Summary of Contents for DGM LTV-1914WHTC
-
Page 2: Table Of Contents
CONTENTS CONTENTS CONTENTS 1. Safety Warnings and Cautions..................2 1. Safety Warnings and Cautions..................2 1. Safety Warnings and Cautions..................2. Descriptions of Main Unit and Remote-Control Unit............5 2. Descriptions of Main Unit and Remote-Control Unit............5 2. Descriptions of Main Unit and Remote-Control Unit............2.1 Main Unit........................5 2.1 Main Unit........................5 2.1 Main Unit........................ -
Page 3: Safety Warnings And Cautions
1. Safety Warnings and Cautions Warning High voltages are used in the operation of this product. Do not remove the cabinet back from your set. Refer servicing to qualified service personnel. Warning To prevent fire or electrical shock hazard, do not expose the main unit to rain or moisture. - Page 4 Caution If the television is to be built into a compartment or similarly enclosed, minimum distances must be maintained. Heat build-up can reduce the service life of your television, and can also be dangerous. Caution Never stand on, lean on, or push the product or its stand suddenly.
- Page 5 Caution When the product is not used for an extended period of time, it is advisable to disconnect the AC power cord from the AC outlet. Caution Avoid exposing the main unit to direct sunlight and other source of the heat. Do not stand the television receiver directly on other products which give off heat.
-
Page 6: Descriptions Of Main Unit And Remote-Control Unit
2. Descriptions of Main Unit and Remote-Control Unit 2.1 Main Unit 2.2 Front Panel Control 2.2.1. Power: Press to turn on and off the TV. 2.2.2. INPUT: Press to show the input source mode. 2.2.3. Menu: Menu display. 2.2.4. CH+/-: Press to scan thought channels. 2.2.5. -
Page 7: Remote-Control Unit
2.3 Remote-Control Unit 1.POWER Press to turn on and off the TV 2. EPG Electronic Program Guide 3. SLEEP Automatic dormancy time set 4. MUTE Mute voices 5. 0~9 TV channel under the choice 6. -/-- Under TV to 10 frequency channels above frequency channel quicklychoice Under the current TV channel to return to the last channel to watch 8.ASPECT Zoom a picture. - Page 8 DVD Player User’s Manual Press to open and close the disc tray. Allow you to search forward/backward through a disc. When the key is pressed for the first time, the current title will GOTO be highlight. After users press the ENTER/OK key, the program specified by the key value will be played. Pressing “LEFT”...
-
Page 9: Illustration Of The Interface Panel
2.4 Illustration of the Interface Panel .1. Sketch map CVBS &S-Video Right Audio Input HDMI PC Audio Input Audio Earphone Output SCART TV signal Input S-VIDEO SPDIF Output CVBS input CI CARD CVBS &S-Video Left Audio Input... -
Page 10: Specifications
3. Specifications Items Relevant illustrations Screen size, 19 LCD TV visible Screen format 16:10 Resolution 1440X900 Maximum 900:1 contrast ratio Maximum 300 cd/m² brightness Display colors 16.7M Maximum 160° (Horizontal) / 160° (Vertical) viewing angle Maximum 5 ms response time The whole Maximum 50,000 hours... -
Page 11: Connection And Preparation
4. Connections and Preparation 4.1 Connect Antenna or Video Facility 1. Use 75 coaxial cable plug or 300-75 impedance converter to plug in antenna input terminal on the rear of the cabinet. 2. Connect the video facility to the audio, video in jack on the rear of the cabinet. -
Page 12: The Osd Menus
5. The OSD Menus VIDEO menu options Press the MENU button on the front panel or on the remote control to display the main menu. Press button to select PICTURE in the main menu. Press button to select the option that you want to adjust in the PICTURE menu. - Page 13 Sharpness Press to select the sharpness mode of your TV. (Available Sharpness Mode: Normal,Sharp, Sharpest, Softest, Soft.) Color temperature Select an optimum color temperature mode to suit your eyes for viewing among Normal, Warm and Cold. DNR (Digital Noise Reduction) If the broadcast signal received is weak, you can select the DNR option to reduce the video noise level...
- Page 14 Setup menu options Press the MENU button on the front panel or on the remote control to display the main menu. Press the button to select SETUP in the main menu Press the button to select your option what you want to adjust in the SETUP menu.
- Page 15 Manual Tuning This option allows you to perform Manual Tuning. Note: Before you perform Manual Tuning, you must choose the country where you are by selecting Country option in the FUNCTION menu. 1. Press to select Manual tuning in SETUP menu 2.
- Page 16 Program Edit This function allows you to sort the TV programs according to your preferences, as following: Fl a g s Skip F avorite Move Lock 1. Press to select Program Edit in SETUP menu. 2. Press to enter into the sub menu, a channel list will display. 3.
- Page 17 Function menu options Press the MENU button on the front panel or on the remote control to display the main menu. Press the button to select FUNCTION in the main menu. Press the button to select your option what you want to adjust in the FUNCTION menu.
-
Page 18: Osd Adjustment In Dtv Mode
DVB Operation Channel List options Press ENTER button to open the Channel List, then Press to select the channel you want to watch. Favorite List options Press FAV button to open the Favorite List, then Press to select the channel you want to watch. - Page 19 Channel Search options Press the button to select SETUP in the main menu. Press the button to select your option what you want to adjust in the SETUP menu. Press the button to adjust When you are satisfied with your adjustment, press the MENU button to return to the previous menu or press the EXIT button to exit the main menu.
- Page 20 Program Edit This function allows you to edit the DTV programs according to your preferences, as following: Common Interface If you have inserted the CI card to the TV, you can see the information of the it. Common Interface 'ENTER' to select; 'MENU' to return Use EPG button on the remote control to display the EPG menu directly as below: Channel Schedule G D-1...
