Toyota PT398-60080 Installation Manual

Toyota PT398-60080 Installation Manual

Remote engine starter
Hide thumbs
Table of Contents

Advertisement

Quick Links

TOYOTA
LAND CRUISER
Preparation
Part Number: PT398-60080
or PT398-60101
Conflicts
Do not install into vehicles without RKE systems.
Recommended Sequence of Application
Item #
Accessory
1
XM
XM Radio
2
TVIP
V2 Glass Breakage Sensor (GBS)
and/or
V4 Remote Engine Starter (RES)

Kit Contents

Item #
Quantity
Description
1
1
Wire Harness
2
1
RES ECU Bracket
3
1
Extra Large Wire Tie
Hardware Bag Contents
Item #
Quantity
Description
1
1
RES ECU
2
1
Gateway ECU
3
1
Gateway ECU Bracket
4
1
M6 Tapping Screw
5
15
Wire Ties
6
1
Waterproof Sheet
7
2
Large Foam Tape (1sheet 2pcs)
8
1
Custom Double Stick Tape
9
2
Key Tag (English)
10
2
Window Labels (English)
11
2
Transmitter Labels (English)
12
1
Engine Room Warning Label (English)
13
2
Key Tag (Spanish)
14
2
Window Labels (Spanish)
15
2
Transmitter Labels (Spanish)
16
1
Engine Room Warning Label (Spanish)
17
1
Owner's Guide
Additional Items Required For Installation
Quantity
Description
Item #
1
1
Black Electrical Tape
2
1
Harness Kit PT398-60090-RS for
LC Kit PT398-60080 ONLY see pg. 2
Care must be taken when installing this accessory to ensure damage does not occur to the vehicle. The installation of this
accessory should follow approved guidelines to ensure a quality installation.
These guidelines can be found in the "Accessory Installation Practices" document.
This document covers such items as:
•
Vehicle Protection (use of covers and blankets, cleaning chemicals, etc.)
•
Safety (eye protection, rechecking torque procedure, etc.)
•
Vehicle Disassembly/Reassembly (panel removal, part storage, etc.)
•
Electrical Component Disassembly/Reassembly (battery disconnection, connector removal, etc.)
Please see your Toyota dealer for a copy of this document.
Issue: C
08/19/10
2010 -
REMOTE ENGINE STARTER (RES)
NOTE: Part number of this accessory may not be the same
as the part number shown.
Recommended Tools
Personal & Vehicle
Protection
Safety Glasses
Safety Gloves
Vehicle Protection
Special Tools
Techstream
Installation Tools
Screwdriver
Nylon Panel Removal Tool
Side Cutters
Torque Wrench
Utility Knife
Pliers
Tape
Wrench
Socket
Special Chemicals
Cleaner
Glass Cleaner
Legend
STOP: Damage to the vehicle may occur. Do not
proceed until process has been complied with.
OPERATOR SAFETY: Use caution to avoid risk of
injury.
CAUTION: A process that must be carefully observed
in order to reduce the risk of damage to the
accessory/vehicle and to ensure a quality installation.
TOOLS & EQUIPMENT: Used in Figures calls out the
specific tools and equipment recommended for this
process.
REVISION MARK: This mark highlights a change in
installation with respect to previous issue.
SAFETY TORQUE: This mark indicates that torque is
related to safety.
Page 1 of 27 pages
TVIP V4
Notes
(Optional)
Blankets, Parts Boxes
Notes
Software version 4.00.017 or
later
Notes
#2 Phillips, Flat Blade Jeweler's
e.g. Panel Pry Tool #1
Toyota SST # 00002-06001-01
36 in•lbf (4.07 N•m)
88.5 in•lbf (10 N•m)
Clip Clamp Pliers
Clear
10mm
10mm, Extension, 10mm Deep
Notes
VDC Approved Cleaner
Household Glass Cleaner

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PT398-60080 and is the answer not in the manual?

Questions and answers

Related Manuals for Toyota PT398-60080

Summary of Contents for Toyota PT398-60080

  • Page 1: Kit Contents

    Safety (eye protection, rechecking torque procedure, etc.) • Vehicle Disassembly/Reassembly (panel removal, part storage, etc.) • Electrical Component Disassembly/Reassembly (battery disconnection, connector removal, etc.) Please see your Toyota dealer for a copy of this document. Page 1 of 27 pages Issue: C 08/19/10...
  • Page 2 TOYOTA LAND CRUISER 2010 - TVIP V4 Procedure REMOTE ENGINE STARTER (RES) PT398-60101 OLD HARNESS NEW HARNESS PT398-60080 PT398-60090-RS Page 2 of 27 pages Issue: C 08/19/10...
  • Page 3 TVIP Vehicle Description – 5P WHITE – 5P WHITE – 10P WHITE – 10P WHITE – 20P WHITE for RES ECU – 5P WHITE for Gateway ECU – GROUND WIRE TERMINAL – 2P WHITE – Gateway ECU – 20P BLUE –...

