IMPORTANT SAFETY INSTRUCTIONS - SAVE THESE INSTRUCTIONS
Thank you for choosing Accents SAN12. The SAN12 is designed to support audio and video accessory equipment; it is
NOT designed to support a television.The weight capacity for each shelf is 50 lbs (22.5 kg), maximum capacity for the
entire unit is 100 lbs (45.5 kg).
This product is designed for use in wood frame walls only! The wall must be capable of supporting up to five times
the weight of the monitor and mount combined. If you have any doubts about the ability of the wall to support the
monitor, contact Customer Service, or a qualified contractor.
Do not use this product for any purpose not explicitly specified by Accents. Improper assembly may cause
property damage or personal injury. If you do not understand these directions, or have doubts about the safety
of the assembly, contact Customer Service or call a qualified contractor. Accents is not responsible for damage or
injury caused by incorrect assembly or use.
This product contains small items that could be a choking hazard if swallowed. Keep these items away
from young children!
©2008 Milestone AV Technologies. All rights reserved. Sanus Accents is a Milestone Brand. Sanus and Sanus Systems
are registered trademarks, and Sanus Accents and the Sanus Accents logo are trademarks of Milestone.
All other brand names or marks are used for identification purposes and are trademarks of their respective owners.
Sanus Systems 2221 Hwy 36 West, Saint Paul, MN 55113 USA
Customer Service: 1-800-359-5520 • 651-484-7988
info@sanus.com • www.accents.sanus.com
SAN12
(6904-100142 <00>)
CAUTION
CAUTION
WARNING
002752.eps

Advertisement

loading
Need help?

Need help?

Do you have a question about the SAN12 and is the answer not in the manual?

Questions and answers

Summary of Contents for Sanus SAN12

  • Page 1 IMPORTANT SAFETY INSTRUCTIONS - SAVE THESE INSTRUCTIONS Thank you for choosing Accents SAN12. The SAN12 is designed to support audio and video accessory equipment; it is NOT designed to support a television.The weight capacity for each shelf is 50 lbs (22.5 kg), maximum capacity for the entire unit is 100 lbs (45.5 kg).
  • Page 2: Supplied Parts And Hardware

    3/16 in. Supplied Parts and Hardware Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the item to your dealer; contact Customer Service. Never use damaged parts! [03] x 2 [04] x 8 [05] x 2 [02] x 1...
  • Page 3 [02] [01] [02] [01] 6904-100142 <00>...
  • Page 4 3/16 in. NOTE When installed, the top of the pillar [01] will be 6 - 32 mm (0.25 - 1.25 in.) higher than the top of the wall plate [02]. Adjust the placement of the mounting holes to suit your needs. Do NOT mount the top shelf higher than 99 cm (39 in.) above the floor.
  • Page 5 CAUTION Avoid potential injuries or property damage! Be sure the hooks on the wall plate [02] engage with the pillar [01]. The pillar must sit flush with the wall. 6904-100142 <00>...
  • Page 6 1/4 in. [13] 12 mm (0.5 in.) 12 mm (0.5 in.) 6904-100142 <00>...
  • Page 7 [04] [03] 6904-100142 <00>...
  • Page 8 5/32 in. [13] [05] [03] [10] 1.5 mm (1/16 in.) [01] 6904-100142 <00>...
  • Page 9 5/32 in. [13] 6904-100142 <00>...
  • Page 10 NOTE Do NOT mount the top shelf higher than 99 cm (39 in.) above the floor. [06] > 99 cm (39 in.) 002351.eps VF-series - Max Shelf Height 6904-100142 <00>...
  • Page 11 [08] [09] 6904-100142 <00>...
  • Page 12 [07] Milestone AV Technologies and its affiliated corporations and subsidiaries (collectively,“Milestone”), intend to make this manual accurate and complete. However, Milestone makes no claim that the information contained herein covers all details, conditions, or variations. Nor does it provide for every possible contingency in connection with the installation or use of this product. The information contained in this document is subject to change without notice or obligation of any kind.
