The control panel is held in place with 5 Phillips head screws and 1 tab.
To remove the control panel assembly:
1.
Remove the top panel.
2.
Pull the dispenser out to the stop
position. Press down on the lock tab.
Pull the dispenser out.
CONFIDENTIAL AND PROPRIETARY INFORMATION-NOT FOR PUBLIC DISCLOSURE. September 2008
Control Panel
3.
4.
Remove the 2 Phillips-head
screws from the control panel
dispenser recess.
Remove the 3 (7-mm) hex-head
screws that attach the top of the
control panel to the control panel
brace.
13