  • Page 4: Vehicle Disassembly

    TOYOTA LAND CRUISER 2010 - TVIP V4 Procedure REMOTE ENGINE STARTER (RES) 1. Vehicle Disassembly. (a) Place the Vehicle in Park with the Parking Brake set. Negative 10mm Socke (b) Remove the Negative Battery Cable. Battery (Fig. 1-1) Cable (1) Protect the Fender before starting.
  • Page 5 TOYOTA LAND CRUISER 2010 - TVIP V4 Procedure REMOTE ENGINE STARTER (RES) (c) Remove the Glove Box Under Cover. Nylon Panel Removal Tool (Fig. 1-3) (1) Begin by protecting the Vehicle Interior with Blankets. Glove Box Under Cover Fig. 1-3 Nylon Panel Removal Tool (d) Remove the Passenger’s Side Dash Side.
  • Page 6 TOYOTA LAND CRUISER 2010 - TVIP V4 Procedure REMOTE ENGINE STARTER (RES) (g) Remove the Passenger’s Side Knee Panel. Nylon Panel Removal Tool (Fig. 1-7) Knee Panel Fig. 1-7 (h) Remove the Passenger’s Side Cluster Side Phillips Screwdriver, Nylon Panel Removal Tool Panel.
  • Page 7 TOYOTA LAND CRUISER 2010 - TVIP V4 Procedure REMOTE ENGINE STARTER (RES) (k) Remove 2 Screws from the bottom of the Phillips Screwdriver Glove Box. (Fig. 1-11) Fig. 1-11 Screws (x2) (l) Open the Glove Box Door, then remove 2 Nylon Panel Removal Tool, 10mm Socket Bolt Covers from the Glove Box.
  • Page 8 TOYOTA LAND CRUISER 2010 - TVIP V4 Procedure REMOTE ENGINE STARTER (RES) VEHICLES EQUIPPED WITH 10mm Deep Socket, Clip Clamp Pliers, Screwdriver NAVIGATION SYSTEM. DVD Unit (p) Remove the DVD Unit from the Glove Box Area. (Fig. 1-15) Screw (1) Remove 2 Screws and 1 Nut.
  • Page 9 TOYOTA LAND CRUISER 2010 - TVIP V4 Procedure REMOTE ENGINE STARTER (RES) (e) Use the existing Vehicle's Bolt to secure the 10mm Socket V4 Harness's Ground Terminal V4 Harness's Ground Terminal with the Vehicle's Ground Vehicle's Ground Terminal. (Fig. 2-4)

  • Page 10: Res Ecu Preparation And Installation

    TOYOTA LAND CRUISER 2010 - TVIP V4 Procedure REMOTE ENGINE STARTER (RES) (i) Secure the 10P Connectors to the Vehicle Side Cutter Harness with 1 Wire Tie. (Fig. 2-8) Wire Tie (j) Secure the V4 Harness to the Vehicle V4 Harness...
  • Page 11 TOYOTA LAND CRUISER 2010 - TVIP V4 Procedure REMOTE ENGINE STARTER (RES) (b) Remove the Backing Sheet of 1 Waterproof Sheet and attach it to the RES ECU near the Waterproof Sheet connectors as shown. (Fig. 3-2) CAUTION: Do not touch the adhesive surface.
  • Page 12 TOYOTA LAND CRUISER 2010 - TVIP V4 Procedure REMOTE ENGINE STARTER (RES) (g) Connect the V4 Harness's White 20P Bolt Connector to the RES ECU. (Fig. 3-6) V4 Harness (h) Using the VDC approved cleaner and Cleaning Method, clean the area indicated on the left side of the Passenger’s Side...
  • Page 13 TOYOTA LAND CRUISER 2010 - TVIP V4 Procedure REMOTE ENGINE STARTER (RES) (m) Attach 1 Large Foam Tape to the Vehicle’s Large Foam Tape Brace and the V4 Harness as shown. Then put the Carpet back. (Fig. 3-9) Vehicle’s Brace GO BACK TO THE V4 HARNESS’S...
  • Page 14 TOYOTA LAND CRUISER 2010 - TVIP V4 Procedure REMOTE ENGINE STARTER (RES) 5. V4 Wire Harness Installation (continued). Side Cutter (a) Route the V4 Harness behind the Vehicle Brace and ECU Brackets as shown. (b) Secure the V4 Harness to the Vehicle Brace Wire Tie with 1 Wire Tie.
  • Page 15 TOYOTA LAND CRUISER 2010 - TVIP V4 Procedure REMOTE ENGINE STARTER (RES) (h) Locate the Vehicle’s 2P Pre-Connector. Side Cutter (Fig. 5-5) 2P Pre- (i) Remove the Break Away Tape from the Connector Connector. (Fig. 5-5) Fig. 5-5 (j) Connect the V4 2P Connector to the 10mm Socket Vehicle’s 2P Pre-Connector.
  • Page 16 TOYOTA LAND CRUISER 2010 - TVIP V4 Procedure REMOTE ENGINE STARTER (RES) (n) Route the remaining V4 Harness as shown. Side Cutter (Fig.5-9) CAUTION: Do not secure the V4 1P RES Diagnostic Connectors. (o) Secure the V4 Harness to the Vehicle Harness with 1 Wire Tie.

