Toyota 00016-32901 Installation Instructions Manual

Doc. 02.34.00
TOYOTA Camry
Part Number: 00016-32901
Accessory Code: KE10
Conflicts
NOTE: Not for installation on vehilce's equipped with
factory installed keyless entry.
General Applicability
Power door locks required
Kit Contents
Item # Quantity Reqd
1 1
2 1
3 1
4 1
5 2
6 2
7 1
Hardware Bag Contents
Item # Quantity Reqd
1 8
2 8
3 2
4 6
5 1
6 1
Recommended Tools
Safety Tools
Special Tools
I T
NSTALLATION OOLS
Phillip screwdriver
Ratchet w/extension
Diagonal wire cutters
Flashlight
Torque Wrench
Special Chemicals
Southeast Toyota Distributors, LLC
Description
Keyless Module
Main Harness
Hardware Bag
Valet Switch
24" Cable Ties
3-Button Transmitter
Owner's Card
Description
Red T-Taps
Black T-Taps
Blue T-Taps
8" Cable Ties
2-1/4"x 2-1/4" Foam Pad
Yellow T-Tap
Straight-Slot screwdriver
10 mm socket
Common pliers
Nylon trim tool
48" lbs
PIO / DIO Rev. C
2012 -
Color Applicability/Trim Level
Vehicle/Trim Color
Recommended Sequence of Events
Item # Accessory
Vehicle Service Parts
00016-79200-01
00016-34030-05
00016-32901-01
00016-30960-56
00016-32901-02
00016-30960-09
Legend
STOP: Damage to the vehicle may occur. Do not
proceed until process has been complied with.
OPERATOR SAFETY: Use caution to avoid risk
of injury.
CRITICAL PROCESS: Proceed with caution to
ensure a quality installation. These points will be
audited on a completed vehicle installation.
TOOLS & EQUIPTMENT: This calls out the
specific tools and equipment required for this
process.
REVISION MARK: This mark highlights a change
in installation with respect to previous issue.
SAFETY TORQUE: This mark indicates that
torque is related to safety.
S
SPECIAL NOTE:
After TMS and Safety mandated preparatory steps have been
taken, the installation sequence is the suggested method for
completing the accessory installation. In some instances the
suggested sequence is written for one associate to install and
in others the sequence is given as part of a team accessory
installation. Unless otherwise stated in the document, the
associates may perform the installation steps in any order to
make the installation as efficient as possible while maintaining
consistent quality.
1 of 10
12/16/11
Keyless Entry System
(may be required for reassembly)
1 Keyless Entry Control Module
2 Keyless Entry Transmitter
1 Main Wiring Harness
1 On/Off Toggle Control Switch
1 Miscellaneous Hardware Kit
1 34" Headlight Extension Wire
* Mandatory
