOL-/VOL+] key and you can select different sub-menus, five classes altogether. Press [CH-] key to enter the sub-menu. PICTURE 1.
Page 19
SOUND 1. The right picture is the sketch map of the sound menu. 2. The definition of each option: . SOUND MODE: Set the sound mode in the sequence of STANDARD→NEWS→MUSIC→PERSONAL→STANDARD by using the [VOL- / VOL+] key. . BASS: Change the value of bass with the [VOL- / VOL+] key rang of 0 to 100.
Page 20
ADVANCE 1. The right picture is the sketch map of the sound menu. 2. Introduction to each item: . NR: Set the Noise Reduction by using the [VOL-/VOL+] key → → → as following: OFF WEAK MIDDLE STRONG . . Blue Screen: Set the function of blue background on or off. .
Page 21
SYSTEM 1. The right picture is the sketch map of the SYSTEM menu. 2. The definition of each option: . OSD Language: Select the language of the OSD menu by press [VOL-/VOL+] key, language will be changed as follows: English→ Russian→French→German→Italian→Spanish→ →...
Page 22
TV CHANNEL 1. The right picture is the sketch map of the TV menu. 2. The definition of each option: . Color System: Color system setup. Press [VOL-/VOL+] key, → → color system changes as follows: AUTO SECAM . . Sound System: Sound system setup. Press [VOL-/VOL+] key, →...
Page 23
GERMANY → SWITZERLAND → SWI-FRA → SWI-ITA → BELGIUM → BEL-DUTCH → NETHERLANDS → DENMARK → FINLAND → ITALY → NORWAY → SWEDEN → LUXEMBOURG → FRENCH → CZECH → POLAND→HUNGARY→CROATIA→ENGLAND→AUSTRIA . OSD Adjustment in PC/HDMI mode . Press [MENU] key and you can get the OSD menu. Press [VOL-/VOL+] key and you can select different submenus, five classes altogether.
Page 24
GEOMETRY (for PC mode only) 1. The right picture is the sketch map of the GEOMETRY menu. 2. The definition of each option: . H-POSITON: Press [VOL-/VOL+] key to adjust the horizontal position of the display. . V-POSITON: Press [VOL-/VOL+] key to adjust the vertical position of the display.
Troubleshooting Before arranging for service, firstly know the status and then check simply as follows: Problems Check No picture or sound Check if the power supply is plugged in. Check if the power switch is in “on” position. Picture is OK, no sound Check if the volume control is set to the minimum or mute position.
Page 26
Troubleshooting Problems Check Diagonal stripes appear on Check if the power supply is plugged in. picture Check if the power switch is in “on” position. Picture has “snow” Check if the antenna is broken. Check if the antenna is disconnected. Check if the antenna is damaged.
Specifications Items Relevant Illustrations Screen size 32 inch TFT Number of Pixels 1366 x 768 pixel MAX Lifetime Backlight 50,000 hours Color System PAL, SECAM Sound System D/K, BG, I, L/L’ Teletext 100 page storage Channel and Frequencies VHF Low channel (VL)=49.75 to 160.25 MHz VHF high channel (VH)=168.25 to 450.25 MHz UHF channel (UHF)=451.25 to 863.25 MHz Television Channel...
Page 29
Specifications Dimension 898 x 708 x 350 mm (Carton) Net Weight 17 Kg (Net) / 22 Kg (Gross) Accessories User Manual x 1 Warranty Card x 1 Web Registration Card x 1 Remote Control x 1 AAA Battery x 1 (pair) Power Cord x 1 Note: All specifications are subject to change without notice.