  • Page 17: Registration Process

    TOYOTA LAND CRUISER 2010 - TVIP V4 Procedure REMOTE ENGINE STARTER (RES) 6. Partial Reassembly. (a) Reassemble the Vehicle, except for the Passenger's Cowl Cover, and Step Cover. (1) Reconnect any disconnected connectors. (2) Torque the Passenger’s Knee Air Bag to 88.5 in•lbf (10 N•m).
  • Page 18 TOYOTA LAND CRUISER 2010 - TVIP V4 Procedure REMOTE ENGINE STARTER (RES) (e) Ensure all Doors are closed and the Smart EXAMPLE Key is in your possession. (Fig. 7-4) (f) Cycle the Vehicle’s “Engine Start Stop“ Button from “OFF” to “ON” 5 times.
  • Page 19 TOYOTA LAND CRUISER 2010 - TVIP V4 Procedure REMOTE ENGINE STARTER (RES) (m) Connect the Techstream Techstream Notebook Vehicle Diagnostic Port Notebook to the Vehicle’s Diagnostic Port. (Fig. 7-7) With the Remote Control Key in your possession, press the Vehicle’s “Engine Start Stop”...
  • Page 20 TOYOTA LAND CRUISER 2010 - TVIP V4 Procedure REMOTE ENGINE STARTER (RES) Select “Smart Access.” (Fig. 7-10) Click . (Fig. 7-10) Fig. 7-10 Click on “Utility.” (Fig. 7-11) Select “ECU Communication ID Registration.” (Fig. 7-11) (w) Click . (Fig. 7-11) Fig.
  • Page 21 TOYOTA LAND CRUISER 2010 - TVIP V4 Procedure REMOTE ENGINE STARTER (RES) (z) Select “Remote Engine Starter.” (Fig. 7-13) (aa) Click “Next>” to continue. (Fig. 7-13) Fig. 7-13 (bb) Click “Exit.” (Fig. 7-14) Fig. 7-14 (cc) Click . (Fig. 7-15) Example Fig.
  • Page 22 TOYOTA LAND CRUISER 2010 - TVIP V4 Procedure REMOTE ENGINE STARTER (RES) (dd) Close the Hood. (Fig. 7-16) EXAMPLE (ee) The Hazard Lights flash twice. Registration is completed (Fig. 7-16) If this procedure failed, the Hazard Lights flash 3 times. Registration was not set.
  • Page 23 TOYOTA LAND CRUISER 2010 - TVIP V4 Procedure REMOTE ENGINE STARTER (RES) 8. Tags and Label Installation. ● For US Vehicles use the English Labels and discard the Spanish Labels. ● For Mexico Vehicles use the Mexico Labels, and discard the English Labels.

  • Page 24: Completing The Installation

    TOYOTA LAND CRUISER 2010 - TVIP V4 Procedure REMOTE ENGINE STARTER (RES) (g) Use Household Glass Cleaner to clean the Clear Tape inside of the Front Door Window. (Fig. 8-4) (h) Use a piece of Clear Tape to lift the Label Etching off its protective backing.

  • Page 25: Accessory Function Checks

    TOYOTA LAND CRUISER 2010 – TVIP V4 CHECKLIST – These points MUST be checked to ensure a quality installation. REMOTE ENGINE STARTER (RES) Accessory Function Checks Close the hood, enter the vehicle and close all doors. Place the shift lever in the “P” (Park) position, set the parking brake and make sure the Vehicle is off.

  • Page 26: Vehicle Function Checks

    TOYOTA LAND CRUISER 2010 – TVIP V4 CHECKLIST – These points MUST be checked to ensure a quality installation. REMOTE ENGINE STARTER (RES) Vehicle Function Checks Function Function Enter the Vehicle □ □ Steering Wheel Column Adjusts Dome/Courtesy Lights Without Interference □...
  • Page 27 TOYOTA LAND CRUISER 2010 – TVIP V4 CHECKLIST – These points MUST be checked to ensure a quality installation. REMOTE ENGINE STARTER (RES) Function Function □ □ Front Wiper/Washer Rear Wiper/Washer (if equipped) □ □ Power Sun/Moon Roof (if equipped)
