SA809 INSTRUCTION MANUAL
We'll Make It Stress-Free
If you have any questions along the way, just give us a call.
1-800-359-5520. We're ready to help!
Scan for more information
san.us/448

Advertisement

loading
Need help?

Need help?

Do you have a question about the SA809 and is the answer not in the manual?

Questions and answers

Summary of Contents for Sanus SA809

  • Page 1 SA809 INSTRUCTION MANUAL We’ll Make It Stress-Free If you have any questions along the way, just give us a call. 1-800-359-5520. We’re ready to help! Scan for more information san.us/448...
  • Page 2 No — Perfect! 30 lb (13.6 kg) Yes — This product is NOT compatible. Visit Sanus.com or call 1-800-359-5520 [UK: 0800 056 2853] to fi nd a compatible product. What is your wall made of? Drywall with Unsure? Call 1-800-359-5520 [UK: 0800 056 2853]...
  • Page 3: Supplied Parts

    Supplied Parts WARNING! This product contains small items that could be a choking hazard if swallowed. Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the damaged item to your dealer; contact Customer Service. Never use damaged parts! STEP 1 Parts STEP 2 Parts STEP 3 Parts...
  • Page 4 Box must be mounted between studs that are at least 406 mm (16 in.) apart. After installation there will not be enough space between the SA809 and the studs for electrical wires/cables, plumbing, ductwork, or insulation. Choose your SA809 location carefully.
  • Page 5 STEP 1 Cut Hole for Housing cont. Use a drywall saw or similar tool to cut the drywall where marked. Remove cut section of drywall. WARNING! ELECTRICAL SHOCK HAZARD! CUTTING OR DRILLING INTO ELECTRICAL WIRES OR CABLES CAN CAUSE DEATH OR SERIOUS PERSONAL INJURY! Always make certain the area behind mounting surfaces is free of electrical wires and cables before cutting, drilling, or installing fasteners.
  • Page 6 Break out the sections of the housing . Optionally, install a UL Listed 120 VAC electrical outlet box (not included) capable of attaching to the SA809 housing following the instructions included with the outlet box. NOTE: Knockouts are provided for ease of installation. Any unused knockouts that have been punched are to be closed up with a metal plug.
  • Page 7 STEP 2 Install Housing cont. Using a screwdriver, turn the screws in the corners of the housing . These will raise the locking tabs in the rear of the housing secure it to the wall. Tighten only until secure. Do not over-tighten screws. View Behind the Wall...
  • Page 8: Step 3 Install Components

    National Electric Code, ANSI/NFPA 70-1999. Refer to communication equipment manufacturer’s specifications for minimum spacings. To use the ECO-Mini (purchased separately) in the SA809, first remove feet. Fit the ECO-Mini into the ECO-Mini bracket...
  • Page 9 STEP 3 Install Components cont. ECO-Mini (purchased separately) with the SA809 - Optional Use two of the screws from the feet to secure the ECO-Mini in the bracket Slide the ECO-Mini and bracket into the top of the housing . Lock the bracket...
  • Page 10 STEP 3 Install Components cont. Use elastic-velcro straps to attach components to the front of the component panel and to secure wires to the back of the panel. NOTE: Zip ties can also be used by looping them through the holes of the component panel to secure components to the component panel...
  • Page 11 STEP 3 Install Components cont. To mount the component panel , press the component panel into the housing until the side buttons "snap" into the depressions in the sides of the housing To remove component panel , grasp panel in the center and pull straight out.
  • Page 12 STEP 3 Install Components cont. Install cover by fitting the bottom tabs of the cover into the bottom slots of the housing . Press near the upper tabs of the cover to "snap" them into the upper slots of the housing...
  • Page 13 Positioning The SA809 can be installed behind most large wall plates of wall mounts. To access the SA809 after installation, disconnect all cables and wires from the TV, then either slide or remove the arm or TV mount from the wall plate.
  • Page 14 Dimensions 0.75 in. 2.87 in. [19.1 mm] [72.9 mm] 14.2 in. [360.7 mm] 11.40 in. [289.6 mm] 8.84 in. [224.6 mm] 3.92 in. [99.6 mm] 14.07 in. [357.5 mm] 4.00 in. 16.63 in. [101.6 mm] [422.4 mm]...
  • Page 16 1. ¿Los accesorios pesan de 13,6 kg (30 lb)? No — ¡Perfecto! Sí — Este producto NO es compatible. Visite Sanus.com o llame al 1-800-359-5520 (Reino Unido: 0800-0562853) para encontrar un producto compatible. 2. ¿De qué está hecha su pared? 3.
  • Page 17 Romper con los sectores de la vivienda. Opcionalmente, instale una lista de UL 120 VAC caja eléctrica de salida (no incluido) capaz de unirse a la carcasa SA809 siguiendo las instrucciones incluidas en la caja de salida. Con cuidado, coloque la carcasa en la sección que cortó...
  • Page 18 Ver página 13 SA809 se puede colocar detrás de la mayoría de las placas murales de los soportes murales. Para tener acceso a SA809 después de la instalación, desconecte todos los cables del televisor, luego deslice o retire el brazo o el soporte del televisor de la placa mural.
  • Page 19 ESPAÑOL...
  • Page 20 Thank you for choosing Sanus! Please take a moment to let us know how we did: Call us: 1-800-359-5520 Email us: info@sanus.com Leave a review: sanus.com UK: 0800 056 2853 Find us on Facebook: SANUS Follow us on Twitter @sanussystems Milestone AV Technologies and its affi liated corporations and subsidiaries (collectively, “Milestone”), intend to make this manual accurate and complete.
