Maximum Power Characteristics

Output Rail Current (Max)
5V 6A
3.3V 6A
5VSB 1.5A
-12V 0.15A
12V 4-6A (see below)
When operating at <8V or >16V or extreme temperatures, de-rate by 25-50%, ventilation will be required.
12V Rail Output Current (buck/boost converter)
Input (V) 12V out current
6-8V 4A (6A peak)
8-11V 5A (7A peak)
Support and warranty: Standard Hardware Warranty 1Year / US, 2 Year EU
Installation support: 30days via email,
M3-ATX User Guide
Current Peak Regulation
(<30 seconds)
8A 1.5%
8A 1.5%
2A 1.5%
0.2A 10%
8A (see below) 2%
Input (V) 12V out current
11-16V 6A (8A peak)
16-24V 4A (7A peak)
