  • Page 2: Table Of Contents

    Contents 1.Introduction ..................1 2.Warnings and Cautions ..............2 3.Main Unit Description ............... 4 4.Television Installation ................7 5.Definition and Function Description of Keys on Remote Control ....9 6.Keys on the main unit and its function ............21 7.Menu Operation and its Functions ............22 8.Operation and its Function Description of Menu ..........33 9.Trouble Shooting ...................34...

  • Page 3: Introduction

    Introduction Thank you for your purchase of our LCD TV/Monitor. To enjoy your set to the fullest, read this manual carefully and keep it handy for future reference. Installation Locate the receiver in the room where direct light does not strike the screen. Total darkness or a reflection on the picture screen can cause eyestrain.

  • Page 4: Warnings And Cautions

    Warnings and cautions Warning High voltages are used in the operation of this product. Do not remove the back cover of the cabinet. Refer servicing to qualified service personnel. Warning To prevent fire or electrical shock hazard, do not expose the main unit to rain or moisture.
  • Page 5 Warnings and cautions Minimum distances 10cm 10cm Caution 20cm If the television is to be built into a compartment or similarly enclosed, the minimum distances must be maintained. Heat build-up can reduce the service life of your television, and can also be dangerous. Caution Never stand on, lean on, push suddenly the product or its stand.

  • Page 6: Main Unit Description

    Warnings and cautions Caution When the product is not used for an extended period of time, it is advisable to disconnect the AC power cord from the AC outlet. Caution Avoid exposing the main unit to direct sunlight and other source of the heat.
  • Page 7 Main unit descriptions Control location 1.Power button 2.Volume down button ( V- ) 3.Volume up button ( V+ ) 4.Program down button (P-) 5.Program up button ( P+ ) 6.MENU button (MENU) 7.SOURCE button 8.Power indicator SOURCE 9.Remote sensor CVBS MENU 10.CVBS AUDIO R...
  • Page 8 Main unit descriptions Control location . AC power switch 16 . AC power cord socket 17.Antenna input socket (75 Ù) 18. Earphone socket 19. VIDEO, S-VIDEO and audio(L/R) input socket 20. SCART2 socket 21. SCART1 socket 22. Y Pb/Cb Pr/Cr , Audio(L/R) input socket 23.HDMI1 input socket 24.HDMI2 input socket 25.VGA AUDIO IN socket...

  • Page 9: Television Installation

    Television Installation Connect antenna or video facility 1.Use 75 coaxial cable plug or 300-75 impedance converter to plug in antenna input terminal on the rear of the cabinet. 2.Connect the video facility to the audio, video in jack on the rear of the cabinet.
  • Page 10 Television Installation Battery installation & replacement for remote control unit. The remote control uses two 1.5V AAA batteries. For battery installation and replacement are as following: 1. Turn the remote control unit upside down. Open the battery compartment cover. 2. Install two new batteries, make sure that battery polarity matches with the marks inside the battery.

  • Page 11: Definition And Function Description Of Keys On Remote Control

    Definition and Function Description of Keys on Remote Control The location and function of keys in the R/C are as the following picture : SIZE INDEX HOLD REVEAL SUBTITLE EXIT PQRS WXYZ -/- - MENU SOURCE MUTE SCAN SLEEP CALL FREEZE ZOOM I/II...
  • Page 12 Definition and Function Description of Keys on Remote Control 1. STANDBY This key is to operate the function of Stand by and Power on. 2. SOURCE Press this key to call out the signal source select Menu as the AV1(Svideo) following sketch map shows.
  • Page 13 Definition and Function Description of Keys on Remote Control Go back to the last channel or source. 5. Numeric digits select -/-- When one-digit is input, use NUM keys [0] ~ [9] directly. If user wants to enter two-digit or three digit press [-/--] first to switch to two or three digit input and then use the NUM keys [0]~[9] to enter the number of the channel;...
  • Page 14 Definition and Function Description of Keys on Remote Control 7. [P+]/ [P-] Press this key to turn to the next or previous program of which the SKIP is set to off. If it's not TV source in the main window, Switch to TV source. 8.
  • Page 15 Definition and Function Description of Keys on Remote Control 11. ( I/II)Support NICAM and A2 as well Press I/II , to switch the sound signal in turn as the following table shows while the icons change synchronously. 12. TXT Use this key to switch between the TELETEXT information revealing and the normal display in turn as follows: Normal TEXT.

