Water Level Control - GE Profile WPDH8800J Technical Support

The water level control is installed on the cabinet right side top brace. The water level
control is connected by a hose to an air chamber attached to the bottom of the outer
tub. The water level control consists of 3 internal switches that monitor 4 water level
conditions.
When the water level rises in the outer tub, air is trapped in the air chamber.
As the water level rises, the air pressure in the air chamber increases.
The increased pressure operates the 3 internal switches.
The washer has overflow protection and will automatically pump out regardless of
whether the washer is on or off, as long as the unit is plugged in. This action
supersedes all other commands.
The 3 internal switches are identified as foam, main, and overflow. The 4 water level
conditions monitored are empty, foam, main, and overflow.
CONFIDENTIAL AND PROPRIETARY INFORMATION-NOT FOR PUBLIC DISCLOSURE. September 2008

Water Level Control

30