  • Page 16: Size

    Definition and Function Description of Keys on Remote Control 13. MIX Use this key to switch between the TELETEXT information revealing and the mix mode display in turn as follows: TEXT MIX. In the MIX mode, text will be lap over the TV picture with a transparent background. 14.
  • Page 17 Definition and Function Description of Keys on Remote Control 17. REVEAL Reveal / conceal some of the concealed information of the current text page. 18. SUBPAGE At the TEXT mode, press this key to enter the selected sub page. 19. EXIT Use this key to switch between the TELETEXT information revealing and the normal display in turn as follows: TEXT Normal.
  • Page 18 Definition and Function Description of Keys on Remote Control following sketch map shows. Use [ ]/[ ]/[ ]/[ ] to select program the picture of the selected program is highlighted by a blue frame and press [OK] or [MENU] to confirm so that it goes to the aimed channel and then exit the scan mode.
  • Page 19 Definition and Function Description of Keys on Remote Control 23. PIP To call out or cancel the PIP function that executes in turn as: SINGLE PIP PBP POP SINGLE 24. PIP P+/P- Use this key to turn to next or previous program of the PIP when the sub source is TV. If it's not TV source in the sub window, Switch to TV source.
  • Page 20 Definition and Function Description of Keys on Remote Control AV1(Svideo) AV2(Svideo) HDMI1 HDMI2 YPbPr SCART1 SCART2...

  • Page 21: Index

    Definition and Function Description of Keys on Remote Control 27. [SWAP] Swap the source of the main window and of the sub window. 28. [PIP SIZE] Change the size of the PIP window. 29. [PIP POSITION] To change the position of the PIP, There are 5 available options: User, top left, top right, bottom right, and bottom left.
  • Page 22 Definition and Function Description of Keys on Remote Control Multiple-use key 2[the Green key] - [ |S| ] Press this key to select Main sound mode from USER, SPEECH, MUSIC, and THEATRE in turn. At the same time, corresponding information is displayed at the bottom of the picture. Multiple-use key 3[the Yellow key] - [SLEEP] Press this key to set the sleep timer.

  • Page 23: Keys On The Main Unit And Its Function

    Definition and Function Description of Keys on Remote Control Multiple-use key 5[OK] [OK] Press this key to confirm and call out the function.If there are no any OSD on screen, this key call out the OSD menu to adjust picture items.Press this key to select from Brightness, Contrast, Color, Sharpness, and TINT in turn.

  • Page 24: Menu Operation And Its Functions

    Menu Operation and its Functions The menu of the picture value adjustment: 1. picture 1.1 Windows: It is to select between the main and sub picture.Only in the POP, PIP, and PBP mode, Windows is an optional item. 1.2 Brightness: Adjust the brightness of the picture. 1.3 Contrast: Adjust the contrast of the picture.
  • Page 25 Menu Operation and its Functions...
  • Page 26 Menu Operation and its Functions 2. Audio 2.1 Volume: Adjust the volume ranging from 0 to 100 by using the [ ]/[ ] key. 2.2 Mode: Adjust the sound effect and the available options are including: USER, THEATER, MUSIC, and NEWS. 2.3 Balance: Adjust the balance between the left and right sound track through [ ]/[ ] key ranging from -50 to +50.
  • Page 27 Menu Operation and its Functions...
  • Page 28 Menu Operation and its Functions 2.6.2 Earphone Volume: Adjust the volume of the headphone. 2.6.3 Earphone Bass: Adjust the bass of the headphone. 2.6.4 Earphone Treble: Adjust the treble of the headphone. 2.6.5 Equalizer: Adjust the equalizer,press the [ ] key to enter as the following sketch map shows: Use the [ ]/[ ] key to select items and use [ ]/[ ] to change the value.
  • Page 29 Menu Operation and its Functions 3.4 SUB Source: Signal source of the sub-picture. TV, VGA, AV1, AV1 (Svideo), AV2, Av2 (Svideo), YPbPr, HDMI1,HDMI2,SCART2, and SCART1 are available. 3.5 PIP Size: Use [ ]/[ ] to change the picture size of the PIP. . 3.6 PIP Transparency: Adjust the Transparency of the PIP.
  • Page 30 Menu Operation and its Functions 4.6 Fine Tune: To make the fine tune of the current program to improve the quality of the picture. 4.7 Program Scan: Use the [ ] key to operate the scan. Note: The Program menu is only active in TV and single window mode. 4.8 Program Table:When it is not in the mode of TEXT or MIX, and there is no PIP or PBP, which means the current picture is the only picture displayed, and the signal source is TUNER as well, press this key to enter the Program Guide option.
  • Page 31 Menu Operation and its Functions 4.9 Program Edit: Use the [ ] key to call the program edit menu (1). Program: Use the [ ]/[ ]/ [0~9] keys to select the current program and use [-/--/---] to set the amount of the program number input.
  • Page 32 Menu Operation and its Functions 5. Setup Instructions of the item are as follows 5.1 Language: To set the language of the OSD menu. 5.2 Blue Screen: When there is no signal input, show blue screen. 5.3 OSD Setting: Enter the OSD setting menu the following sketch map shows: Including: 5.3.1 Transparency: Transparency of the OSD menu...
  • Page 33 Menu Operation and its Functions When Lock is selected, menu is called out as the following sketch map: The initialization password is 0000 . Once the correct password is input, screen shows menu as the following sketch map shows:...
  • Page 34 Menu Operation and its Functions Functions of the items are as follows: 5.6.1 Panel Lock When it is set to ON, keys on the main unit are locked, which means they are out of use. 5.6.2 Program: Program number of the current channel. Users can use the NUM keys and [ ]/[ ] to set.

  • Page 35: Operation And Its Function Description Of Menu

    Operation and Function Description of Menu text information of the set channel when the TV is turned on; when it is set to off, this function is canceled. 6.3 Power on Time: To set the power on time. Users can use the NUM keys and [ ] to set the time.

  • Page 36: Troubleshooting

    Troubleshooting Before arranging for service, firstly know the status and then check simply as follows: Problems Check Check if the power supply is plugged in. No picture or sound. Check if the power switch is in "on" position. Picture is OK,no sound. Check if the volume control is set to the minimum or mute position.
  • Page 37 Troubleshooting Problems Check Check if the antenna is broken. All channels lose colour Check if the antenna is disconnected. intermittently. Check if the antenna is damaged. Poor recrption,loss of coulur Check if channels are correctly tuned(see "Fine tuning"). with certain channels. The receiver may be affected by interfernece(e.g.

  • Page 38: Specifications

    Ite m s R e le v a n t ill u s tr a tio n s M IX life t i m e b a c k li g h t 5 0 ,0 0 0 h o u r s N u m b e r o f P ix e ls 1 9 2 0 X 1 0 8 0 p ix e l C h a n n e l a n d fr e q u e n c ie s...
  • Page 41 ¾ ¯ ¸ æ...
  • Page 42 ¾ ¯ ¸ æ º Í × ¢ Ò â 10cm 10cm × ¢ Ò â 20cm × ¢ Ò â × ¢ Ò â...
  • Page 43 × ¢ Ò â × ¢ Ò â × ¢ Ò â...
  • Page 44 SOURCE CVBS MENU AUDIO R AUDIO L S-Video2 EARPHONE POWER...
  • Page 45 Ù VIDEO HDMI1 HDMI2 Pr/Cr Pb/Cb Y AUDIO IN SCART2 SCART 1 S-VIDEO 17 18...

  • Page 48: Hold

    SIZE INDEX HOLD REVEAL SUBTITLE EXIT PQRS WXYZ -/- - MENU SOURCE MUTE SCAN SLEEP CALL FREEZE ZOOM I/II FREEZE SOURCE SWAP SIZE...
  • Page 49 AV1(Svideo) SOURCE AV2(Svideo) HDMI1 HDMI2 YPbPr SCART1 SCART2...
  • Page 51 MUTE...
  • Page 55 22. [...
  • Page 57 AV1(Svideo) AV2(Svideo) HDMI1 HDMI2 YPbPr SCART1 SCART2...
  • Page 58 ] - [ |P| ]...
  • Page 59 ] - [ |S | ] ] - [SLEEP] ] - [CALL] ------ MONO PIP: SCART1 CVBS Sleep OFF 10:20...
  • Page 60 sharpness...
  • Page 66 4. Program Auto search Channel Found Last found Freq.: Manual Search 48.537MHZ Press Menu to Exit Current Channel Last found Freq.: 62.278MHZ Press Menu to Exit...
  • Page 69 5. Setup...
  • Page 71 6. Time...
  • Page 74 背 燈 最 長 使 用 壽 命 　 5 0 , 0 0 0 小 時 。 　 圖 元 　 × 1 9 2 0 1 0 8 0 V H F L o w c h a n n e l ( V L ) = 4 8 . 2 5 t o 1 4 7 . 2 5 M H z 頻...
